HEAVY DUTY BELT SANDER
MODEL NO: CAT70
PART NO: 3110750
OPERATING & MAINTENANCE
INSTRUCTIONS
GC0414

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAT70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke CAT70

  • Page 1 HEAVY DUTY BELT SANDER MODEL NO: CAT70 PART NO: 3110750 OPERATING & MAINTENANCE INSTRUCTIONS GC0414...
  • Page 2 INTRODUCTION Thank you for purchasing this CLARKE Air Sander. The CAT70 Sander is ideal for use in garages and workshops. The narrow belt and adjustable handle allow access in awkward places. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way.
  • Page 4: Sander-Specific Safety Rules

    • Moving to another work area. • Passing the tool to another person. 13. Never use the tool if it is defective or operating abnormally. 14. This tool should be serviced at regular intervals by qualified personnel. 15. Avoid damaging the tool by applying excessive force of any kind. 16.
  • Page 5 Your sander has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 6: Compressed Air Requirements

    • A typical air line layout is shown above. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil. clarke airline oil should be used, and the lubricator adjusted to approx 2 drops per minute.
  • Page 7: Before Use

    ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR COMPRESSORS AND COMPRESSED AIR SUPPLY. 1. Pour 2-3 drops of CLARKE airline oil into the air inlet. This should be done regardless of whether or not a lubricated air supply is to be used.
  • Page 8 INSTALLING THE BELT 1. To replace sanding belt, push the idler pulley assembly (Item 2) towards the handle until it clicks into the secured position. Replace the belt and press the tension bar (item 14), to re-tension the belt (see Fig 1 2.
  • Page 9: Disconnecting The Air Supply

    1. Before use, drain water from the airline filter and compressor. 2. Pour a few drops of Clarke air-line oil, into the tool air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in- line mini oiler is not used, this procedure should be repeated after every two to three hours of use.
  • Page 10: Abrasive Belts

    If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts.
  • Page 11: Troubleshooting

    TROUBLESHOOTING SYMPTOM PROBLEM SOLUTION Tool runs at normal 1. Motor parts worn. 1. Return to Clarke dealer speed but slows down for repair. under any load. 2. Worn or sticking 2. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant.
  • Page 12: Parts List

    PARTS LIST Description No Description Idle Pulley Arm Assy End Plate B Idle Pulley Assy Spacer 10 x 13 x 3 Socket Head Bolt 5x28 Sunk Key 2x2.5x 10 Washer Circlip Bearing 626ZZ Spring End Plate A Finger Pad Assy Cylinder Key Bolt Assy Blade Set...
  • Page 13: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 14: Specification

    20 mm x 520 mm Please note that the details and specifications contained herein are correct at the time of going to print. However Clarke International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
