User Manual
4-Port USB KVM Switch
Installation
Installation
4-Port USB KVM Switch
GCS634U
PART NO. Q1013-a
Guide
1
GCS634UW6
www.iogear.com
Part No. M1013-a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCS634U and is the answer not in the manual?

Questions and answers

Summary of Contents for IOGear GCS634U

  • Page 1 User Manual 4-Port USB KVM Switch Installation Guide Installation 4-Port USB KVM Switch GCS634U PART NO. Q1013-a GCS634UW6 www.iogear.com Part No. M1013-a...
  • Page 2 International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice.
  • Page 3: Table Of Contents

    Table of Contents Package Contents System requirement Introduction Installation Operation Limited Warranty Federal Communications Commission (FCC) Statement CE Compliance Contact...
  • Page 4: Package Contents

    Package Contents This package contains: • 1 4-Port KVM Switch (two cables built-in) • 2 Detachable custom KVM cables • 1 User Manual • 1 Quick Start Guide • 1 Warranty Registration Card If any items are damaged or missing, please contact your dealer.
  • Page 5: System Requirement

    System requirement Console • A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any . computer in the installation • A USB Keyboard • A USB Mouse Computers The following equipment must be installed on each computer that is to be connected to the system: •...
  • Page 6: Introduction

    Introduction 1) Port LEDs 2) USB Keyboard Port 3) USB Mouse Port 4) VGA Monitor Port 5) Stereo Speaker Port 6) USB Plug (black) 7) VGA Plug (blue) 8) Audio Plug (light green) 9) Custom KVM Plug (dark green) 10) Custom KVM Ports...
  • Page 7: Installation

    Installation Plug your keyboard and mouse into the correct USB ports on the side of the switch. If using a wireless keyboard and mouse whose receiver has only one USB plug, make sure it is inserted into the keyboard port and not the mouse port. Plug your monitor into the VGA port on the side of the switch.
  • Page 8: Operation

    Operation Switching between computers (Toggle keys) By default, all of the following commands begin by pressing the [Scroll Lock] key twice. A few PC key- boards and all Apple keyboards do not have a [Scroll Lock] key. If you have one of these keyboards you must use the alternate toggle key of [Control] instead.
  • Page 9 [Scroll Lock] [Scroll Lock] [a] [Enter] This will start the Auto Scan mode, the KVM focus cycles from port to port at a 5 second interval. [Scroll Lock] [Scroll Lock] [a] [n] [Enter] This will start the Auto Scan mode, the KVM focus cycles from port to port at a [n] second interval. To exit Auto Scan mode, press [Esc] or [Spacebar].
  • Page 10 Advanced Hotkeys You may enter advanced hotkey mode by pressing and holding [Num Lock] on the number pad, then pressing the [-] key on the number pad and immediately releasing both keys. On Apple keyboards the [Clear] key on the number pad should be used in place of [Num Lock]. If you have done this correctly the Caps Lock and Scroll Lock lights on the keyboard should begin flashing.
  • Page 11 Mac keyboard Clear Minus...
  • Page 12 PC keyboard Minus Num Lock...
  • Page 13 [HKM] [T] – This will change the toggle key used to switch between computers. Each time you enter this command the toggle key will switch between the default of [Scroll Lock] and the alternate of [Control]. [HKM] [H] – This will change the hotkey used to enter hotkey mode. Each time you enter this command the keys used to enter HKM will switch between the default of [Num Lock]+[-] and the alternate of [Control]+[F12].
  • Page 14 [HKM] [F4] – This will type out a list of current KVM settings. Open a word processor before using this command in order to see how the KVM is configured. [HKM] [F5] – This will reset the USB ports on the switch, and may clear up any keyboard or mouse problems.
  • Page 15 Using a PC keyboard to emulate a Sun PC Keyboard Mac Keyboard Keyboard [Shift] Shift After you set up the appropriate Keyboard [Ctrl] Ctrl Platform, [Win] you will be able to use a PC (101/104) key keyboard to emulate the functions of the Sun [Ctrl] [4] keyboard when the Control key [Ctrl] is used in [Alt]...
  • Page 16 Using a PC keyboard to emulate a Mac PC Keyboard Sun Keyboard Keyboard [Ctrl] [T] Stop After you set up the appropriate Keyboard [Ctrl] [F2] Again Platform, you will be able to use a PC (101/104) [Ctrl] [F3] Props key keyboard to emulate the functions of the [Ctrl] [F4] Undo Mac keyboard.
  • Page 17: Limited Warranty

    Limited Warranty WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support Warranty Information This product carries a 3 Year Limited Warranty. For the terms and conditions of this warranty, please go to http://www.iogear.com/support/warranty...
  • Page 18: Federal Communications Commission (Fcc) Statement

    Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential setting.
  • Page 19: Ce Compliance

    CE Compliance This device has been tested and found to comply with the following European Union directives: Electromagnetic Capability (2004/108/EC), Low Voltage (2006/95/EC) and R&TTED (1999/5/EC).
  • Page 20: Contact

    Contact IOGEAR Toll Free 866-9-IOGEAR (USA) Phone: 949-453-8782 19641 Da Vinci, Foothill Ranch, CA92610 www.iogear.com support@iogear.com...
