- Page 1 HIGH SPEED SANDER MODEL NO: CAT25B PART NO: 3110404 OPERATING & MAINTENANCE INSTRUCTIONS GC0315...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Sander. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. -
Page 4: Sander-Specific Safety Rules
• The tool will be left unattended. • Moving to another work area. • Passing the tool to another person. 14. Never use the tool if it is defective or operating abnormally. 15. The tool should be serviced at regular intervals by qualified service personnel. -
Page 5: Compressed Air Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source. • Air compressors used with the tool must comply with the appropriate European Community Safety Directives. -
Page 6: Before Use
BEFORE USE When opening the carton for the first time, check against the following list that all the items are present. Any damage or deficiency should be reported to your CLARKE dealer immediately. NO DESCRIPTION NO DESCRIPTION Disc Retaining Flange Nut... -
Page 7: Connecting The Air Supply
REPLACEMENT DISCS NOTE: Common sanding discs with 22 mm bore are used and are available from a Clarke dealer. NOTE: IMPORTANT: Only use abrasive sanding pads designed for use with this type of sanding pad. CONNECTING THE AIR SUPPLY NOTE: Ensure the compressor is turned off. -
Page 8: Disconnecting The Air Supply
1. Before use, drain water from the air tank, air line and compressor. 2. Pour a few drops of CLARKE airline oil, into the air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in- line mini oiler is not used, this procedure should be repeated after every two to three hours of use. -
Page 9: Troubleshooting
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. When not in use, disconnect from air supply, clean tool and store in a safe, dry place. -
Page 10: Component Parts
COMPONENT PARTS No Description No Description Body Rear End Plate Control Pin Cylinder Rubber Gasket Vanes Ball Rotor Spring Bushing-Front End Hose Joint Front End Plate Rubber Gasket Spacer O-Ring Bearing Regulator Cylinder Housing Trigger Sanding Adaptor Holding Tool Lock Down Adaptor Housing Lock Ring Backing Plate - 4”... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
