- Page 1 Wrist Digital Blood Pressure Monitor Model UB-533 Instruction Manual Original Manuel d’instructions Traduction Manual de Instrucciones Traducción Manuale di Istruzioni Traduzione 使用手冊 翻譯 1WMPD4003121...
-
Page 2: Table Of Contents
Contents Dear Customers ..............................2 Preliminary Remarks .............................. 2 Precautions ................................2 Parts Identification ..............................4 Symbols .................................. 5 Using the Monitor ..............................8 1. Installing / Changing the Batteries ........................ 8 2. Selecting a User ............................9 3. Adjusting the Built-in Clock Before Use ......................9 4. -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this device will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time. Preliminary Remarks This device conforms to the European Directive 93/42 EEC for Medical Products. - Page 4 Do not modify the device. It may cause accidents or damage to the device. To measure blood pressure, the wrist must be squeezed by the cuff hard enough to temporarily stop blood flow through the artery. This may cause pain, numbness or a temporary red mark to the wrist. This condition will appear especially when measurement is repeated successively.
-
Page 5: Parts Identification
Parts Identification button ( average, memory and change of preset parameters) Display button ( user selection and clock button START Battery cover Carrying case Cuff Alkaline batteries (LR03 or AAA) Display MEMORY Systolic pressure Average Diastolic pressure WHO classification indicator Correct Position Guidance (C.P.G.) indicator Pressure bar indicator Cuff Fitt Error Symbol... -
Page 6: Symbols
Symbols Symbols that are printed on the device case Symbols Function / Meaning Standby and Turn the device on Battery installation guide Direct current Serial number Date of manufacture Type BF: Device and cuff are designed to provide special protection against electrical shocks. EC directive medical device label International protection symbol WEEE label... - Page 7 Symbols that appear on the display Symbols Function / Meaning / Recommended Action The heart mark appears while measurement is in progress. It blinks when the pulse is detected. Remain as still as possible. Irregular Heartbeat (I.H.B.) symbol appears when an irregular heartbeat is detected. It may light when a very slight vibration like shivering or shaking is detected.
- Page 8 Symbols Symbols that appear on the display (continued) Symbols Function / Meaning Recommended Action Previous measurements stored in MEMORY Average data FULL BATTERY The battery power indicator during measurement LOW BATTERY Replace all batteries with new ones when the indicator blinks. The battery is low when it blinks Take another measurement.
-
Page 9: Using The Monitor
Using the Monitor 1. Installing / Changing the Batteries 1. Remove the battery cover. Battery cover 2. Remove the used batteries and insert new batteries into the battery compartment as shown, taking care that the polarities (+ and -) are correct. Use only LR03 or AAA batteries. 3. -
Page 10: Selecting A User
Using the Monitor 2. Selecting a User Turn off 1. Press the button when turning off the device. The indicator is blinking. button 2. Select a user from user and user using the button. User or User Press the button to turn off the device. START button START... -
Page 11: Applying The Cuff
Using the Monitor 4. Applying the Cuff 1. Wrap the cuff around your wrist about 1 cm above your hand as shown in the figure About 1 cm at the right. 2. Fasten the cuff tightly using the Velcro strip. Note: For proper measurements, fasten the cuff tightly and measure on a bare wrist. -
Page 12: The C.p.g. Function Switch
6. The C.P.G. Function Switch From step 6 of page 9 Refer to page 18 for the C.P.G. function that will indicate the proper angle so that the height of the cuff is the same level as your heart. The C.P.G. function button 1. -
Page 13: Measurement
Note: When removing the batteries, preset parameters (of clock, user and my C.P.G.) are reset. Select a user from user and user using the button. 8. Measurement During measurement, it is normal for the cuff to feel very tight. 9. After Measurement While readings are displayed, if you press the button to turn the device off, new readings are stored in START... -
Page 14: Measurements
Measurements Note: The UB-533, once used, will provide an inflation appropriate to the user. 1. Wrap the cuff around your wrist. Sit comfortably with the cuff at the same level as your heart and relax. 2. Press the button. All of the display segments are displayed. -
Page 15: Recalling The Memory Data
Recalling the Memory Data Turn off Note: This device stores the last 60 measurements in memory. button Memory mode 1. Press the button when turning the device off. The average of all measurements and the number of data are displayed. User selection button If no data, “0”... -
Page 16: Deleting Data Stored In Memory
What is an Irregular Heartbeat? The UB-533 blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement. -
Page 17: Ihb
% IHB %IHB is displayed as frequency of IHB detected. IHB can detect not only noises such as physical movement but also an irregular heartbeat.Therefore,we recommend contacting your physician if %IHB level is high. Number of detected IHBs in memory %IHB= x 100 % Total number... -
Page 18: Pressure Bar Indicator
Pressurizing Pressure Bar Indicator The indicator monitors the progress of pressure during measurement. Inflation in progress Measurement in progress WHO Classification Indicator Inflation complete Each six segments of the bar indicator correspond to the WHO Classification Indicator WHO blood pressure classification is described on 20 page. Severe hypertension Moderate hypertension Example... -
Page 19: The C.p.g. Indicator
The C.P.G. Indicator The C.P.G. Indicator C.P.G. indicator The C.P.G. (Correct Position Guidance) indicator is the function to inform a difference between the height (wrist angle) of the blood pressure monitor and your cardiac height in the correct posture (Example: sitting posture, height of table and chair, etc.) during the measurement. -
Page 20: About Blood Pressure
The Indicator During Measurement And Recalling Memory The C.P.G. indicator can be displayed at the beginning of measurement and is included in data stored in the memory. Adjust and keep the angle during measurement. About Blood Pressure What is Blood Pressure? Blood pressure is the force exerted by blood against the walls of the arteries. -
Page 21: Who Blood Pressure Classification
WHO Blood Pressure Classification Standards to assess high blood pressure, without regard to age, have been established by the World Health Organization (WHO), as shown in the chart at the right. Blood Pressure Variations An individual’s blood pressure varies greatly on a daily and seasonal basis. -
Page 22: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Batteries are drained. Replace all batteries with new ones. Nothing appears in the Reinstall the batteries with negative and positive display, even when the Battery terminals are not in the correct terminals matching those indicated in the battery device is turned on. -
Page 23: Technical Data
Technical Data Type UB-533 Measurement method Oscillometric measurement Pressure: 0 – 299 mmHg Measurement range Pulse: 40 – 180 beats / minute Pressure: ±3 mmHg Measurement accuracy Pulse: ±5% Power supply 2 x 1.5V alkaline batteries (LR03 or AAA) Approx. 250 measurements, when AAA alkaline batteries are used, with pressure value Number of measurements of 170 mmHg at room temperature of 23°C. - Page 24 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 U.S.A.
