O W N E R S M A N U A L
WHAT TO DO IF YOU SMELL GAS
• Open windows
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Do not store or use gasoline or other
Massachusetts installations (WARNING): This product must be installed by a licensed plumber or gas fitter when installed within the
Commonwealth of Massachusetts. Other Massachusetts code requirements: Flexible connector must not be longer than 36", shutoff valve
must be a "T" handle gas cock, only direct vent sealed combustion products are approved for bedroom/bathrooms, fireplace dampers must
be removed or welded in the open position prior to the installation of a fireplace insert or gas log.
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY
EG 28 B Vented
FOR YOUR SAFETY
this or any other appliance.
B y S H E R W O O D I N D U S T R I E S
If the information in this manual is
property damage, personal injury
qualified installer, service agency
vapors and liquids in the vicinity of
Flammable
WARNING
not followed exactly, a fire or
explosion may result causing
or loss of life installation and
service must be performed by a
or the gas supplier.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EG 28 B and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro EG 28 B

Summary of Contents for Enviro EG 28 B

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY THIS MANUAL IS PRINTED ON RECYCLED PAPER EG 28 B Vented B y S H E R W O O D I N D U S T R I E S O W N E R S M A N U A L...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS FOR SAFE INSTALLATION AND OPERATIONOF YOUR "ENVIRO" STOVE, PLEASE, CAREFULLY READ THE FOLLOWING INFORMATION: • To prevent injuries do not allow anyone who is GENERAL unfamiliar with the operation to use the stove. • Installation and repair should be done by a qualified service person.

  • Page 3: Table Of Contents

    CSA 2.33-M98 VENTED GAS FIREPLACE HEATER CGA 2.17-M91 GAS FIRED APPLIANCES FOR USE AT HIGH ALTITUDE SPECS: ENVIRO EG 28 B VENT UNITS; • Have all been certified for use with either natural or propane gases. (See control panel and rating label.) •...

  • Page 4: Deciding Where To Locate Your Stove

    DECIDING WHERE TO LOCATE YOUR STOVE DIMENSIONS: Front Width: 22" (56cm) Rear Width: 22" (56cm) Height: 27-1/2" (70cm)* Depth: 19" (48cm) (*Not including vent coupling) Shipping Weight: 210 lbs (95 kg) FIG. 1 CLEARANCES: A. Side wall to stove 10" (25cm) B.

  • Page 5: Vent Terminal Clearances

    VENT TERMINAL CLEARANCES Figure 3 A= Clearance above grade, verandah, porch, deck, or H= *Not to be installed above a meter/regulator [balcony (*12 inches (30cm) minimum] assembly within 3 feet (90cm) horizontally from B= Clearance to window or door that may be opened [*12 the center-line of the regulator inches (30cm) minimum] I= Clearance to service regulator vent outlet...

  • Page 6: Venting

    6” decorative, stove pipe. The flue collar of the appliance will fit inside of standard vent and may be fastened directly to the vent. The ENVIRO incorporates its own internal draft hood, so no additional external draft hood is required. Check periodically that the vent is unrestricted and an adequate draft is present when the unit is in operation.
  • Page 7 A. USING AN EXISTING CHIMNEY • Measure the height of the chimney beforehand and purchase the appropriate kit. Never attempt to over stretch a flexible liner to accommodate the height of the chimney. • Any flue damper must be removed or locked permanently in the open position.

  • Page 8: Installation Of Log Sets And Embers

    ENVIRO dealer. (See page 10 glass cleaning.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. • A) This appliance is equipped with a pilot, which must be lit by If you cannot reach your gas supplier, call the fire hand by following these instructions exactly.

  • Page 10: Maintenance And Technical

    Initial paint curing of the The door and glass assembly must be replaced appliance can leave behind a slight film on the glass. as a complete unit. By your ENVIRO Dealer. This is a temporary problem. It is therefore No substitute materials are allowed.

  • Page 11: Trouble Shooting

    TROUBLE SHOOTING Problem Possible Cause Solution Spark will not light the pilot after Defective piezo Ignitor Check connections to Ignitor repeated pressing of spark Ignitor -If Ignitor connections are good but there is no spark-replace Ignitor Broken spark electrode -Check for broken ceramic insulation replace, electrode if broken Miss-aligned spark electrode -If spark is not arcing from the...

  • Page 12: Gas Line Connection

    GAS LINE CONNECTION ORIFICE SIZES, PRESSURE AND BTU’S NATURAL GAS PROPANE GAS Orifice size #43dms #53 dms Manifold pressure. 3.8”wc (0.95kPa) 11” wc (2.74 kPa) Min. Manifold pressure. 1.1”wc (0.27kPa) 2.7” wc (0.67 kPa) Supply Pressure. 7.0”wc (1.74kPa) 12” wc (2.98 kPa) Min.

  • Page 13: Electrical

    ELECTRICAL The ENVIRO EG 28.FS.BV. Will operate with no external power supply. These models have a Millivolt gas control that uses the pilot flame to generate enough electricity to operate the main burner. The appliance when installed, must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE.

  • Page 14: Parts And Accessories

    PARTS AND ACCESSORIES Service Parts available from your local Enviro Dealer Burner Control Assembly Convection Blower Natural Gas Pilot Assembly Light Bulb Holder Propane Pilot Assembly Light Switch (momentary) Door Bolt Fan Controller Relief Door Gasket Log Set (with Embers)

  • Page 15: Fuel Type Conversion

    ADJUSTING THE VENTURI • Remove the ash shelf by undoing the screw at each end, pull shelf towards you. • Remove one screw from the cover plate located below the ash shelf. Loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place.

  • Page 16: Warranty

    WARRANTY Because of our high standards Sherwood Industries Ltd. can offer a *Lifetime Warranty on all it’s gas products. Covered under this warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis. These steel components are covered against manufacture’s defects for 5 years and labor for the first years and for parts only thereafter.

  • Page 17: Parts List

    PARTS LIST EC-001 EG28-108 Freestanding Pedestal 120° F Ceramic Temperature Sensor EC-002 220° F Ceramic Spill Switch EG28-109 Freestanding Pedestal Door EC-006 SIT Nova 820 NG Valve 50% EG28-116A Burner Tray Top (Post 2000) EC-007 SIT Nova 820 LP Valve 50% EG28-120 Freestanding DV Owner’s Manual EC-009...

  • Page 20: Installation Data Sheet

    INSTALLATION DATA SHEET The following information must be recorded by the installer for warranty purposes and future reference. Model: EG 28 B vented Name of Dealer: Name of Owner: ___________________________________________ __________________________________________ Address: Address: __________________________________________ ___________________________________________ ___________________________________________ __________________________________________ ___________________________________________ __________________________________________ Phone: ___________________________________...
