N_One Wireless USB Adapter
Wireless Mode
Prefer Channel
Authentication
Mode
Encryption Method
Create with
Passphrase
Enter Key Manually
Passphrase
Select the desired wireless mode to which you want to
connect. This option only available under Ad-Hoc mode, it
allows user to select the prefer channel.
Select the channel you would like to use under Ad-Hoc
mode. Channel 1 ~ 13.
You MUST select the option to match the Wireless LAN you
wish to join. The available options are:
•
Open System - Broadcast signals are not encrypted.
This method can be used only with no encryption or
with WEP.
•
Shared Key - Broadcast signals are encrypted using
WEP. This method can only be used with WEP.
•
Auto Switch - This is another WEP system; it will
select either Open System or Shared Key as required.
•
WPA-PSK - PSK means "Pre-shared Key". You must
enter this Passphrase value; it is used for both
authentication and encryption.
•
WPA2-PSK - This is a further development of WPA-
PSK, and offers even greater security. You must enter
this Passphrase value; it is used for both authentication
and encryption.
•
WPA Radius - This version of WPA requires a Radius
Server on your LAN to provide the client authentication
according to the 802.1x standard. Data transmissions
are encrypted using the WPA standard.
•
WPA2 Radius - This version of WPA2 requires a
Radius Server on your LAN to provide the client
authentication according to the 802.1x standard. Data
transmissions are encrypted using the WPA2 standard.
The available options depend on the Authentication method
selected above. The possible options are:
•
Security Off - No data encryption is used.
•
WEP - If selected, you must enter the WEP data shown
below. This WEP data must match the Access Point or
other Wireless stations.
•
AES, TKIP - These options are available with WPA-
PSK, WPA2-PSK, WPA-Radius and WPA2-Radius.
Select the correct option.
Enable this check box and enter a word or group of
printable characters in the Passphrase box, select the
desired encryption to automatically configure the WEP Key.
Enable this check box and select the desired key in the
drop-down list. Then enter the key values you wish to use
and select the desired encryption. Other stations must have
matching key values.
For WPA-PSK and WPA2-PSK modes, you need to enter
the desired value (8~63 characters). Other Wireless
Stations must use the same key.
14
