INSTRUCTION MANUAL

Network Camera

MODEL
IPD-BX11
OUTDOOR USE WARNING
WARNING – TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
The apparatus shall not be exposed to
dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the
apparatus.
Ikegami Tsushinki Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPD-BX11 and is the answer not in the manual?

Questions and answers

Related Manuals for Ikegami IPD-BX11

Summary of Contents for Ikegami IPD-BX11

  • Page 1: Instruction Manual

    ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Ikegami Tsushinki Co., Ltd.

  • Page 2: Table Of Contents

    Thank you for choosing this Ikegami Network Camera. Please read this Instruction Manual carefully to keep your Ikegami camera at peak performance for longer service period. This unit is a cube-type 1 CMOS Network Camera and making use of a 1/3” type digital pixel sensor system (DPS).
  • Page 3 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
  • Page 5 14) Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

  • Page 6: Introduction

    Accidents or breakdowns due to mistaken usage or negligence. Disassembly or repair of equipment that is not recognized by Ikegami. Improper use by a third party of the surveillance images produced by this equipment, or damages resulting from such use.

  • Page 7: Cautions Concerning Network Connections

    The contents of information recorded on the SD memory card used with this device may correspond in some cases to private information. If this device is given to a third party due to disposal, transfer or repairs, please be especially careful about handling. 1-4.

  • Page 8: License For Third Party Software

    1-6. License for third party software We are licensed to use the software made by third parties for this product. The license for each software shall be applicable to the software in question respectively and not to the whole software of this product. Certain software used in this product and made by third parties are used based on the following licenses: * GNU General Public License Version 2 (GPL)

  • Page 9: General

    2. General This Network camera is provided with a 1/3-inch DPS CMOS sensor. The CCTV camera features wide dynamic range, high sensitivity and high resolution, and is equipped with the color/black-and-white switching, back- light compensation, automatic iris control, line lock and other functions. The unit is best suited for general surveillance.

  • Page 10: Features

    3. Features (1) Hyper Wide Light Dynamic Range (Hyper WDR) The WDR function provides for very effective compensation of high light and dark areas in screen. This situation may occur generally outside or viewing from indoor to outdoor scenes. Even in large light fl...

  • Page 11: Name Of Each Section And Its Function

    4. Name of each section and its function LENS VIDEO OUT LAN/802.3af DC12V...
  • Page 12 Lens mount (CS mount) This is used to mount the lens on the camera. Many types of CS mount lens can be attached. Back focus lock screw After completing the fl ange back adjustment of the camera, use the supplied Allen wrench to tighten the screw until it is fully fi xed. Holder mounting screw holes These holes are used to install and fi...
  • Page 13 DC12V power input terminal Keep the input power at DC10.5-15.0 V. * This installation should be made by a qualifi ed service person and should conform to all local codes.

  • Page 14: Operating Procedure

    5. Operating Procedure 5-1. User Setup This camera is provided with user setup function for picture quality, and camera ID. In order to set up, use coaxial multiple controller (optional). The setup menu is a tree type on-screen-display. When installing the camera it is possible to set up the various functions. 5-1-1.
  • Page 15 • SWITCHED LEVEL: The brightness level for switching to the day or night mode can be preset. The levels can be selected in the order of BRIGHT, MID and DARK. COLOR: The color mode can be selected. B/W: The Monochrome (B/W) mode can be selected.
  • Page 16 • In case of Red Using the U, D, L or R button, the fi eld can be reduced. • To quit the fi eld setting screen, hold down the E button longer than 2 seconds. Once the 1SPOT ZONE screen appears, select RET and press the E button.
  • Page 17 AWC: This is the so-called one-push automatic white balance control. Shoot a target white subject and press the E button, and the white balance will be adjusted. MANUAL: Adjust manually Select MANUAL, press the E button and the screen at left appears on screen.
  • Page 18 5-1-2. SETUP MENU 2/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CHROMA Possible to adjust chroma level. Adjust while viewing the screen. (3) DETAIL Possible to adjust details. Adjust while viewing the screen. (4) PEDESTAL Possible to choose pedestal level.
  • Page 19 5-1-3. SETUP MENU 3/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CAMERA ID Up to 24 characters can be displayed on screen. OFF: No screen display. ON: Screen display.
  • Page 20 (4) PRIVACY MASK Possible to set up to 8 privacy masks. Move to the Privacy Mask item and press the E button to display screen to the right. * Note: If the camera ID is displayed on the same line as the privacy mask, the mask becomes transparent.
  • Page 21 Mask1 Sky blue Mask1 blue Mask2 Sky blue Mask2 blue Mask3 Sky blue Mask3 blue Mask4 Sky blue and so on. Hold E button more than 2 seconds, the screen changes to the Privacy Mask Setting. This process shall be made after fi nishing mask setting.
  • Page 22 5-1-4. SETUP MENU 4/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) MONITOR The optimum picture quality can be selected according to the monitor used. CRT: To be used when the camera is connected with a CRT (cathode ray tube) monitor.
  • Page 23 *Note Select the video signal method according to your TV system. If the wrong selection is made, the image may be distorted or not displayed. This does not indicate a malfunction. (5) COLOR BAR Press the E buttons to get the color displayed. Press the E button again to go back to the Setup Menu screen.

  • Page 24: Warranty And After-Sale Service

    A warranty accompanies this product. Read and fi ll out the warranty card that you have received at your dealer. Keep this card in a safe place. ● Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics (Europe) GmbH or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period according to the warranty coverage.

  • Page 25: Specifi Cations

    7. Specifi cations (1) Image Sensor: 1/3-inch Pixim DPS CMOS sensor (2) Pixel Number: Approx. 410,000 pixels, 758 (H) x 540 (V) (3) Scanning system: NTCS: 525 TV lines / 59.94Hz , 2 : 1 interlace (4) Sync system: Internal synchronization: Crystal-lock (5) Analog video output: VBS 1.0Vp-p/75 ohms (6) Resolution:...
  • Page 26 (27) Network: Ethernet 10Base-T/100Base-TX (28) Protocol: TCP, UDP, RTP/RTCP, RTSP, HTTP, FTP, NTP, ONVIF support Multicast delivery possible (29) Monitoring: Dedicated viewer or Dedicated recorder (30) Power Requirement: DC 12 V (+10.5V ~ + 15V) PoE (IEEE 802.3af) CLASS 0 (31) Power Consumption: Approx.

  • Page 27: External Appearance

    8. External Appearance 60±3 70±3 LENS VIDEO OUT LAN/802.3af DC12V (22) 2-1/4"-20UNC 14±0.5...

  • Page 28: Setup Flow Chart

    9. Setup Flow Chart...
  • Page 30 MEMO...
  • Page 31 MEMO...
  • Page 32 37 Brook Avenue, Maywood, N.J. 07607, U.S.A. Phone: (201) 368-9171, FAX (201) 569-1626 www.Ikegami.com ■ Ikegami Electronics (Europe) GmbH Ikegami Strasse 1, D-41460 Neuss, Germany Phone : 02131-123-0, FAX 02131-102820 www.Ikegami.de ■ Ikegami Electronics U.K. Offi ce: Unit E1, Cologne Court, Brooklands Close, Windmill Road, Sunbury-on-Thames, Middlesex, TW16 7EB, U.K.
