SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY
THIS MANUAL IS PRINTED ON RECYCLED PAPER
EG 40 Direct Vent
O W N E R S M A N U A L
WHAT TO DO IF YOU SMELL GAS
• Open windows
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Do not store or use gasoline or other Flammable vapors and liquids in the
Massachusetts Installations (WARNING): This product must be installed by a licensed plumber or gas fitter when installed within the
Commonwealth of Massachusetts. Other Massachusetts code requirements:-Flexible connector must not be longer than 36", shutoff valve
must be a "T" handle gas cock, only direct vent sealed combustion products are approved for bedroom/bathrooms, fireplace dampers
must be removed or welded in the open position prior to the installation of a fireplace insert or gas log.
vicinity of this or any other appliance.
B y S H E R W O O D I N D U S T R I E S L T D .
WARNING
If the information in this
manual is not followed exactly,
a fire or explosion may result
causing property damage,
personal injury or loss of life,
installation and service must
be performed by a qualified
installer, service agency or the
gas supplier.
EG40-070

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EG 40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro EG 40

Summary of Contents for Enviro EG 40

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY THIS MANUAL IS PRINTED ON RECYCLED PAPER EG 40 Direct Vent B y S H E R W O O D I N D U S T R I E S L T D .

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS FOR SAFE INSTALLATION AND OPERATION OF YOUR "ENVIRO" STOVE, PLEASE, CAREFULLY READ THE FOLLOWING INFORMATION: • GENERAL To prevent injuries do not allow anyone who is • unfamiliar with the operation to use the stove. Installation and repair should be done by a qualified service person.

  • Page 3: Table Of Contents

    DIRECT VENT GAS FIREPLACE in CANADA and the USA as follows: LISTED GAS FIRED GRAVITY DIRECT VENT WALL FURNACE (EG 40 DV. Nat. & LPG. ) TESTED TO: ANSI Z21.44-1995 GAS FIRED GRAVITY AND FAN TYPE DIRECT VENT WALL FURNACE.

  • Page 4: Deciding Where To Locate Your Stove

    • Before beginning, carefully check the glass door and the log set DECIDING WHERE TO LOCATE YOUR STOVE DIMENSIONS: Front Width: 25" (63 cm) Rear Width: 25" (63 cm) Height: 29-1/8" (74 cm*) Depth 21" (53 cm) (*not including vent coupling) Shipping Weight 256lbs (116 kg) FIG.

  • Page 5: Vent Terminal Clearances

    VENT TERMINAL CLEARANCES H=* Not to be installed above a meter/regulator assembly A= Clearance above grade, verandah, porch, deck, or within 3 feet (90 cm) horizontally from the center-line of balcony [*12 inches (30 cm) minimum] the regulator B= Clearance to window or door that may be opened I= Clearance to service regulator vent outlet [*12 inches (30 cm) minimum] [*6 feet (1.8m) minimum]...

  • Page 6: Planning Your Installation

    RTV High Temperature Silicone be applied to each outer vent joint and milpac to each inner joint before installation. This model has also been tested for horizontal venting installations when using SHERWOOD INDUSTRIES LTD. horizontal venting kit PART # EG 40-500 SHERWOOD INDUSTRIES LTD PARTS: Horizontal direct vent termination cap Spring spacers Flue collar adapter 5”...

  • Page 7: Horizontal Installation

    When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. It is important to note when passing through a wall, the maximum allowable wall thickness is 10-inches (254 mm), 1 ½ inches clearance to combustibles must be maintained.
  • Page 8 STEP 7 . Slide the decorative wall thimble up to the wall surface and attach with the screws provided. Apply decorative brass or chrome trim if desired. FIG-14. FIG. 11 FIG. 12 FIG-13 FIG-14 NOTES (1) The four wood screws provided should be replaced with the appropriate fasteners for stucco, brick, concrete, or other types of siding.
  • Page 9 VERTICAL INSTALLATION STEP 1. Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters, or other nearby combustible surfaces. Do not pack air spaces with insulation. STEP 2. Set the gas appliance in the desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the ceiling.
  • Page 10 NOTES: If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet, to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose. FIG-18 Whenever possible, use 45°- elbows instead of 90°- elbows.

  • Page 11: Cathedral Ceiling Installation

    CATHEDRAL CEILING INSTALLATION STEP 1. Follow installation steps 1 and 2 under Vertical Termination. STEP 2. Using the plumb bob, mark the centerline of the venting system on the ceiling and drill a small hole through the ceiling and roof at this point. From the roof, locate the drill hole and mark the outline of the “Cathedral Ceiling Support Box”. STEP 3.
  • Page 12 Install 2 spring spacers around the flex pipe. Slide the horizontal section of pipe over the flexible liner and install through the wall thimble. Ensure that this portion of pipe slides onto the vent termination cap. Slide the inside finished collar over the horizontal section of pipe and secure to wall using the screws provided.
  • Page 13 VENTING INTO CLASS “A” CHIMNEYS Simpson GS vent cap This model is also certified and tested to vent into CLASS “A” wood stove chimneys. Place the freestanding direct vent appliance in the desired Cap adapter location. Class “a Chimney Using Simpson Dura Vent conversion kit #s 931-932-933, depend on the ID diameter of the CLASS “A”...

  • Page 14: Installation Of Log Sets And Embers

    Use only a single layer. Do not pile embers. The use of other foreign materials on the burners may create dangerous conditions. If over time, through cleaning and servicing, these embers require replacement, contact your nearest ENVIRO dealer for replacement embers.

  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. • A) This appliance is equipped with a pilot, which must be lit by If you cannot reach your gas supplier, call the fire hand by following these instructions exactly.

  • Page 16: Maintenance And Technical

    Check to ensure the pilot Door glass assembly, must be replaced as a flame is blue with small yellow tips. complete unit by your ENVIRO Dealer. No substitute materials are allowed. OPENING THE DOOR FOR CLEANING THE INSIDE OF THE FIREBOX Caution door is hot when in operation.

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING Problem Possible Cause Solution Spark will not light the pilot after Defective piezo ignitor Check connections to ignitor. repeated pressing of spark ignitor -If ignitor connections are good but there is no spark-replace ignitor. Broken spark electrode -Check for broken ceramic insulation Replace, electrode if broken.

  • Page 18: Gas Line Connection

    GAS LINE CONNECTION ORIFICE SIZES, PRESSURE AND BTU’S NATURAL GAS PROPANE GAS FRONT BURNER #48 (1.93 mm) #56 (1.32 mm) REAR BURNER #43 (2.49 mm) #54 (1.40 mm) Manifold pressure. 3.8” WC (0.95kPa) 11 ”WC (2.74kPa) Min. Manifold pressure. 1.1” WC (0.27kPa) 2.7”...

  • Page 19: Electrical

    ELECTRICAL The ENVIRO EG 40.FS.DV will operate with no external power supply. These models have a Millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burner. The appliance when installed must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE.

  • Page 20: Parts And Accessories

    PARTS AND ACCESSORIES Service Parts available from your local Enviro Dealer Burner Control Assembly Convection Blower Natural Gas Pilot Assembly Light Bulb Holder Propane Pilot Assembly Light Switch (momentary) Door Bolt Fan Controller Relief Door Gasket Log Set (with Embers)

  • Page 21: Fuel Conversion

    ADJUSTING THE VENTURIES • here is a separate air shutter for each burner • Remove one screw from the cover plate located below the ash shelf. Loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place.

  • Page 22: Warranty

    WARRANTY Sherwood Industries Ltd. offers a *Lifetime Warranty on this gas product. The lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger.

  • Page 23: Parts List

    EG 40 Rear Log EC-056 Freestanding Pedestal Door Magnet 30-043 Pilot Line with Brass Ferals EC-057 3/8” Tadpole Door Gasket (6.9ft) 50-081 EG 40 Log Set Complete EC-058 Window Channel Tape 50-343 Blank Orifice – Front EC-059 Door Latch Bolt 50-345...

  • Page 26: Installation Data Sheet

    INSTALLATION DATA SHEET The installer for warranty purposes and future reference must record the following information. Please keep this information for your records. Model: EG 40 Name of Owner: Name of Dealer: __________________________________________ ___________________________________________ Address: Address: __________________________________________ ___________________________________________ __________________________________________ ___________________________________________...
