- Page 1 User Manual (GCS634U)
- Page 3 All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this document.
-
Page 4: Table Of Contents
Table of Contents Package Contents Features System Requirements Introduction Installation Operation Specification Technical Support Limited Warranty... -
Page 5: Package Contents
Package Contents This package contains: • 1 4-Port KVM Switch (two cables built-in) • 2 Detachable custom KVM cables • 1 User Manual • 1 Quick Start Guide • 1 Warranty Registration Card If any items are damaged or missing, please contact your dealer. - Page 6 Overview Introducing the four port 4-Port USB KVM switch from IOGEAR® – A simple solution for those with more PCs than hands. Use one USB keyboard, one monitor and one USB mouse to control up to four USB computers. This self-powered KVM switch features the unique USB sniffing technology for USB mouse &...
-
Page 7: Features
Features • Use one USB keyboard, monitor and USB mouse to control up to four USB computers. • Two 6’ long molded-in cables to simplify setup, with two additional detachable cables to reduce clutter. • Share your multimedia speakers among the connected computers. •... -
Page 8: System Requirements
System requirement Console • A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any computer in the installation • A USB Keyboard • A USB Mouse Computers The following equipment must be installed on each computer that is to be connected to the system: •... -
Page 9: Introduction
1) Port LEDs 2) USB Keyboard Port 3) USB Mouse Port 4) VGA Monitor Port 5) Stereo Speaker Port 6) USB Plug (black) 7) VGA Plug (blue) 8) Audio Plug (light green) 9) Custom KVM Plug (dark green) Introduction... - Page 10 Introduction 10) Custom KVM Ports (dark green)
-
Page 11: Installation
1. Plug your keyboard and mouse into the correct USB ports on the side of the switch. If using a wireless keyboard and mouse whose receiver has only one USB plug, make sure it is inserted into the keyboard port and not the mouse port. 2. -
Page 12: Operation
Operation Switching between computers (Toggle keys) By default, all of the following commands begin by pressing the [Scroll Lock] key twice. A few PC keyboards and all Apple keyboards do not have a [Scroll Lock] key. If you have one of these keyboards you must use the alternate toggle key of [Control] instead. - Page 13 Operation mouse) to the exact port number typed. The number must be between 1 and 4, and you must use the numbers across the top of the keyboard, not the number pad. The sound will not switch, allowing you to remain listening to the same computer as before.
- Page 14 Operation Advanced Hotkeys You may enter advanced hotkey mode by pressing and holding [Num Lock] on the number pad, then pressing the [-] key on the number pad and immediately releasing both keys. On Apple keyboards the [Clear] key on the number pad should be used in place of [Num Lock]. If you have done this correctly the Caps Lock and Scroll Lock lights on the keyboard should begin flashing.
- Page 15 Operation [HKM] [A] (number) [Enter] – This will put the switch into Auto Scan mode, disabling the keyboard and mouse but switching the display every few seconds to the next computer. The number typed in determines the number of seconds the switch will remain on each port. Press [Esc] or [Space] to cancel Auto Scan mode.
- Page 16 Operation [HKM] [X] [Enter] – This will disable all toggle key functions. Neither [Scroll Lock] nor [Control] will allow you to change ports until this command is entered again. [HKM] [R] [Enter] – This will reset all KVM settings to their defaults.
- Page 17 Using a PC keyboard to emulate a Sun Keyboard After you set up the appropriate Keyboard Platform, you will be able to use a PC (101/104) key keyboard to emulate the functions of the Sun keyboard when the Control key [Ctrl] is used in conjunction with other keys.
- Page 18 Operation Using a PC keyboard to emulate a Mac Keyboard After you set up the appropriate Keyboard Platform, you will be able to use a PC (101/104) key keyboard to emulate the functions of the Mac keyboard. The corresponding functions are shown in the table to the right.
-
Page 19: Specification
Function Specification CPU Ports Port Selection Hotkeys 4 x Type-A (M) Connectors 4 x HDB-15 (M) Speaker 4 x Audio Jack (M) Console Keyboard 1 x Type-A (F) Connectors Mouse 1 x Type-A (F) 1 x HDB-15 (F) Speaker 1 x Audio Jack (F) LEDs 4 x Green Keyboard / Mouse Emulation... -
Page 20: Technical Support
Technical Support If you need technical support, please check out our IOGEAR Tech Info Library (T.I.L.) at www.iogear.com/support for the latest tips, tricks, and troubleshooting. The IOGEAR T.I.L. was designed to provide you with the latest technical information about our products. Most of the answers to your questions can be found here, so please try it out before contacting technical support. -
Page 21: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCI- DENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchant- ability, or fitness for any particular purpose. - Page 24 Contact Info. Hubble • Irvine, CA 92618 • (P) 949.453.8782 • (F) 949.453.8785 • www.iogear.com...
