Ikegami IPD-DM11 Instruction Manual

Ikegami IPD-DM11 Instruction Manual

Network camera
Hide thumbs Also See for IPD-DM11:
Table of Contents

Advertisement

Quick Links

Download this manual

INSTRUCTION MANUAL

Network Camera

MODEL
IPD-DM11
OUTDOOR USE WARNING
WARNING – TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
The apparatus shall not be exposed to
dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the
apparatus.
Ikegami Tsushinki Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPD-DM11 and is the answer not in the manual?

Questions and answers

Related Manuals for Ikegami IPD-DM11

Summary of Contents for Ikegami IPD-DM11

  • Page 1: Instruction Manual

    ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Ikegami Tsushinki Co., Ltd.

  • Page 2: Table Of Contents

    Thank you for choosing this Ikegami Network Camera. Please read this Instruction Manual carefully to keep your Ikegami camera at peak performance for longer service period. This unit is a dome-type 1 CMOS Network camera and making use of a 1/3” type digital pixel sensor system (DPS).
  • Page 3 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
  • Page 5 14) Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

  • Page 6: Introduction

    Accidents or breakdowns due to mistaken usage or negligence. Disassembly or repair of equipment that is not recognized by Ikegami. Improper use by a third party of the surveillance images produced by this equipment, or damages resulting from such use.

  • Page 7: Protection Of Personal Information

    • Mistaken usage method of SD card. • If the SD card was not correctly inserted in the device. • If the SD card has undergone electrical or mechanical shock or force. • If the SD card was removed or the device power was turned off during access to the SD card.

  • Page 8: Ip Address Setting

    1-5. IP address setting The IP camera requires IP address setting. Please set up the IP address and subnet mask in advance. For details of the setting, please consult your network administrator. The IP address of the camera at shipment, the user name, and the password are as shown below: IP address : 192.168.1.100...
  • Page 9 This machine is compatible with PoE (Power over Ethernet) When using the PoE feed HUB, power is supplied from the PoE HUB and there is no need for subsequent "Confi rmation of power-supply voltage" and "Power cable connection". Confi rmation of power-supply voltage Before connecting the power source, please ensure the power-supply voltage is DC10.5 - 15V.

  • Page 10: Limitations On Equipment Use

    1-7. Limitations on Equipment Use This equipment has its usage regulated by the VC-1 and AVC/H.264 Patent Portfolio Licenses Concerning Personal and Non-Commercial Use. This license should be observed in limiting use of this equipment to private use or uses that are non-profi t. For details consult the following: http://www.mpegla.com Reference: Actions permitted by VC-1 and AVC/H.264 images for private...

  • Page 11: General

    The text of the license is included in the Instruction manual (Application Instructions). Distribution of source code of free software If you would like to purchase the GPL/LGPL software used in this product, please contact our sales division. In accordance with the licence terms, we will provide this at cost.
  • Page 12 (5) High-quality picture and high resolution The camera is designed for smear-free imaging and low noise. The well-designed DSP, Digital Signal Processor, effectively enhances details, which achieves crisp and sharp images with a high signal-to- noise ratio. (6) High sensitivity Various modes of Automatic Gain control (AGC) are available to fi...

  • Page 13: Camera Installation

    4. Camera Installation 4-1. Mounting section Holes for camera fixing Ø124 4-2. Mounting the camera (Ceiling) The mounting screw position, please tighten screws through. Camera Screws Dome cover L-form wrench 4-3. Mounting the camera (Wall) Upper The way of installation is the almost same as to a ceiling.

  • Page 14: Name Of Each Section And Its Function

    5. Name of each section and its function...
  • Page 15 Lens fi xing screws (elevation) These are screws to fi x the camera in the desired elevation position. Fix these screws after setting the viewing position. Vari-focal lens Can be used with fl exible angle of view using varifocal lens. FOCUS lever Tighten the screw after focus adjustment.

  • Page 16: Connections

    6. Connections Be sure not to apply power before making connections. 6-1. Power cable Use DC12V (10.5V to 15V). * This installation should be made by a qualifi ed service person and should conform to all local codes. 6-2. Image output cable (RJ-45) This is output terminal for image signal.

  • Page 17: Angle And Lens Adjustment

    7. Angle and Lens adjustment 7-1. Angle adjustment Before doing this, the clear dome cover has to be removed. Remove the dome cover The cover will be removed if the three torque screws are unscrewed. Pay attention not to drop a dome cover while doing this. Note: When imaging in a horizontal direction, the black section of the dome cover may be imaged so that part of the image is missing.

  • Page 18: Operating Procedure

    8. Operating Procedure 8-1. User Setup This dome camera is provided with user setup function for picture quality, and camera ID. In order to set up, use coaxial multiple controller (optional). The setup menu is a tree type on-screen-display. When installing the camera it is possible to set up the various functions. 8-1-1.
  • Page 19 button, and the screen at right shows up. • SWITCHED LEVEL: The brightness level for switching to the day or night mode can be preset. The levels can be selected in the order of BRIGHT, MID and DARK. COLOR: The color mode can be selected. B/W: The Monochrome (B/W) mode can be selected.
  • Page 20 LENS IRIS: Select according to the type of lens used. • DC: Select when using an auto-iris lens. * With the IPD-DM11, remains fi xed in DC mode. (6) GAIN The gain control modes can be selected. AGC: This is an automatic sensitivity adjustment mode.
  • Page 21 the white balance will be adjusted. MANUAL: Adjust manually Select MANUAL, press the SET button and the screen at left appears onscreen. R GAIN is used to adjust the reddish color. B GAIN is used to adjust the bluish color. (8) EXIT Used to save the settings and to quit the menu.
  • Page 22 8-1-2. SETUP MENU 2/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CHROMA Possible to adjust chroma level. Adjust while viewing the screen. (3) DETAIL Possible to adjust details. Adjust while viewing the screen. (4) PEDESTAL Possible to choose pedestal level.
  • Page 23 8-1-3. SETUP MENU 3/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) CAMERA ID Up to 24 characters can be displayed on screen. OFF: No screen display. ON: Screen display.
  • Page 24 (4) PRIVACY MASK Possible to set up to 8 privacy masks. Move to the Privacy Mask item and press the SET button to display screen to the right. * Note: If the camera ID is displayed on the same line as the privacy mask, the mask becomes transparent.
  • Page 25 Mask1 Sky blue Mask1 blue Mask2 Sky blue Mask2 blue Mask3 Sky blue Mask3 blue Mask4 Sky blue and so on. Hold SET button more than 2 seconds, the screen changes to the Privacy Mask Setting. This process shall be made after fi nishing mask setting.
  • Page 26 8-1-4. SETUP MENU 4/4 * New settings can be saved, if EXIT is selected to quit the menu. (1) PAGE Possible to change pages. (2) MONITOR The optimum picture quality can be selected according to the monitor used. CRT: To be used when the camera is connected with a CRT (cathode ray tube) monitor.
  • Page 27 *Note Select the video signal method according to your TV system. If the wrong selection is made, the image may be distorted or not displayed. This does not indicate a malfunction. (5) COLOR BAR Press the SET buttons to get the color displayed. Press the SET button again to go back to the Setup Menu screen.

  • Page 28: Warranty And After-Sale Service

    A warranty accompanies this product. Read and fi ll out the warranty card that you have received at your dealer. Keep this card in a safe place. ● Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics (Europe) GmbH or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period according to the warranty coverage.

  • Page 29: Specifi Cations

    10. Specifi cations (1) Image Sensor: 1/3-inch Pixim DPS CMOS sensor (2) Pixel Number: Approx. 410,000 pixels, 758 (H) x 540 (V) (3) Scanning system: NTCS: 525 TV lines / 59.94Hz , 2 : 1 interlace (4) Sync system: Internal synchronization: Crystal-lock (5) Video output: VBS 1.0Vp-p/75 ohms (6) Resolution...
  • Page 30 (24) Audio function: Built-in AUDIO input : 1 line AUDIO output : 1 line (25) Network: Ethernet 10Base-T/100Base-TX (26) Protocol: TCP, UDP, RTP/RTCP, RTSP, HTTP, FTP, NTP, ONVIF support Multicast delivery possible (27) Monitoring: Dedicated viewer or Dedicated recorder (28) Inclusion lens: Maximum Focal length (f) Field angle (H) Field angle (V)

  • Page 31: External Appearance

    11. External Appearance 3-Ø5 Ø124 Ø148 Ø100...

  • Page 32: Setup Flow Chart

    12. Setup Flow Chart...
  • Page 34 MEMO...
  • Page 35 MEMO...
  • Page 36 37 Brook Avenue, Maywood, N.J. 07607, U.S.A. Phone: (201) 368-9171, FAX (201) 569-1626 www.Ikegami.com ■ Ikegami Electronics (Europe) GmbH Ikegami Strasse 1, D-41460 Neuss, Germany Phone : 02131-123-0, FAX 02131-102820 www.Ikegami.de ■ Ikegami Electronics U.K. Offi ce: Unit E1, Cologne Court, Brooklands Close, Windmill Road, Sunbury-on-Thames, Middlesex, TW16 7EB, U.K.
