- Page 1 Wrist Digital Blood Pressure Monitor Model UB-511 Instruction Manual Original Manuel d’instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione 使用手冊 1WMPD4000888C 翻譯...
-
Page 2: Table Of Contents
Contents Dear Customers..............................2 Preliminary Remarks ............................2 Precautions.................................2 Contraindications ............................3 Parts Identification ..............................4 Symbols ................................5 Using the Monitor..............................6 1. Installing / Changing the Batteries......................6 2. Fastening the Cuff ............................ 7 3. How to Take Proper Measurements......................8 4. Measurement ............................8 5. -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time. Preliminary Remarks This device conforms to the European Directive 93/42 EEC for Medical Products. -
Page 4: Contraindications
Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of according to the applicable local regulations. When reusing the device, confirm that the device is clean. Do not modify the device. It may cause accidents or damage to the device. To measure blood pressure, the wrist must be squeezed by the cuff hard enough to temporarily stop blood flow through the artery. -
Page 5: Parts Identification
Parts Identification Display Systolic pressure Battery holder Carrying case Diastolic pressure cover Pulse rate button START Alkaline batteries Cuff (LR03 or AAA) Part of display MEMORY Systolic pressure Pressure bar indicator Diastolic pressure WHO classification indicator I.H.B indicator Pulse rate (Irregular heartbeat indicator) Heart mark Battery indicator... -
Page 6: Symbols
Symbols Symbols Function / Meaning Recommended Action Standby and on switch Battery installation guide Direct current Serial number Date of manufacture Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. The indicator while measurement is in progress. It blinks Measurement is in progress. -
Page 7: Using The Monitor
Symbols Function / Meaning Recommended Action Diastolic blood pressure in mmHg. Pulse per minute PUL./min EC directive medical device label WEEE label Manufacturer EU-representative Refer to instruction manual/booklet Using the Monitor 1. Installing / Changing the Batteries 1. Slide the battery cover as shown to remove it from the device. -
Page 8: Fastening The Cuff
• Insert the batteries as shown on the cuff. If not, the device will not work. • When (LOW BATTERY mark) appears on the display, replace both batteries with new ones at the same time. Do not mix old and new batteries. It may cause the battery life to be shortened, or the device to malfunction. -
Page 9: How To Take Proper Measurements
3. How to Take Proper Measurements For best accuracy in blood pressure measurement: • Sit comfortably on a chair. Rest your arm on the table. Do not cross your legs. Keep your feet on the floor and straighten your back. •... -
Page 10: Measurements
Measurements Note: The UB-511, once used, will provide an inflation appropriate to the user. 1. Sit comfortably with the cuff at the same level as your heart and relax. 2. Press the button. START The average recorded blood pressures and data number are START displayed briefly. -
Page 11: Notes For Proper Measurement
Measurements Notes For Proper Measurement Sit down in a comfortable position. Place the arm to be used for the measurement on a table or other support so that the center of the cuff will be at the same height as your heart. Relax for about five or ten minutes before taking a measurement. -
Page 12: What Is An Irregular Heartbeat
What Is An Irregular Heartbeat? Model UB-511 blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement. It is important that you be relaxed, remain still and do not talk during measurements. -
Page 13: Who Classification Indicator
WHO Classification Indicator Each six segments of the bar indicator correspond to the WHO blood pressure classification described on the next page. Example WHO Classification Indicator Moderate Mild High Severe hypertension hypertension hypertension normal Moderate hypertension Mild hypertension High normal Normal Optimal The indicator displays a segment, based on the... -
Page 14: Why Measure Blood Pressure At Home
To prevent hypertension or keep it under control: Do not smoke Exercise regularly Reduce salt and fat intake Have regular physical checkups Maintain proper weight Why Measure Blood Pressure At Home? Blood pressure measured at a clinic or doctor's office may cause Reference Material: Journal of Hypertension 1999, Vol 17 No.2 apprehension and can produce an elevated reading, 25 to 30 Grade 3 hypertension (severe) -
Page 15: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Batteries are drained. Replace all batteries with new ones. Nothing appears in the Reinstall the batteries with negative and display, even when the Battery terminals are not in the correct positive terminals matching those indicated on power is turned on. -
Page 16: Maintenance
The device was designed and manufactured for a long service life. However it is generally recommended to have the monitor inspected every 2 years, to ensure proper functioning and accuracy. Please contact either your authorized dealer or A&D for maintenance. Technical Data Type UB-511 Clinical test According to ANSI / AAMI SP-10 1992 Measurement Applied part... - Page 17 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 U.S.A.
