Options Guide - English
PRIMERGY BX400 S1
System Unit
Options Guide
December 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIMERGY BX400 S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu PRIMERGY BX400 S1

Summary of Contents for Fujitsu PRIMERGY BX400 S1

  • Page 1 Options Guide - English PRIMERGY BX400 S1 System Unit Options Guide December 2010...

  • Page 2: Copyright And Trademarks

    – The contents of this manual may be revised without prior notice. – Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. – No part of this manual may be reproduced in any form without the prior written permission of Fujitsu.
  • Page 3 Before reading this manual For your safety This manual contains important information for safely and correctly using this product. Carefully read the manual before using this product. Pay particular attention to the accompanying manual "Safety Notes and Regulations" and ensure these safety notes are understood before using the product.
  • Page 4 (hereafter, "high safety use"). Customers should not use this product for high safety use unless measures are in place for ensuring the level of safety demanded of such use. Please consult the sales staff of Fujitsu if intending to use this product for high safety use.

  • Page 5: Table Of Contents

    Contents Introduction ......7 Concept and target groups ....7 Documentation overview .
  • Page 6 Contents Rack model ......58 Index ........59 Options Guide BX400 S1...

  • Page 7: Introduction

    The installation and removal of the hot-plug components is described in the Operating Manual supplied with the system unit. Documentation overview More information on your PRIMERGY BX400 S1 system unit can be found in the following documents: – "Quick Start Hardware - PRIMERGY BX400 S1" leaflet "...
  • Page 8 Internet. The overview page showing the online documentation available on the Internet can be found using the URL (for EMEA market): http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can be accessed using the Industry standard servers navigation option. For the Japanese market please use the URL: http://primeserver.fujitsu.com/primergy/manual.html.

  • Page 9: Expansions And Upgrades

    Introduction Expansions and upgrades Accessible drive One bay is available for an optical disk drive (ODD) (DVD or Blue-ray). It is located on the upper front bezel (rack model) or on the Front-Side I/O Module (FSIOM) (floorstand model). ServerView Local Service Display for Blade You can install a ServerView Local Service Display for Blade instead of a front control panel for local administration and easier identification of defective components (rack model).
  • Page 10 Introduction Options Guide BX400 S1...

  • Page 11: Procedure

    (see the Operating Manual of the server blade). For the latest information on optional products provided for the BX400 S1 system unit see the configurator of the system unit: https://globalsp.ts.fujitsu.com/dmsp/docs/cnfgbx400s1.pdf (for the EMEA market) http://primeserver.fujitsu.com/primergy/system.html (for the Japanese market)
  • Page 12 Procedure Options Guide BX400 S1...

  • Page 13: Safety Instructions

    Safety instructions The following safety instructions are also provided in the manual "Safety Notes and Regulations" or " 安全上のご注意 ". This device meets the relevant safety regulations for IT equipment. If you have any questions about whether you can install the server in the intended environment, please contact your sales outlet or our customer service team.
  • Page 14 Safety instructions Before starting up CAUTION! During installation and before operating the device, observe the instructions on environmental conditions for your device. If the device is brought in from a cold environment, condensation may form both inside and on the outside of the device. Wait until the device has acclimatized to room temperature and is absolutely dry before starting it up.
  • Page 15 Safety instructions CAUTION! Ensure that the power sockets on the device and the properly grounded power outlets are freely accessible. The On/Off button or the main power switch (if present) does not isolate the device from the mains power supply. To disconnect it completely from the mains power supply, unplug all network power plugs from the properly grounded power outlets.
  • Page 16 Safety instructions CAUTION! Proper operation of the system (in accordance with IEC 60950-1/2 resp. EN 60950-1/2) is only ensured if the casing is completely assembled and the rear covers for the installation slots have been fitted (electric shock, cooling, fire protection, interference suppression).
  • Page 17 Safety instructions CAUTION! Install the screw removed during installation/detaching Internal Options in former device/position. To use a screw of the different kind causes a breakdown of equipment. The installation indicated on this note is sometimes changed to the kind of possible options without notice. Options Guide BX400 S1...
  • Page 18 Safety instructions Working with CDs/DVDs/BDs and optical drives When working with devices with optical drives, these instructions must be followed. CAUTION! Only use CDs/DVDs/BDs that are in perfect condition, in order to prevent data loss, equipment damage and injury. Check each CD/DVD/BD for damage, cracks, breakages etc. before inserting it in the drive.
  • Page 19 Safety instructions Do not contaminate the CD/DVD/BD surface with fingerprints, oil, dust, etc. If dirty, clean with a soft, dry cloth, wiping from the center to the edge. Do not use benzene, thinners, water, record sprays, antistatic agents, or silicone-impregnated cloth. Be careful not to damage the CD/DVD/BD surface.
  • Page 20 Safety instructions Modules with Electrostatic-Sensitive Devices Modules with electrostatic-sensitive devices are identified by the following sticker: Figure 1: ESD label When you handle components fitted with ESDs, you must always observe the following points: Switch off the system and remove the power plugs from the power outlets before installing or removing components with ESDs.

  • Page 21: Preparation

    Preparation CAUTION! Follow the safety instructions in the chapter "Safety instructions" on page Floorstand model 4.1.1 Opening the system unit Ê Terminate all applications and shut down the system unit correctly. Ê If your operating system has not switched off the server, press the On/Off button.

  • Page 22: Rack Model

    Preparation Rack model Ê Terminate all applications and shut down the system unit correctly. Ê If your operating system has not switched off the server, press the On/Off button. Ê Pull all power cables out of the power outlet. Options Guide BX400 S1...

  • Page 23: Optical Disk Drive (Odd)

    Optical Disk Drive (ODD) CAUTION! When installing the ODD, hold it by the side. Applying force to the top may cause failures. Follow the safety instructions in the chapter "Safety instructions" on page Figure 3: Preparing the ODD Ê Fasten the engaging hook on the ODD. Options Guide BX400 S1...

  • Page 24: Rack Model

    Optical Disk Drive (ODD) Rack model The ODD mounting bay is located on the upper front bezel of the system unit. Ê Empty the sever blade slots 7 and 8. See the Operating Manual for how to remove server blades, storage blades and server blade dummy modules. Figure 4: Removing the ODD dummy module Ê...
  • Page 25 Optical Disk Drive (ODD) Figure 5: Inserting the ODD Ê Push the ODD in the bay of the system unit until it engages. Ê Reinstall server blades, storage blades or server blade dummy modules in slots 7 and 8, see the Operating Manual. Ê...

  • Page 26: Floorstand Model

    Optical Disk Drive (ODD) Floorstand model The ODD mounting bay is located on the FSIOM. Ê Empty the sever blade slots 7 and 8. See the Operating Manual for how to remove server blades, storage blades and server blade dummy modules. Figure 6: Disengaging the FSIOM Ê...
  • Page 27 Optical Disk Drive (ODD) Figure 7: Removing the FSIOM Ê Disconnect the door sensor cable (small circle) and the LCD cable (large circle) from the FSIOM. Ê Unlock the FSIOM (1) and pull it out of the system unit completely (2). Figure 8: Removing the ODD dummy module from the FSIOM Ê...
  • Page 28 Optical Disk Drive (ODD) Figure 9: Inserting the ODD in the FSIOM Ê Push the ODD into the bay of the FSIOM until the engaging hook (1) under the metal holder (2) locks in place. Figure 10: Connecting the SATA cable to the ODD Ê...
  • Page 29 Optical Disk Drive (ODD) Figure 11: Connecting the door sensor cable and the LCD cable to the FSIOM Ê Push the FSIOM into the system unit until the security lock engages. Ê Connect the door sensor cable (small circle) and the LCD cable (large circle) to the FSIOM.
  • Page 30 Optical Disk Drive (ODD) Options Guide BX400 S1...

  • Page 31: Serverview Local Service Display For Blade

    ServerView Local Service Display for Blade CAUTION! Follow the safety instructions in the chapter "Safety instructions" on page Figure 12: Front control panel The ServerView Local Service Display for Blade is an option in the rack model of the BX400 S1 system unit. The ServerView Local Service Display for Blade is placed in the FSIOM instead of the front control panel.
  • Page 32 ServerView Local Service Display for Blade Figure 13: Disengaging the FSIOM Ê Disengage the lock of the FSIOM (1) and pull it out of the system unit up to the stop (2). If the FSIOM is hard to unlock, press it at the top front as you release Options Guide BX400 S1...
  • Page 33 ServerView Local Service Display for Blade Figure 14: Removing the FSIOM Ê Unplug the SATA cable (1). Ê Unlock the FSIOM (2) and pull it out of the system unit completely. Figure 15: Removing the front control panel carrier from the FSIOM Ê...
  • Page 34 ServerView Local Service Display for Blade Figure 16: Removing the front control panel from the carrier Ê Remove the stopper from the carrier. To do this, loosen the screw (1) and push the stopper (2) out. Ê Remove the front control panel from the carrier (3). Figure 17: Inserting the ServerView Local Service Display for Blade into the carrier Ê...
  • Page 35 ServerView Local Service Display for Blade Figure 18: Inserting the carrier into the FSIOM Ê Push the carrier all the way to the stop into the FSIOM (1). In this position the lock engages (2). Ê Disengage the locking mechanism of the ServerView Local Service Display for Blade (3) and slide it completely into the FSIOM.
  • Page 36 ServerView Local Service Display for Blade Figure 20: Inserting the carrier into the FSIOM Ê Push the FSIOM into the system unit until the security lock engages. Ê Connect the SATA cable (see circle). Ê Disengage the security lock of the FSIOM (1) and push it completely into the system unit (2).

  • Page 37: Conversion From A Rack Model To A Floorstand Model

    Conversion from a rack model to a floorstand model CAUTION! Follow the safety instructions in the chapter "Safety instructions" on page The rack model can be optionally converted to floorstand model using a conversion kit. Ê Make a note of the positions of the individual server blades and storage blades, the connection blades, power supply units, fan units and management blades in the system unit for reinstallation.
  • Page 38 Conversion from a rack model to a floorstand model Ê Store the ODD or ODD dummy module in a safe place. You will need it for installing on the FSIOM later on. Removing the handles bars Figure 22: Removing the handle bars Ê...
  • Page 39 Conversion from a rack model to a floorstand model Removing the ID card Figure 23: Pulling the ID card up to the stop Ê Pull the ID card out of the system unit up to the stop. Figure 24: Removing the ID card Ê...
  • Page 40 Conversion from a rack model to a floorstand model Removing the FSIOM Figure 25: Disengaging the FSIOM Ê Disengage the lock of the FSIOM (1) and pull it out of the system unit up to the stop (2) If the FSIOM is hard to unlock, press it at the top front as you release Options Guide BX400 S1...
  • Page 41 Conversion from a rack model to a floorstand model Figure 26: Removing the FSIOM Ê Unplug the SATA cable (1). Ê Unlock the FSIOM (2) and pull it out of the system unit completely. Options Guide BX400 S1...
  • Page 42 Conversion from a rack model to a floorstand model Removing the SATA cable Ê Detach the SATA cable from the cable guides inside the FSIOM bay (see arrows). Figure 27: Removing the SATA cable Options Guide BX400 S1...
  • Page 43 Conversion from a rack model to a floorstand model Figure 28: Opening the cable channel Ê Remove the cover above the cable channel on top of the system unit by loosening the two countersunk screws (see circles). Figure 29: Removing the SATA cable Ê...
  • Page 44 Conversion from a rack model to a floorstand model Removing the front control panel Figure 30: Removing the front control panel from the FSIOM Ê Unplug the LCD cable from the front control panel and from the FSIOM (see circles) and remove the LCD cable by detaching the cable clamp. Ê...
  • Page 45 Conversion from a rack model to a floorstand model Installing the ODD Figure 31: Inserting the ODD in the FSIOM Ê Push the ODD into the bay of the FSIOM until the engaging hook (1) under the metal holder (2) locks in place. Figure 32: Connecting the SATA cable to the FSIOM Ê...
  • Page 46 Conversion from a rack model to a floorstand model Figure 33: Connecting the SATA cable to the ODD Ê Connect the other plug of the SATA cable to the port on the ODD (see circle) and put the cable in the cable clamp (1). Options Guide BX400 S1...
  • Page 47 Ê Turn the system unit through 90° to the right so that the bay of the FSIOM is on the bottom. CAUTION! Get a second person to help you do this. The PRIMERGY BX400 S1 system unit is large and heavy. Figure 34: Removing the rack model sidebars Ê...
  • Page 48 Conversion from a rack model to a floorstand model Figure 35: Attaching the floorstand sidebars Ê Attach the floorstand sidebars with the countersunk screws you obtained with the removal of the sidebars of the rack model. Options Guide BX400 S1...
  • Page 49 Ê Put the system unit through 180° in the upright position. CAUTION! Get a second person to help you do this. The PRIMERGY BX400 S1 system unit is large and heavy. Options Guide...
  • Page 50 Conversion from a rack model to a floorstand model Securing the top cover module Figure 37: Engaging hooks of the top cover module The top cover module is equipped with engaging hooks on both sides (see circles) for the anchoring on the housing of the system unit. Figure 38: Oblong holes in the housing of the system unit In the figure above, the oblong holes in the housing of the system unit for the application of the engaging hooks of the top cover module are indicated by...
  • Page 51 Conversion from a rack model to a floorstand model Figure 39: Fastening the top cover module Ê Push the top cover module backward as far as it will go. Ê Secure the top cover module on both sides with countersunk screws (see circle).
  • Page 52 Conversion from a rack model to a floorstand model Inserting the ID Card Figure 40: Inserting the ID card Ê Insert the ID Card in the slot provided on the ServerView Local Service Display for Blade. Routing cables Figure 41: Routing the cables Ê...
  • Page 53 Conversion from a rack model to a floorstand model Figure 42: Routing the LCD cable Ê Route the cables under the guides as shown in the figure (see arrows). Figure 43: Closing the cable channel Ê Insert the slot cover above the cable channel and secure it with the two countersunk screws you obtained with the removal (see circles).
  • Page 54 Conversion from a rack model to a floorstand model Installing the FSIOM Figure 44: Connecting the door sensor cable and the LCD cable to the FSIOM Ê Push the FSIOM into the system unit until the security lock engages. Ê Connect the door sensor cable (small circle) and the LCD cable (large circle) to the FSIOM.
  • Page 55 Conversion from a rack model to a floorstand model Securing the side covers Figure 45: Side cover fastening arrangements Ê Place the left side cover on the three metal brackets (see arrows) and hook the side cover in the eight t-profile pins (see circles). Options Guide BX400 S1...
  • Page 56 Conversion from a rack model to a floorstand model Figure 46: Fastening the side cover Ê Push the side cover completely backward and secure it with the provided screw (see circle). Ê Secure the right side cover in the same way. Ê...

  • Page 57: Completion

    Completion CAUTION! Follow the safety instructions in the chapter "Safety instructions" on page Floorstand model Figure 47: Inserting the door Ê Insert the hinge hole of the door (1) in the hinge pin (2). Options Guide BX400 S1...
  • Page 58 Completion Figure 48: Positioning the door hinge pin Ê Pull the hinge pin downward (1) and position it in the hinge hole in the cover plate (2). Ê Insert the key. Ê Lock the door. Ê Connect all power plugs to the power outlets. Ê...
