Summary of Contents for Clarke CAT121
- Page 1 DUAL ACTION SANDER MODEL NO: CAT121 PART NO: 3110877 OPERATION & MAINTENANCE INSTRUCTIONS LS0211...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................. 2 GUARANTEE ................2 ENVIRONMENTAL PROTECTION ..........2 CONTENTS ................. 2 TABLE OF CONTENTS ..............3 GENERAL SAFETY RULES ............4 AIR SUPPLY ................. 6 Recommended Air Supply Connection ............6 THE DUAL ACTION SANDER ............7 Before Use ...................... -
Page 4: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 5 • The tool will be left unattended. • Moving to another work area. • Passing the tool to another person. 12. Never use the tool if it is defective or operating abnormally. 13. The tool should be serviced at regular intervals by qualified service personnel.
-
Page 6: Air Supply
AIR SUPPLY WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source for the tool. •... -
Page 7: The Dual Action Sander
THE DUAL ACTION SANDER DESCRIPTION PART NUBER NO DESCRIPTION PART NUBER Trigger RONCAT12101 Locking Nut RONCAT12104 Speed Control RONCAT12102 Backing Pad RONCAT12105 Balancer RONCAT12103 1/4” BSP (Female RONCAT12106 Air Inlet) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 8: Before Use
1. Remove the travel plug from the air inlet at the bottom of the tool. 2. Pour 2-3 drops of CLARKE airline oil into the air inlet. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 9: Adjusting The Speed
2. Release pressure from the trigger to stop the sander. 3. Always ensure the sander has stopped before putting it down on any surface after use. NOTE: Replacement sanding sheets are available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: After Use
• If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 11: Maintenance
• Drain water from air tank, air line and compressor. • Pour a few drops of CLARKE Air Line Oil, into the air inlet. This should be carried out regardless of whether or not an inline mini oiler is used. -
Page 12: Specifications
1.81 Kg Please note that the details and specifications contained herein, are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate... -
Page 13: Vibration Emissions
VIBRATION EMISSIONS Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 hertz is potentially damaging and is most hazardous in the range from about 5 to 20 hertz. - Page 14 Some tools with a high vibration value, such as impact wrenches, are generally used for a few seconds at a time, therefore the cumulative time may only be in the order of a few minutes per day. Nevertheless, the cumulative effect, particularly when added to that of other hand held power tools that may be used, must always be taken into account when the total daily dose rate is determined.
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
