3" ANGLE POLISHER
MODEL NO: CAT220
PART NO: 3110474
OPERATING & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC 0422

Advertisement

Table of Contents
loading

Summary of Contents for Clarke CAT220 3110474

  • Page 1 3” ANGLE POLISHER MODEL NO: CAT220 PART NO: 3110474 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC 0422...
  • Page 2: Specification

    1.5 m/s Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - DO NOT wear loose clothing or jewellery. Tie long hair out of the way.
  • Page 4: Transportation And Storage

    10. NEVER use the tool if it is defective or operating abnormally. 11. ALWAYS disconnect from the air supply when: • Performing any maintenance. • The tool is not in use. • The tool will be left unattended. • Moving to another work area. •...
  • Page 5 OVERVIEW NO DESCRIPTION NO DESCRIPTION Spindle access port Spindle Locking pin Trigger Foam applicator pads (coarse/fine) Speed Regulator Backing disc Air Inlet (with travel plug) Wool buffing mop Air exhaust Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 6: Compressed Air Requirements

    COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR COMPRESSORS AND COMPRESSED AIR SUPPLIES. • A typical air line layout is shown below. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil.
  • Page 7: Before Use

    • The air hose must be rated at least 150% of the maximum operating pressure of the tool • Use only clean, dry, regulated compressed air as a power source. • Air compressors used with the tool must comply with the appropriate European Community Safety Directives.
  • Page 8: Operation

    You can fit a whip hose with a quick fit coupling if required (available from your CLARKE dealer). FITTING THE BACKING DISC Insert the spindle locking pin through the aperture provided and into the hole in the drive spindle to stop the spindle from rotating.
  • Page 9 USING THE POLISHER IMPORTANT: Do not add too much wax to the applicator pad, as it will increase the time and effort needed to complete the task. A saturated pad may also separate from the disc pad during use. 1. Clean the workpiece's surface to remove dust, dirt, oil or grease. 2.
  • Page 10: Disconnecting The Air Supply

    1. Before use, drain water from the air tank, air line and compressor. 2. Pour a few drops of CLARKE airline oil into the air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in-line mini oiler is not used, this procedure should be repeated after every two to three hours of use.
  • Page 11: Service And Repair

    If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of CLARKE airline oil into the air inlet and run the tool for 5 seconds in order to lubricate the internal parts.
  • Page 12: Troubleshooting

    2. Motor parts worn. 2. Return to your CLARKE dealer for repair. 3. Worn or sticking 3. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant.
  • Page 13: Declarations Of Conformity

    DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 14: Parts List

    PARTS LIST Description No Description Main housing Eccentric wheel Bush Screw Valve pin Grub screw Spring Drive spindle O-ring Bearing Screw cap Circlip Trigger pin Backing disc Trigger O-ring Bearing Muffler stand Front plate O-ring Cylinder Muffler liner Muffler Rotor Grub screw Rotor blade Air regulator...
  • Page 15: Parts Diagram

    PARTS DIAGRAM GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
