Konica Minolta bizhub PRO C6500 Specification Sheet

Konica Minolta bizhub PRO C6500 Specification Sheet

Konica minolta bizhub pro specification sheet
Hide thumbs Also See for bizhub PRO C6500:

Advertisement

Specifications
Model Name
bizhub PRO C6500
Type
Console with document feeder (Colour Copier / Printer / Scanner)
Resolution
Scanning
600 x 600dpi
Printing
600 x 600dpi
Memory
DIMM
256MB x 4
HDD
40GB x 4 (option)
Paper sizes
Main Unit
A5 – A3 (140 x 182mm – 330 x 487mm)
Multi-bypass
A6 – A3 (100 x 148mm – 330 x 487mm)
Warm-up Time
420 seconds or less
First-copy Time
Full Colour
6.5 seconds or less
B/W
5.0 seconds or less
Copy Speed
Full Colour
36cpm (A3), 41cpm (B4), 65cpm (A4), 65cpm (B5)
B/W
36cpm (A3), 41cpm (B4), 65cpm (A4), 65cpm (B5)
Magnification
Fixed
Fixed Ratio: 1:1
0.5%; Reduction: 0.500/0.707/0.816/0.866;
Enlargement: 1.154/1.224/1.414/2.00
Zoom
Zoom: 25% to 400% in 0.1% increments, 3 user settings
Paper Capacity (Main Unit)
500 x 3 sheets + 250 sheet multi-bypass
Paper Weights
Main Unit
64 – 209g/m
2
(256g/m
2
for A4 and larger sizes)
Multi-bypass
64 – 300g/m
2
Multiple Copy
Up to 9,999
Power Requirement
240V/15A
Power Consumption
2.8kW (main unit only) or less
Dimensions (W x D x H)
786 x 992 x 1,056mm
Weight
Approx. 360kg (main unit only)
Print Controller (optional)
Model
IC-303
Type
External
CPU
Intel Pentium4 3.2GHz FSB800MHz
Hard Disk
160GB
Memory
Standard
1GB (DIMM 512MB x 2)
Maximum
2GB
Speed
65ppm
Resolution
1,800 equivalent x 600 dpi
Printer Languages
Adobe PostScript3 (3017)
Network Protocol
TCP/IP, AppleTalk, IPX/SPX
Operating System
Windows 2000 (SP2 or later) / XP (SP4 or later), Windows Server 2003,
Mac OS X (10.2.1, 10.2.3, 10.2.4 or later), UNIX (Solaris 8 or later), Linux
Fonts
136 Adobe PostScript fonts, 2 Multiple Master fonts
Interface
Ethernet (10/100/1000BASE-T) x 2
System Options
DF-609
Capacity
100 sheets
B6 – A3 (128 x 139.7mm – 297 x 431.8mm)
Document
Paper Sizes
Feeder
Paper Weights
Single sided: 35 – 210g/
m
2
; double sided: 50 – 210g/
m
2
RU-503/504
Paper Sizes
Postcard, A6, B6, A5, A5S, B5, B5S, A4, A4S, B4, A3, A3 wide, tab
Relay Unit
paper, irregular sizes (100 x 139mm – 331 x 488mm)
Paper Weights
64 – 300g/
m
2
3,000 sheets max. (B6 – A3, irregular sizes); 64 – 256g/
PF-601 Paper
Upper Tray
m
2
Feed Cabinet
Lower Tray
3,000 sheets max. (Postcard – A3, irregular sizes); 64 – 300g/
System Overview
FD-501
FS-503
SD-501
LS-501
Multi-Folding Unit
Staple Finisher
Saddle Stitcher
Large Capacity Stacker
System Options (continued)
HT-503/504
Description
Prevents coated sheets of paper from sticking
Dehumidifying
HT-503
For the LU-202 Large Capacity Unit
Heater
HT-504
For the PF-601 Paper Feed Trays
LS-501 Larger
Capacity
5,000 sheet stacker (main tray), 200 sheet (sub-tray)
Capacity
Paper Sizes
Straight / shift mode: A5, B5, A4, A4S, B4, A3, A3 wide, irregular sizes
Stacker
Sub-tray mode: Postcard, B6S, A5, A5S, B5, B5S, A4, A4S, B4, A3, A3
wide, irregular sizes, tabs
Paper Weights
50 – 244g/
m
2
(50 – 300g/
m
2
in sub-tray)
SD-501 Saddle
Paper Sizes
Saddle stitching / trimming / multi-centre fold: B5, B5S, A4, A4S, B4,
Stitcher
A3, A3 wide, irregular sizes
Multi-letter fold: A4S
Sub-tray: Postcard, B6, B6S, A5, A5S, B5, B5S, A4, A4S, B4, A3, wide
sizes, irregular sizes, tabs
Paper Weights
Saddle stitching & trimming: 50 – 244g/
Multi-centre fold: 50 – 244g/
2
m
Multi-letter fold: 50 – 91g/
m
2
Sub-tray: 50 – 300g/
m
2
Max. Sheet Cutting
50 sheets x 2 (80g/
m
2
)
FS-503 Staple
Paper Sizes
Staple mode: A5, B5, B5S, A4, A4S, B4, A3, irregular sizes, tabs
Finisher
Straight / shift mode: A5, B5, B5S, A4, A4S, B4, A3, irregular sizes, tabs
Sub-tray: Postcard, A6S, B6S, A5, A5S, B5, B5S, A4, A4S, B4, A3, A3
wide, irregular sizes, tabs
Paper Weights
Staple / shift / straight mode: 50 –244g/
Sub-tray mode: 50 – 300g/
m
2
Capacity
Main tray: Straight / shift mode: 3,000 sheets (B5, B5S, A4, A4S); 1,500
sheets (B4, A3); 500 sheets (A6, B6, A5)
Staple mode: 1,000 sheets
Sub tray: 200 sheets (same size)
Staple Modes
Corner stapling: horizontal, vertical
2-point stapling: horizontal, vertical
FD-501
Punch Types
2-hole punch, 4-hole punch
Multi-Folding
Fold Types
Centre fold, letter fold-in, letter fold out, double parralell, Z-fold, gatefold
Unit
Paper Sizes
2-hole punch: A5, A5S, B5, B5S, A4, A4S, B4, A3, tabs4-hole punch: B5,
A4, B4, A3, tabs
Folding mode: A4S, B4, A3, irregular sizes
Post insertion mode: A5, B5, B5S, A4, A4S, B4, A3 wide, irregular sizes,
tabs
Straight mode: B6S, A5, A5S, B5, B5S, A4, A4S, B4, A3, A3 wide,
irregular sizes, tabs
Sub tray mode: Postcard, A6S, B6S, A5, A5S, B5, B5S, A4, A4S, B4, A3,
A3 wide, irregular sizes, tabs
Paper Weights
Punch mode: 50 – 209g/m
2
Folding mode: 50 – 130g/m
2
(centre fold, letter fold-in, letter fold out,
Z-fold); 50 – 91gm
2
(double parralell, gatefold)
Post insertion mode: 50 – 300g/m
2
Straight mode: 50 – 244g/m
2
Sub-tray mode: 50 – 300g/m
2
m
2
OT-502 Output Tray
DF-609 Direct Feeder
(OC-506 Original Cover also available)
PK-512 Punch Kit
IC-303 Print Controller (External)
PI-502 Post Inserter
IC-408 Print Controller (Embedded)
RU-503 Relay Unit
FS-607 Staple Finisher
bizhub PRO C6500
RU-504 Relay Unit
(with power unit)
LU-202 Large Capacity Unit
HT-503 Dehumidifying Heater
m
2
m
2
HD-506 Internal HDD
PF-601 Paper Feed Cabinet
HT-504 Dehumidifying Heater
For Production Print Professionals
The full-colour, on-demand digital press that expands the boundaries of production printing
