SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY
THIS MANUAL IS PRINTED ON RECYCLED PAPER
EG 28 Direct Vent
O W N E R S M A N U A L
WHAT TO DO IF YOU SMELL GAS
• Open windows
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
Do not store or use gasoline or other Flammable vapors and liquids in the vicinity of
FOR YOUR SAFETY
this or any other appliance.
B y S H E R W O O D I N D U S T R I E S
WARNING
If the information in this manual
is not followed exactly, a fire or
explosion may result causing
property damage, personal
injury or loss of life. Installation
and service must be performed
by a qualified installer, service
agency or the gas supplier.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enviro EG 28
Summary of Contents for Enviro EG 28
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY THIS MANUAL IS PRINTED ON RECYCLED PAPER EG 28 Direct Vent B y S H E R W O O D I N D U S T R I E S O W N E R S M A N U A L...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS FOR SAFE INSTALLATION AND OPERATION OF YOUR "ENVIROGAS" STOVE, PLEASE, CAREFULLY READ THE FOLLOWING INFORMATION: • To prevent injuries do not allow anyone who is GENERAL unfamiliar with the operation to use the stove. • Installation and repair should be done by a qualified service person. -
Page 3: Table Of Contents
DIRECT VENT GAS FIREPLACE in CANADA and the USA as follows: LISTED GAS FIRED GRAVITY DIRECT VENT WALL FURNACE (EG 28 DV. Nat. & LPG. ) TESTED TO: ANSI Z21.88-1998 CSA 2.33-M98 VENTED GAS FIREPLACE HEATER. UL307B-1995 GAS BURNING HEATING APPLIANCES FOR MANUFACTURED HOMES. -
Page 4: Deciding Where To Locate Your Stove
DECIDING WHERE TO LOCATE YOUR STOVE DIMENSIONS: Front Width: 22"/ 56 cm Rear Width: 22"/ 56 cm Height: 27-1/2"/ 70 cm* Depth 19"/ 48 cm (*not including vent coupling) Shipping Weight: 210 lbs/95 kg FIG. 1 CLEARANCES: A. Side wall to stove 10"/ 25 cm B. -
Page 5: Vent Terminal Clearances
VENT TERMINAL CLEARANCES A= Clearance above grade, verandah, porch, deck, or H= *Not to be installed above a meter/regulator assembly balcony [*12 inches (30 cm) minimum] within 3 feet (90 cm) horizontally from the center-line of B= Clearance to window or door that may be opened the regulator [*12 inches (30 cm) minimum] I= Clearance to service regulator vent outlet... -
Page 6: Planning Your Installation
These models have been tested and certified for use with SIMPSON DURAVENT DIRECT VENT TYPE "GS" PIPE FOR GAS STOVES. SECURITY VENTING SYSTEMS (SECURE VENT) Kits are available for vertical venting or horizontal venting. It is recommended that a bead of RTV High Temperature Silicone be applied to each outer vent joint and milpac to each inner joint before installation. -
Page 7: Horizontal Installation
When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. It is important to note when passing through a wall, the maximum allowable wall thickness is 10-inches (254mm), 1 ½ inches clearance to combustibles must be maintained. - Page 8 STEP 7 . Slide the decorative wall thimble up to the wall surface and attach with the screws provided. Apply decorative brass or chrome trim if desired. FIG-14. FIG. 11 FIG. 12 FIG-13 FIG-14 NOTES (1) The four wood screws provided should be replaced with the appropriate fasteners for stucco, brick, concrete, or other types of siding.
- Page 9 VERTICAL INSTALLATION STEP 1. Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters , or other nearby combustible surfaces. Do not pack air spaces with insulation. STEP 2. Set the gas appliance in the desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the ceiling.
- Page 10 NOTES: If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet, to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose. FIG-18 When ever possible, use 45°...
-
Page 11: Cathedral Ceiling Installation
CATHEDRAL CEILING INSTALLATION STEP 1. Follow installation steps 1 and 2 under Vertical Termination. STEP 2. Using the plumb bob, mark the centerline of the venting system on the ceiling and drill a small hole through the ceiling and roof at this point. From the roof, locate the drill hole and mark the outline of the “Cathedral Ceiling Support Box”. STEP 3. - Page 12 Install 2 spring spacers around the flex pipe. Slide the horizontal section of pipe over the flexible liner and install through the wall thimble, ensure that this portion of pipe slides onto the vent termination cap. Slide the inside finished collar over the horizontal section of pipe and secure to wall using the screws provided.
- Page 13 VENTING INTO CLASS “A” CHIMNEYS Simpson GS Dura This model is also certified and tested to vent into vent cap CLASS “A” wood. stove chimneys Cap Adapter Place the freestanding direct vent appliance in the desired location. Using Simpson Dura Vent conversion kit #s 931-932- Class “a Chimney 933, depend on the ID diameter of the CLASS “A”...
-
Page 14: Installation Of Log Sets And Embers
INSTALLATION OF LOGSET and EMBERS INSTALLATION OF LOGSET and EMBERS INSTALLING THE GLOWING EMBERS INSTALLING THE GLOWING EMBERS A bag of Rock Wool embers is provided for use on the burner. A bag of Rock Wool embers is provided for use on the burner. CAUTION: Use only the type of ember material supplied with this appliance. -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A) This appliance is equipped with a pilot, which must be lit by •... -
Page 16: Maintenance And Technical
MAINTENANCE AND TECHNICAL To Replace: Periodically check to ensure that your "Direct Vent" • open door fully system is clear. • Lift door vertically so that hinge pins lift out of hinge receivers. Periodically check the pilot and burner. Check to see •... -
Page 17: Trouble Shooting
TROUBLE SHOOTING Problem Possible Cause Solution Spark will not light the pilot after Defective piezo igniter Check connections to igniter repeated pressing of spark igniter -If igniter connections are good but there is no spark-replace igniter Broken spark electrode -Check for broken ceramic insulation replace, electrode if broken Miss-aligned spark electrode -If spark is not arcing from the... -
Page 18: Gas Line Connection
GAS LINE CONNECTION ORIFICE SIZES, PRESSURE AND BTU’S NATURAL GAS PROPANE GAS Main Orifice #42 dms #53 dms Manifold pressure. 3.8” wc (0.95 kPa) 11” wc (2.74 kPa) Min. Manifold pressure. 1.1” wc (0.27 kPa) 2.7” wc (0.67 kPa) Supply Pressure. 7.0”... -
Page 19: Electrical
The ENVIROGAS EG 28.FS.DV. will operate with no external power supply. These models have a Millivolt gas control which uses the pilot flame to generate enough electricity to operate the main burner. The appliance when installed, must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE. -
Page 20: Parts And Accessories
PARTS AND ACCESSORIES Service Parts available from your local Envirogas Dealer Burner Control Assembly Convection Blower Natural Gas Pilot Assembly Light Bulb Holder Propane Pilot Assembly Light Switch (momentary) Door Bolt Fan Controller Relief Door Gasket Log Set (with Embers) Regulating Valve Thermocouple Piezo Igniter... -
Page 21: Fuel Conversion
ADJUSTING THE VENTURI • Remove the ash shelf by undoing the screw at each end, pull shelf towards you. • Remove one screw from the cover plate located below the ash shelf. Loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place. -
Page 22: Warranty
WARRANTY Sherwood Industries Ltd. offers a *Lifetime Warranty on this gas product. The lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger. -
Page 23: Parts List
PARTS LIST EC-001 EG28-108 FREESTANDING PEDESTAL 120° F CERAMIC TEMP SENSOR EC-002 220° F CERAMIC SPILL SWITCH EG28-109 FS PEDESTAL DOOR EC-006 SIT NOVA 820 NG VALVE 50% EG28-116 BURNER TRAY TOP EC-007 SIT NOVA 820 LP VALVE 50% EG28-120 FS DV OWNERS MANUAL EC-009 THERMOCOUPLE (POST 10/00) -
Page 24: Exploded Views
BV 4” FS BV CRIMPED STOVE TOP 120 ° F (49° C) FLUE PIPE EG28124 CERAMIC FAN EG28-169 TEMP SENSOR DV 4” EC-001 FS DV FLARED BV TOP STOVE TOP FLUE PIPE BAFFLE EG28-126 EG28-170 EG28-132 CONVECTION DV TOP BLOWER BAFFLE EC-030 EG28-131... - Page 25 FULLY ASSEMBLED PAN BURNER TOP PILOT EC-015 NG , 016 LP BURNER CONTROL ASSEMBLY PAINTED DOOR ASSEMBLY THERMOPILE COMPLETE WITH GLASS (A+B) EC-012 EG28-143 NG EG28-099 EG28-145 LPG THERMOCOUPLE GOLD DOOR ASSEMBLY EC-009 WITH GLASS (A+B) EG28-101 VENTURI PILOT ORIFICE TUBE EC-019 NG, 020 LP SPARK ELECTRODE...
-
Page 26: Installation Data Sheet
INSTALLATION DATA SHEET The installer for warranty purposes and future reference must record the following information. Please keep this information for your records. Model: EG 28 Direct Vent Name of Owner: Name of Dealer: __________________________________________ ___________________________________________ Address: Address: __________________________________________ ___________________________________________...
