USER Sets the print area of the image.
L Sets the print area of the left side.
R Sets the print area of the right side.
T Sets the print area of the top side.
B Sets the print area of the bottom side.
Multi Maximum print size Setting at factory shipping
(mm approx.)
1L 93.5x124.7
1 99.8x74.8
2 51.0x74.8 (S)
51.0x65.0 (L)
4, 4D 49.9x37.4
6 32.8x37.4
16 24.9x18.7
2 2 2 2 2
Multiple prints with L size ink sheet
If you print multiple images with L size ink sheet, the images
are printed as follows.
1 1-image (75x100mm)
4,4D 6-image (36.5x48mm)
16 24-image (19x25mm)
1
4D
S.MENU (Sub.MENU)
See the next page for details.
YES All settings in MENU are reset to the settings made by
the installer.
NO Reset is not performed.
T B L R
0 0 0 0
0 0 0 0
4 8 0 0
8 16 6 6
10 20 18 18
0 0 0 0
2 4-image (50.8x74mm)
6 9-image (30x35mm)
2
6
RESET
Print size Resolution
(mm approx.) (pixels)
93.5x124.7 1600x1200
99.8x74.8 1280x960
51.0x73.9 654x948
48.0x36.5 616x468
29.9x35.0 384x450
24.9x18.7 320x240
4
16
S u b . M E N U
S L E E P
O P S K I P
M A R G I N
D P S
< B A C K
R E S E T
Y E S
N O
< B A C K
