- Page 1 .HDV / SD CF CARD VIDEO RECORDER. DN-60A Instruction Manual www.datavideo-tek.com...
-
Page 2: Table Of Contents
Contents Warranty..................................5 Standard Warranty ..............................5 Two Year Warranty ............................... 5 Disposal ................................5 Packing List ................................6 Product Overview ................................ 6 Features................................7 Connections & Controls ............................... 8 Front Panel ................................8 ... - Page 3 Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or incorrect information.
-
Page 4: Warnings And Precautions
AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be walked on, rolled over, damaged or otherwise stressed. -
Page 5: Warranty
Certain parts with limited lifetime expectancy such as LCD Panels, DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty expires. -
Page 6: Packing List
Packing List Item No. Description Instruction Manual DN-60A Recorder 12V DC 500mA (2W) Switching Adaptor IEEE1394 6-4pin cable 50CM IEEE1394 6-6pin cable 50CM Product Overview The DN-60 is a small and portable video recorder/player capable of recording to certified removable Compact Flash (CF) cards. It can record up to 4.5 hours* of video depending on the recording format, settings and CF card size. -
Page 7: Features
Features Small, easy to carry and camera mountable Compact Flash recorder Input Video Connections: IEEE-1394 supports DV25, DVC Pro 25, DVC Pro 50 and HDV only Embedded External or Internal Time Code Output Connections: IEEE-1394 in playback can supply DV, DVC Pro and HDV signals to the camera ... -
Page 8: Connections & Controls
Connections & Controls Front Panel LCD Panel – Shows the status and menu options of the DN-60 Menu Navigation Button – Rotate to change menu options on LCD panel and press in to select DC Power input – Connect the 12V DC 500mA (2W) power adaptor here Status LED Power On / Auto / Off switch CF Card Protection Cover –... -
Page 9: Rear Panel
Rear Panel Battery Compartment Cover – Press in gently and slide up to access Camera Mount screw thread – Attach DN-60 camera mount here DV/DVC Pro/HDV i/o Port – Attach 6pin IEEE-1394 cable connector here RS-232 Port – Connect 3.5mm Jack for RS-422 control by computer or RMC-200. -
Page 10: Cf Card Slot
CF Card Slot CF Card Protection Cover – Slide down then lift up carefully to open this cover and get access to the CF card slot and the card eject button. 2. CF Card Eject Button – Press in to eject the fitted CF card. When the slot is empty (no CF card inserted), this button is normally in the depressed position. -
Page 11: Powering On
Auto power ON/OFF position (when camera is on / off) Manual power OFF position The LCD display panel will show “Datavideo DN-60 Loading…” after a few seconds the Home Display will be shown. The DN-60 is now ready for set up or use as a recorder or playback device. -
Page 12: Status Led And Error Messages
DN-60 Status LED and Error Messages The DN-60 has a red status LED just below the Menu Navigation Button. This can be used as a quick way of confirming that the unit is working correctly or is requiring user attention. LED constantly OFF DN-60 is idle or the unit is waiting to be powered on. -
Page 13: Menus
DN-60 Menus Pressing the Navigation Button in will select the menu option or confirm a value. Rotating the Navigation Button in either direction will change the menu option or set a value. If all options have been displayed then the menu display will only scroll options in one direction. Choose EXIT to return to a previous menu level or to return to the initial Home screen. -
Page 14: Setup Mode
Setup Mode Entered from the Main Menu, these options enable various record and playback related modes to be setup. Menu Option Action taken Here Loop Playback Mode can be switched ON or PLAY SET UP OFF. Here settings for File Type, Sync to Tape, Pre-Trigger, RECORD SET UP Time Lapse, Record at Power ON and Record Date can be changed. -
Page 15: Record Setup Options
Record Setup Options Entered from the SETUP Menu, this set of options enable various record related parameters and modes to be setup. Menu Option Action taken Will return you to the SET UP menu. Exit The file options change depending on the Signal Type chosen SET FILE TYPE in System Set Up.DV and DVC signals can be recorded to Microsoft avi, Canopus avi, QuickTime mov or MXF OP1A... -
Page 16: System Set Up
System Set Up Entered from the SET UP Menu, this set of options enable file system, signal and power related parameters and modes to be setup. Menu Option Action taken Exit Will return you to the SET UP menu. Where the recorder is set to operate in one of three modes, SET SIGNAL DV+DVC 60Hz, DV+DVC 50Hz or HDV 50/60Hz. -
Page 17: Save Set Up
Save Set Up Entered from the SET UP Menu, this set of options enable file system, signal and power related parameters and modes to be setup. Menu Option Action taken Will return you to the SET UP menu. Exit The current user settings will be stored for SAVE AS USER #1 later Recall as USER1 The current user settings will be stored for... -
Page 18: General Setup Notes
DN-60 General Setup Notes Before using your DN-60 for the first time, there are a few basic operational settings that must be chosen. These are found under the Setup Mode options (see pages 14 to 17). Choose a file operating system, FAT32 or NTFS Set up the file system type seen on the CF card by the computer when transferring files. -
Page 19: Format The Cf Card
Format the CF card The DN-60 is primarily a capture device, as opposed to an archiving device, and it is best to start out with freshly DN-60 formatted CF card(s) on each project. Formatting your card in another device may cause issues later on. If you are re-using your CF cards just remember to backup any existing content already on the card(s) to computer first before formatting the card(s). -
Page 20: Pausing The Record Process
NOTE: The IEEE-1394 output signal on the camera/source device must match the DN-60 input Signal Type for the recording to start. If the DN-60 or source device do not match then the DN- 60 will stay at 00:00:00:00 as it cannot automatically recognise the signal presented. Pausing the Record Process The DN-60 will automatically pause recording if time code from the tape deck is not moving and Sync to Tape is ON. -
Page 21: Using Pre-Trigger Set Up
select the RECORD option. Press in the Menu Navigation Button and if the connected camera is live then the recording will start. Ensure the Camera is supplying the DN-60 with DV25, DVCPro25 or DVCPro50. The DN-60 display will change from 00:00:00:00 to show the current amount of video hours, minutes, seconds and frames captured after each interval point is reached. -
Page 22: Before Transferring Cf Card To A Computer
Before transferring CF card to a computer Prior to using the DN-60 CF card with a computer and seeing your video as files instead of clips the MAKE MEDIA FILES menu process under TOOLS mode must be undertaken otherwise the computer may see a blank card. -
Page 23: Qualified Dn-60 Cf Cards And Record Times
Not all CF cards on general sale are optimised for video applications. Certain cards may look to be compatible but may provide un-reliable results when reading or writing DN-60 video data. Datavideo have tested and recommend using only CF media that has been qualified for use with this product. -
Page 24: Updating Dn-60 Firmware
Updating DN-60 Firmware From time to time Datavideo may release new firmware to either add new features or to fix reported bugs in the current DN-60 firmware. Customers can update the DN-60 firmware themselves if they wish or they can contact their local dealer or reseller for assistance should they prefer this method. -
Page 25: Rs-232 Controller Command Set
DN-60 RS-232 Controller Command Set Rev 3.1 July 29, 2006 Communication Format: Mode: No synchronization Character Length: 1 start bit + 8 data bits + 1 parity bit + 1 stop bit Data Rate: 38,400 Baud Parity: Command Format: CMD1, CMD2, Data bytes …., Checksum byte A Command is made up of two address bytes, CMD1 and CMD2, a variable number of Data bytes (Data from 0 up to 15) and a Checksum byte. -
Page 26: Connector Pin Assignment
20h, 24h, 44h Frame Step 10h, 01h, 11h Reverse 21h, 11h, nnh, csum Jog Forward 10h, 01h, 11h 21h, 12h, nnh, csum Variable Forward 10h, 01h, 11h 21h, 13h, nnh, csum Shuttle Forward 10h, 01h, 11h 21h, 21h, nnh, csum Jog Reverse 10h, 01h, 11h 21h, 22h, nnh, csum... -
Page 27: Sense Request
02h, F5h, 08h, 01h, 0h Enable Loop Play When this command is issued from the Idle state the Loop Play feature is enabled. Loop Play is where the the last play command is repeated from its beginning when the end is reached. 01h, F0h, XXh Select Bin XX When this command is issued from the Idle state bin XX is selected. -
Page 28: Transport Control
25h, F5h, bb, nn Select Bin and Play to Offset Content of the bin number bb is played at 1x speed starting at Frame Offset 0 to Frame Offset nn then pause. Frame Offset nn is 4 bytes and starts with the LSB. This command may be issued from the idle state or any other Play state. - Page 29 Command Name Response Name 01h, F3h, XXh, csum Select and Empty Bin 10h, 01h, 11h Transport Control 20h, 00h, 20h Stop 10h, 01h, 11h 20h, 01h, 21h Play 10h, 01h, 11h 20h, 02h, 22h Record 10h, 01h, 11h 20h, 0Dh, 2Dh Eject 10h, 01h, 11h 20h, 10h, 30h...
-
Page 30: User Notes
User Notes... -
Page 31: Specifications
Specifications Digital Video In/Out IEEE-1394, 400Mbps max, 6-pin Recording and Playback Formats Digital Input and Output: DV25, DVC Pro25, DVC Pro50, HDV Recording time (minutes per 10GB) DV25: 46.3 HDV: 49.4 at 1080i, 64.3 at 720p Media File Format DV25: *.avi (Type II, Microsoft, Canopus), *.mov, *.mxf (OP1A) HDV:... -
Page 32: Service And Support
It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
