- Page 1 HD DUAL-ACTION SANDER Model Nos: CAT24B & CAT93 Part No: 3110403 & 3110849 OPERATION & MAINTENANCE INSTRUCTIONS GC11/12...
-
Page 2: Introduction
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................. 2 GUARANTEE ................2 ENVIRONMENTAL PROTECTION ..........2 TABLE OF CONTENTS ..............3 SAFETY PRECAUTIONS ..............4 OVERVIEW .................. 6 AIR SUPPLY REQUIREMENTS............7 ASSEMBLY ................... 8 OPERATION..................9 TROUBLESHOOTING..............10 MAINTENANCE ................11 PARTS LIST & DIAGRAM...............12 SPECIFICATIONS .............. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND /OR DAMAGE TO PROPERTY WORK ENVIRONMENT • Keep the work area clean and tidy. • Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 5 Moving to another work area. • Never use the tool if it is defective or operating abnormally. • The tool should be serviced as required by your CLARKE dealer. • Avoid damaging the tool for example by applying excessive force.
-
Page 6: Overview
AIR INLET LOCKING NUT REGULATOR VALVE The CAT24B and CAT 93 Sanders are ideal for use in garages and workshops. Random orbit sanders give a virtually scratch - free finish on various surfaces prior to painting or varnishing the finished surface. -
Page 7: Air Supply Requirements
AIR SUPPLY REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE THOROUGHLY FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source. •... -
Page 8: Assembly
1. Remove the plastic blanking plug from the connection port of the tool. 2. Pour 2-3 drops of CLARKE airline oil into the air inlet. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 9: Operation
4. Connect the other end of the hose to the compressor. (A whip hose with a quick fit coupling is available from your CLARKE dealer). 5. Turn on the air supply and check for air leaks. Rectify any found before proceeding. -
Page 10: Troubleshooting
3. If the tool is not to be used for longer than 24 hours, run a few drops of CLARKE airline oil into the air inlet and run the tool for a few seconds to ensure that the oil has been well distributed throughout the tool. -
Page 11: Maintenance
**Clarke Airline Oil is available from your CLARKE dealer: part no 3050825. Parts & Service: 020 8988 7400/E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 12: Parts List & Diagram
PARTS LIST n i i n i l Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Parts Diagram
Part no. 6502102 ACCESSORIES A wide range of accessories are available including filter/regulators, lubricators, high pressure hoses, etc. Contact your CLARKE dealer for further information, or call CLARKE International on 01992 565333. Parts & Service: 020 8988 7400/E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Specifications
SPECIFICATIONS l n I " 4 i n i " 6 " 6 Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400/E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
