- Page 1 MiniView ADC ™ 2-Port ADC Switch User Manual (GCS602) ®...
- Page 2 All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR assumes no responsibility for any inaccuracies or errors that may appear in this document. Reproduction in whole...
-
Page 3: Table Of Contents
Package Contents Overview Features Requirements Introduction Installation Operation Technical Support Troubleshooting Specifications Radio & TV Interference Statement Limited Warranty Table of Contents... -
Page 4: Package Contents
Package Contents The complete MiniView™ ADC package consists of: 1 2-Port ADC KVM Switch 2 ADC Cables 1 User Manual 1 Warranty/ Registration Card If any of the items are missing or damaged please contact your dealer immediately. -
Page 5: Overview
Cinema and Studio flat panel displays utilize the ADC connector interface to manage the connection to the latest Apple® Mac systems. The Miniview ADC KVM Switch GCS602 provides a quick and convenient method to access the comput- ers connected to the system: using the push button Port Selection Switch located on the unit’s top panel. -
Page 6: Features
Studio Display, and 22-inch Apple Cinema Display, etc.) - Easy to install – no software required – connecting cables to the computers is all it takes - Easy to operate – computer selection via push button on KVM switch - LED displays for easy status monitoring... -
Page 7: Requirements
Console • Either 1 ADC Cinema / Studio Display or 1 Analog ADC CRT Monitor Computer • An ADC equipped computer system • A DVI equipped system (additional ADC to DVI adapter required) Please take note of the following: 1. The Apple Display Connector (ADC) cable carries digital and analog video (DVI-D) signals, power and USB, and is compatible with DVI graphics cards, provided that you have the proper adapter/converter to separate out power and USB. -
Page 8: Introduction
Pictorial Introduction Front View 1. Online LED indicators Each CPU Port has a corresponding LED. The LED lights ORANGE when the connected computer is powered on. 2. Selected LED indicators Each CPU Port has a corresponding LED. The LED lights GREEN when its port is selected 3. -
Page 9: Console View
Console View 4. ADC Console Connector Your ADC flat panel display cable plugs in here Pictorial Introduction Computer Side 5. ADC Connector 1 This cable plugs into the ADC port on the computer you are designating as Computer 1 6. ADC Connector 2 This cable plugs into the ADC port on the computer you are designating as Computer 2... -
Page 10: Installation
2. To prevent damage to your equipment due to ground potential difference, make sure that all devices on the installation are properly grounded. Consult your dealer for technical details, if necessary. Step 1. Plug the ADC cable from the ADC display into the Console port connector of the GCS602 unit. - Page 11 Installation Step 2. Plug your USB keyboard and USB mouse into the USB ports on the back of the ADC display.
- Page 12 Installation Step 3. Use the ADC cables to connect the ADC display port of the computers to the ADC Ports 1 and 2 (on the rear panel). Note: If your computer comes with a standard DVI connectors, you need a DVI to ADC adapter (purchased separately).
-
Page 13: Technical Support
This is not the case. Simply use the Port Selection push button (described below), to switch to the active computer on the other ADC 2 port. Step 5. Turn on power to the connected computers that is selected. Note: GCS602 only allows computer to boot on the slected port. Installation... -
Page 14: Operation
Controlling the computers in your MiniView™ ADC installation from a single console is simple. Manual Port Selection Simply press the Port Selection push button on the Master View’s top panel to switch between computers (ADC1, ADC2). The Selected LED on the top panel lights to indicate the active port. -
Page 15: Power Off
Operation Power Off 1. Turn off the power to the connected computers. 2. Unplug each power wall cord from the computers. 3. Unplug the ADC cables from the computers and the Apple display. Important: Failure to follow the above Powering Off steps will result in damage to the connected equipment. -
Page 16: Troubleshooting
Troubleshooting y l t ™ c t i l l a ™ OSD Opera- tion , t r y l l , t r... - Page 17 Continued from last table y l t e i l y t i i l e Troubleshooting e l l l l a ® t i l l ™ ™ y t i y t i...
-
Page 18: Specifications
Specification " 4 " 1 " 5 c i t F ° F ° ° 0 F ° F ° ° 0 o l i ° 0 ° 0... -
Page 19: Radio & Tv Interference Statement
Radio and TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 20: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchant- ability, or fitness for any particular purpose. -
Page 22: Contact Info
® Contact info. 23 Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
