INSTALLATION GUIDE
HB0075
CHIMNEY RANGE HOOD
MODEL VJ70430SS
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGE 10.
Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville QC J2C 7W9
1-800-567-3855
REGISTER YOUR PRODUCT ON LINE AT: www.bnv.ca
For additional information - visit www.venmar.ca
08383 rev. 04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jazz VJ70430SS and is the answer not in the manual?

Questions and answers

Related Manuals for Venmar Jazz VJ70430SS

Summary of Contents for Venmar Jazz VJ70430SS

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGE 10. Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville QC J2C 7W9 1-800-567-3855 REGISTER YOUR PRODUCT ON LINE AT: www.bnv.ca For additional information - visit www.venmar.ca...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR TO REDUCE THE RISK OF INJURY TO PERSON(S) IN INJURY TO PERSON(S) OBSERVE THE FOLLOWING: THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*: 1.

  • Page 3: Prepare The Installation

    1. MEASURE THE INSTALLATION AND INSTALL DUCTWORK WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. WARNING To reduce the risk of fire, use only metal ductwork. ROOF CAP 6” ROUND DUCT The minimum hood distance above cooktop must not be less than 24”.

  • Page 4: Wiring Installation

    3. WIRING INSTALLATION WARNING Electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards. This range hood must be properly grounded. Turn off electrical power at service entrance before wiring. GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.

  • Page 5: Install Hood Mounting Bracket

    4. INSTALL HOOD MOUNTING BRACKET WARNING Make sure power is switched off at service panel before starting installation. WARNING When cutting or drilling into wall, do not damage electrical wiring and other hidden utilities. TUDS URFACE Install a wood wall framing between 2 wall studs over the installation location. This framing will support hood mounting bracket.

  • Page 6: Install The Hood

    6. PREPARE THE DECORATIVE FLUE WARNING Be careful when handling the lower and upper flues; they may have sharp edges. PPER Remove the protective plastic film on both lower and upper flues. Carefully slide the upper RACKET SLOTS UP flue inside the lower flue, leaving about 2” of the upper flue over the lower flue. Attach the 2”...
  • Page 7 7. INSTALL THE HOOD (CONT’D) OWER FLUE MOUNTING BRACKET 4. Align the hood and center it above the hood mounting bracket. Gently lower the hood until it is hung to the bracket. Using 2 no. 8 x 1¼” screws, secure the lower flue mounting bracket to the wall.

  • Page 8: Reinstall Grease Filter

    7. INSTALL THE HOOD (CONT’D) PPER FLUE MOUNTING BRACKET 6. Slide up the upper flue until it is aligned with its mounting bracket. The bracket should be PPER FLUE inside the flue. Secure the upper flue on the upper flue mounting bracket using 2 no. 8 x 5/16” mounting screws.

  • Page 9: Light Bulbs

    9. LIGHT BULBS WARNING Make sure power is switched off at service panel before carrying out any operation on the hood. This range hood requires two UL approved halogen bulbs (JC type, 12 V, 20 W). WARNING In order to prevent the risk of personal injury, the halogen lamps must be cooled down before removing them. To replace bulbs: 1.

  • Page 10: Operation

    10.OPERATION The hood is operated using the push button located at the bottom of FAN CONTROLS LIGHTS the grease filter. The light switch turns the lamps on and off. The blower switch turns the blower on to three speed settings: MED.

  • Page 11: Replacement Parts

    Any third party replacement part used may cause serious damage and drastically reduce the performance level of your unit, which will result in premature failing. Venmar Ventilation Inc. also recommends to contact a Venmar certified service depot for all replacement parts and repairs.

  • Page 12: Warranty

    To contact Venmar Ventilation Inc. Warranty Service call 1-800-567-3855 (in Canada). In order to qualify for a warranty claim, the owner of a Venmar Jazz range hood must have the model and serial number along with a proof of the original purchase date. At the time of requesting service, describe the nature of any defect in the product or part.
