Intel ETHEREXPRESS PRO/100 Quick Start Card

Q u i c k
EtherExpress
Use these instructions to install the PRO/100 PC Card under Windows 95*
Windows 98*, Windows for Workgroups, or Windows NT*. For MS-DOS
without Windows , see Chapter 2, Software Installation in the User's Guide .

1. Windows 95 / 98

Start your computer first and let
Windows 95 /98 run. With the
Intel logo on top and the arrow on
the label facing into your
computer, insert the card in a PC
Card (PCMCIA) slot. Push until
the card is firmly seated. Go to
step 2.

1. Windows 3.x

Do not start your computer. With
the Intel logo on top and the arrow
on the label facing into your
computer, insert the card in a PC
Card (PCMCIA) slot. Push until
the card is firmly seated.

2. Attach adapter cable to card

As shown, attach the adapter cable to the card and push in lightly. Note position
of Intel logo.

3. Connect network cable to adapter

As shown, attach the network cable RJ-45 connector to the PRO/100 PC Card
RJ-45 cable receptacle.
668560-003
S t a r t
™
PRO/100 Mobile PC Card
C a r d
ATTACH THE ADAPTER
CABLE TO THE CARD
CONNECT THE NETWORK
CABLE TO THE ADAPTER
CABLE
More
