ICFDV Series Direct Vent
Gas Fireplace Insert
Models:
ICFDV30LNTSC, ICFDV30CNTSC
WARNING
IF The INFORMATION IN TheSe INSTRuCTIONS IS NOT
FOLLOWeD exACTLy, A FIRe OR expLOSION MAy
ReSuLT CAuSING pROpeRTy DAMAGe, peRSONAL
INjuRy OR LOSS OF LIFe.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
–
WhAT TO DO IF yOu SMeLL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment, alteration,
services or maintenance can cause injury or property
damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency
or the gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSA only) or
mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from the
manufacturer.
Installation and
Operating Instructions
4164
ICFDV insert cover
Due TO hIGh TeMpeRATuReS, The AppLIANCe
ShOuLD Be LOCATeD OuT OF TRAFFIC AND
AWAy FROM FuRNITuRe AND DRApeRIeS.
ChILDReN AND ADuLTS ShOuLD Be ALeRTeD
TO T h e h A Z A R D S O F h I G h S u R FA C e
TeMpeRATuRe AND ShOuLD STAy AWAy TO
AVOID BuRNS OR CLOThING IGNITION.
yOuNG ChILDReN ShOuLD Be SupeRVISeD
WheN They ARe IN The SAMe ROOM AS The
AppLIANCe.
CLOThING OR OTheR FLAMMABLe MATeRIAL
ShOuLD NOT Be pLACeD ON OR NeAR The
AppLIANCe.
Keep The ROOM AReA CLeAR AND FRee FROM
COMBuSTIBLe MATeRIALS, GASOLINe, AND
OTheR FLAMMABLe VApORS AND LIquIDS.
INSTALLeR: Leave this manual with the appliance.
CONSuMeR: Retain this manual for future refer-
ence.
20304164 10/11 Rev. 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Monessen Hearth ICFDV30LNTSC
Summary of Contents for Monessen Hearth ICFDV30LNTSC
-
Page 1: Installation And Operating Instructions
ICFDV Series Direct Vent Gas Fireplace Insert Models: ICFDV30LNTSC, ICFDV30CNTSC WARNING IF The INFORMATION IN TheSe INSTRuCTIONS IS NOT FOLLOWeD exACTLy, A FIRe OR expLOSION MAy Installation and ReSuLT CAuSING pROpeRTy DAMAGe, peRSONAL INjuRy OR LOSS OF LIFe. Operating Instructions –... -
Page 2: Table Of Contents
CONTeNTS ICFDV Fireplace Insert Thank you and congratulations on your purchase of a Monessen Fireplace Insert pLeASe ReAD The INSTALLATION AND OpeRATION INSTRuCTIONS BeFORe uSING The AppLIANCe! IMpORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMpORTANT SAFeTy INFORMATION ICFDV Fireplace Insert OWNeR INSTALLeR Please retain these instructions for future reference. Please leave these instructions with the appliance. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. • Any change to this fireplace or its controls can be dangerous. -
Page 4: Code Approval
IMpORTANT SAFeTy INFORMATION & CODe AppROVAL ICFDV Fireplace Insert Continued from page 3 IMpORTANT: 14. Do not use any solid fuels (wood, coal, paper, card- pLeASe ReAD The FOLLOWING board, etc.) in this fireplace. Use only the gas type CAReFuLLy indicated on rating plate. -
Page 5: Product Features
Model Fuel BTu/h BTu/h Size ANSI Z223.1/NFPA 54 and/or local codes having juris- ICFDV30LNTSC Nat. 31,000 22,500 diction. In Canada, please consult provincial and/or local authori- ties having jurisdiction for installation at elevations above 4,500 feet (1,370 m). -
Page 6: Insert Dimensions
INSeRT DIMeNSIONS ICFDV Fireplace Insert ” (560 mm) ” (303 mm) ” 10 ” (56 mm) (257 mm) ” (144 mm) " 16 " (535 mm) (410 mm) ” (621 mm) 2 ” 27 ” (689 mm) (57 mm) Figure 2 ICFDV Fireplace Insert Dimensions 4164 ICFDV insert dims... -
Page 7: Installation Information
GeNeRAL INSTALLATION INFORMATION ICFDV Fireplace Insert BeFORe yOu START Read this homeowner manual thoroughly and follow all instructions carefully. Inspect all con- tents for shipping damage and immediately inform your dealer if any damage is found. Do not install any unit with damaged, incomplete, or substitute parts. Check your packing list to verify that all listed parts have been received. -
Page 8: Clearances
CLeARANCeS ICFDV Fireplace Insert INSeRT CLeARANCeS No combustibles (ie: drapes, doors) may be within, or swing within 36" of the front of the insert. 12” (305 mm) Maximum Depth Side Wall 12” (305 mm) 3/4” (19 mm) Maximum Depth Combustible Facing 9”... -
Page 9: Installation
INSTALLATION ICFDV Fireplace Insert INSeRT pLACeMeNT Burn your insert for at least six (6) hours on "HIGH" the first time you use it. Place the fan in the "OFF" position • The insert must be placed within a code-conforming during this time. masonry fireplace or a tested and listed zero-clear- ance (UL-127, solid fuel) fireplace. -
Page 10: Venting Installation
VeNTING INSTALLATION ICFDV Fireplace Insert VeNTING RequIReMeNTS Read all instructions completely and thoroughly before attempting installation. • Failure to do so could result in serious injury, Make sure the exhaust pipe on heater property damage or loss of life. Operation of connects to exhaust portion of cap. -
Page 11: Altitude Considerations
VeNTING INSTALLATION ICFDV Fireplace Insert ALTITuDe CONSIDeRATIONS This heater has been tested at altitudes ranging from sea level to 4,500 feet (1,370 m). In this testing, heater with standard orifice burns correctly with just an air shutter adjustment. If you need to resize orifice for use at high altitude, contact your dealer. -
Page 12: Venting Configurations
VeNTING INSTALLATION ICFDV Fireplace Insert VeNTING CONFIGuRATIONS Termination Kits (Refer to Page 12) Exhaust Inlet 3" (75 mm) Exhaust UL 1777 Gas Liner 3" (75 mm) Inlet Recommended block-off plate (noncombustible metal). Prevents odors from chimney entering room. UL 127 Solid Fuel Z.C Fire- FP1924 Figure 8 -... -
Page 13: Intake/Exhaust Manifold Removal & Vent
VeNTING INSTALLATION ICFDV Fireplace Insert INTAKe/exhAuST MANIFOLD ReMOVAL AND VeNT INSTALLATION The intake/exhaust manifold is shipped attached to insert. It may be removed to allow tight installation. Exhaust Collar 1. Unfasten the two (2) machine screws on the face of the unit and release the plate assembly by sliding the plate back. -
Page 14: Insert Installation
INSeRT INSTALLATION ICFDV Fireplace Insert CheCK GAS Type Use proper gas type for the insert you are installing. If you have conflicting gas type, do not install insert. See dealer where you purchased the insert for proper insert according to your gas type. - Page 15 INSeRT INSTALLATION ICFDV Fireplace Insert A manual shut-off valve is factory installed Only persons licensed to work with gas upstream of the appliance. union tee and piping may make the necessary gas con- plugged 1/8" NpT pressure tapping point nections to this appliance. should be installed upstream of the appli- ance.
-
Page 16: Check Gas Pressure
CheCK GAS pReSSuRe ICFDV Fireplace Insert 1. Check gas type. The gas supply must be the same as Pressure Inlet stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOp! Do not install the appliance. -
Page 17: Electrical Installation
eLeCTRICAL INSTALLATION ICFDV Fireplace Insert eLeCTRICAL WIRING This insert will work without any electrical supply. Electricity is only needed to operate blower. 300 Watts To Outlet A/C Module Verify proper operation after servicing. Pilot Optional Aux. 300 Watts 300 Watts RF Receiver A/C Module ON/OFF Button... -
Page 18: Log Placement
LOG pLACeMeNT ICFDV Fireplace Insert Before you begin - This unit is supplied with six (6) ceramic fiber logs. Do not handle these logs with your bare hands. Always wear gloves to prevent skin irritation from ceramic fibers. After handling the logs, wash your hands gently with soap and water to remove any traces of fibers. -
Page 19: Log Placement
LOG pLACeMeNT ICFDV Fireplace Insert Log #2 3. Align the two pin holes on Log #1 onto the burner. Figure 17 4. Place log #2 by aligning the holes to the burner pin. Figure 17 Figure 17 LG1117 Log #3 Log #1 5. - Page 20 LOG pLACeMeNT ICFDV Fireplace Insert 7. Align log #5 hole to the burner pin and rest on log #2. Figure 20 Log #5 Figure 20 LG1120 8. Align the cutout on the bottom of log #6 and fit it into log #5. Figure 21 LG1120 ICFDV log 5...
- Page 21 OpTIONAL GLASS & STONe INSTALLATION ICFDV Fireplace Insert DeCORATIVe GLASS & STONe INSTALLATION Use caution when handling glass. 1. Remove glass frame using the cam tool supplied with unit. NOTe: The unit is designed to use 2/3 of the glass provided. The remaining decorative glass is intended for future use.
-
Page 22: Surround Installation
SuRROuND INSTALLATION ICFDV Fireplace Insert Insert INSTALL SuRROuND 1. Remove glass door assembly. Page 36, Figure 44 Facing 2. Align cast or beveled surround holes with insert and attach with screws pro- vided. 3. Re-attach glass door assembly. 4. Attach filigree to face by gently pushing into place. - Page 23 SuRROuND INSTALLATION ICFDV Fireplace Insert Figure 26 - Figure 27 - Small Surround with Side FP2953 Trimmable Surround FP2954 Control Access FP2953 sm surr 3 side ctrl FP2954 contemporary surround 20304164...
-
Page 24: Operating Instructions
OpeRATING INSTRuCTIONS ICFDV Fireplace Insert FOR yOuR SAFeTy ReAD BeFORe LIGhTING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of lie. A. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions. -
Page 25: Operating Instructions
OpeRATING INSTRuCTIONS ICFDV Fireplace Insert OpeRATING INSTRuCTIONS 1. STOp! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. With five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOp! Follow "B"... -
Page 26: Signature Command System Operation
SIGNATuRe COMMAND SySTeM OpeRATION INSTRuCTIONS ICFDV Fireplace Insert To Thermopile FeATuReS RF Receiver ON/OFF To Sensor Command Center To Sparker • Easy Access Function Operation and System Configuration • Operation Confirmation/Fault Diagnostic Indications (LED/ NG/LP Conversion Buzzer) • ON/OFF/HI/Med/Low Operation Control •... -
Page 27: System Configuration/Setup
SIGNATuRe COMMAND SySTeM OpeRATION INSTRuCTIONS ICFDV Fireplace Insert SySTeM CONFIGuRATION/SeTup All System configuration/setup is done on the Command Center. NOTe: When using On/Off wall switch, the switch must be in the ON position to perform all configuration set ups at the command center. Intermittent/Standing pilot Setup (Default intermittent) 1. - Page 28 SIGNATuRe COMMAND SySTeM OpeRATION INSTRuCTIONS ICFDV Fireplace Insert FuNCTIONS/OpeRATION (with Command Center) Turning on the fireplace 1. Turn on the master switch and wait for a beep. 2. Press the ON button on the Command Center or turn on wall switch. Pilot will light and burner will come on High set- ting or last memory setting (See Turning Off Fireplace below).
-
Page 29: Touch Screen Remote Control Operation
TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert Due to the sensitive temperature monitoring components in the transmitter, it is necessary to allow the transmitter to stabilize to room tem- perature before accurate room temperatures are displayed. If the transmitter is activated from a severe cold condition, allow 15 minutes for accurate temperature readings to appear on the LCD display. - Page 30 TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert Setting privacy Code on Transmitter: Battery Door Figure 31 The remote transmitter privacy code is preset in factory. In the event of activation or interference from other near- by transmissions, change the code using the following procedures (learn function must be performed after changing the code): FP2650...
- Page 31 TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert c. Slide down on the arrow buttons to exit TIMER 1. Press the ON/up button to turn mode and shut off the fireplace. on the fireplace. The flame icon on the LCD displays High. Thermostat Mode 2.
- Page 32 TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert the Set temperature and the Room temperature. There 5. When the fan button is flashing, slide up and down on is no manual flame height adjustment. The fan speed will the arrow buttons will turn the blower speed to High also automatically adjust if turned on.
-
Page 33: Safety Features
TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert 5. When the light button is flashing, slide up and down on n Safety Features the arrow buttons will turn the light brightness to HIGH 1. Low Battery Detection or Off directly without pressing the light button again to When low battery condition occurs, the transmitter will confirm turn off the fireplace. - Page 34 TOuCh SCReeN ReMOTe CONTROL OpeRATION ICFDV Fireplace Insert n using the Mounting Base The transmitter comes with a mounting base which allows you to hang the transmitter on the wall. 1. Secure the mounting base on the wall with supplied screws.
-
Page 35: Air Shutter Adjustment
AIR ShuTTeR ADjuSTMeNT (NATuRAL GAS ONLy) ICFDV Fireplace Insert ADjuST The AIR ShuTTeR The venturi under the burner is equipped with an air shutter. The opening of the venturi has been set at 3/16" for Natural Gas and fully open for Propane installation at sea level. The burner on Natural Gas models may be adjusted for high altitude as follows: To access the air shutter, remove three (3) screws securing burner to engine base and slide burner to the left or remove from firebox. -
Page 36: Glass Frame Removal
GLASS FRAMe ReMOVAL ICFDV Fireplace Insert Make sure the glass panel edges do not Always use gloves when handling broken touch any metal parts during thermal ex- glass. pansion. GLASS FRAMe ReMOVAL 1. Carefully remove upper filigree by pulling straight out. 2. -
Page 37: Blower Removal And Assembly
BLOWeR ReMOVAL and ASSeMBLy ICFDV Fireplace Insert BLOWeR RepLACeMeNT Turn off the unit and allow to cool completely. Turn off Label all wires prior to disconnection when gas at shut-off and disconnect all electricity to unit. servicing controls. Wiring errors can cause 1. -
Page 38: Cleaning And Maintenance
CLeANING and MAINTeNANCe ICFDV Fireplace Insert Make sure the gas valve knob is in the “OFF” position. Wait at least five (5) minutes before start-ing maintenance. VeNTING SySTeM A qualified agency should examine the venting system annually. CLeANING GLASS Clean the ceramic glass periodically. Condensation will sometimes form on the glass during a cold startup. -
Page 39: Firebox Cleaning
CLeANING and MAINTeNANCe ICFDV Fireplace Insert FIReBOx CLeANING • Allow logs to cool completely before cleaning. Logs reach high tem- peratures. • Make sure clearances to combustibles leave enough room for main- tenance and service. • Carefully reassemble and reseal insert properly after any cleaning or servicing. -
Page 40: Yearly Service Procedure
MAINTeNANCe ICFDV Fireplace Insert yeARLy SeRVICe pROCeDuRe Failure to inspect and maintain heater may lead to improper combustion and a potentially dangerous situation. A qualified technician should do the following once a year. 1. Check pilot flame. Flame should touch approximately 3/8" of the top of thermopile and touch top of thermocouple. -
Page 41: Troubleshooting
TROuBLeShOOTING ICFDV Fireplace Insert SIGNATuRe COMMAND SySTeM OPERATION FAULT ACTION DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about the control 8 seconds board are... -
Page 42: Replacement Parts
RepLACeMeNT pARTS ICFDV Fireplace Insert 20304164 4164 ICDV parts... - Page 43 RepLACeMeNT pARTS ICFDV Fireplace Insert Ref. Description qty. ICFDV30LNTSC ICFDV30CNTSC 1. Log #1 83D1047 2. Log #2 83D1049 3. Log #3 83D1045 4. Log #4 83D1048 5. Log #5 83D1050 6. Log #6 83D1046 7. Stone xx White 20303043 8. Stone xx Black 20303041 9.
-
Page 44: Optional Accessories
OpTIONAL ACCeSSORIeS ICFDV Fireplace Insert 6 a,b 2 a,b 8 a,b,c 9 a,b,c 7 a,b,c Optional Accessories Ref. Description ICFDV30 Light Kit (not shown) ICF30LK Square Face - Textured Black ICF30SFTB Square Face - Iron Age ICF30SFIA Small, 3-sided Surround 5/8" Deep - Black ICF30S3FB Small, 3-sided Surround 2"... - Page 45 ICFDV Fireplace Insert 20304164...
-
Page 46: For Massachusetts Residents Only
ICFDV Fireplace Insert Massachusetts Residents Only — please read and follow these special requirements NOTe ReGARDING VeNTeD pRODuCTS 2. Approved Carbon Monoxide Detectors. Each carbon This product must be installed by a licensed plumber or gas fitter monoxide detector as required in accordance with the above when installed within the Commonwealth of Massachusetts. -
Page 47: Warranty
(3) incidental or consequential damage. All service work must be performed by a Monessen authorized dealer. This warranty is expressly in lieu of other warranties, expressed or implied, including the warranty of mer- chantability of fitness for purpose and of all other obligations or liabilities. -
Page 48: Efficiencies
ICFDV Fireplace Insert efficiency Ratings Model enerGuide Ratings Steady State (%) D.O.e. Fireplace efficiency (%) Fan-OFF Fan-ON (AFue%) ICFDV30LN 71.9 76.5 77.5 67.2 ICFDV30CN 71.9 76.5 77.5 67.2 MhSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com 20304164...
