1.1 Introduction

The PCM-9574 is an all-in-one Celeron™/Pentium
board computer (SBC) with an AC 97 Audio interface a 2x AGP LCD
controller, a PCI Fast Ethernet interface and one PCI expansion slot.
With the Intel Celeron
PCM-9574 achieves outstanding performance that surpasses any
other SBC in its class. This compact unit is only 203 x 146 mm
(8" x 5.75"). It offers all the functions of a single board industrial
computer, but still fits in the space of a 5.25" floppy drive.
On-board features include four serial ports (three RS-232, one
RS-232/422/485), one multi-mode parallel (ECP/EPP/SPP) port, two
USB (Universal Serial Bus) ports, one infrared port (SIR), one
CompactFlash socket for CFC, a floppy drive controller, and a
keyboard/PS/2 mouse interface. The built-in high-speed PCI IDE
controller supports PIO, UDMA/33 and bus master modes. Up to two
IDE devices can be connected, including large hard disks,
CD-ROM drives and tape backup drives.
The PCM-9574 features power management to minimize power
consumption. It complies with the "Green Function" standard and
supports doze, standby and suspend modes. In addition, the board's
watchdog timer can automatically reset the system or generate an
interrupt in case the system stops due to a program bug or EMI.
The PCM-9574 has been certified as complying with FCC Class A
and CE Marking Class A.

Highly integrated Socket 370 SBC

The PCM-9574 is a highly integrated SBC that combines AC 97
Audio, PanelLink, and network functions on a single computer board
the size of a 5.25" floppy drive. Major on-board devices adopt PCI
technology to achieve outstanding computing performance when used
with Intel
the world's smallest and most powerful all-in-one Socket 370 board.
2 PCM-9574 User's Manual
TM
processor, the
® TM
Celeron /Pentium
®
III processors, making the PCM-9574
®
III level single
