  6. Assembly and use manual

Aussie 69F6U00KS1 Assembly And Use Manual

Six burner event grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For Outdoor Household Use Only. Not for Commercial Use.
Need Help? Need to Register Your Grill? Looking for Aussie Parts & Accessories?
Visit us online at www.AussieGrills.com Or call Aussie Customer Service at 1-800-251-7558
WARNING
!
• Failure to follow these instructions could result in
fire or explosion which could cause death, serious
personal injury, or property damage.
• Read and follow instructions carefully before
assembly or use.
• Do not use this product for any other purpose than
which it is intended.
• These instructions must be kept with the user.
SAVE THESE INSTRUCTIONS.
WARNING
!
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
• An LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
LP Gas Grill Assembly and Use Manual
Six Burner Event Grill
Sets Up In Minutes
Great for Every Occasion
69F6U00KS1
D A N G E R
!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the appli-
ance and immediately call your gas supplier or
your fire department.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 69F6U00KS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aussie 69F6U00KS1

Summary of Contents for Aussie 69F6U00KS1

  • Page 1 Great for Every Occasion 69F6U00KS1 For Outdoor Household Use Only. Not for Commercial Use. Need Help? Need to Register Your Grill? Looking for Aussie Parts & Accessories? Visit us online at www.AussieGrills.com Or call Aussie Customer Service at 1-800-251-7558 WARNING D A N G E R •...
  • Page 2 D A N G E R CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space, such as a camper, tent, car, or home. WARNING To reduce the risk of serious injury or death from fire or explosion: •...

  • Page 3: Table Of Contents

    Packing List Description Grill Body Folding Cart Firebox Handles Wheels Casters Cylinder Bracket Cooking Grids (not pictured) Flavor Activators (not pictured) Grease Pan (not pictured) Hardware Pack (not pictured) Detailed Parts List and Owner’s Manual and Warranty Illustrations may be Card (not pictured) found on pages 26 &...

  • Page 4: Assembly Instructions

    Assembly Instructions CAUTION PINCH HAZARD To reduce the risk of bodily injury from pinch hazard, keep hands and fingers away from hinges, leg pivot points and moving parts. Only open the cart by gripping the top of each leg frame. Read and follow these instructions to set up your grill.

  • Page 5: Set-Up Instructions

    Set-Up Instructions Step 1 Unfolding Cart To avoid being pinched by hinges or moving parts, only open the cart by gripping the top of each leg frame. Gripping at the top, lift up and outwards until the leg frames are straight up. Press down firmly at the center of each Leg Lock Bracket to insure each is straight and in the locked position.

  • Page 6: Step 3 Placing The Grill Body On The Cart

    CAUTION To reduce the risk of bodily injury from lifting, the following assembly step will require two people. Step 3 Placing the Grill Body on the Cart With one person at each end, grasp the “Gripping Portion” of the Tubular Handles and place the Grill Body on Cart. Corners of Firebox will fit INSIDE brackets on top of legs.

  • Page 7: Step 4 Opening The Firebox

    Step 4 Firebox Handle in Up and Locked position Opening the Firebox IMPORTANT: Be sure the Firebox Handles are in the Up and Locked position before opening and using side tables. First, open the left side table, then open the right. When closing, first close the right side table so the drainage lip is under the edge of the left side table.

  • Page 8: Grease Pan/Foil Pan Installation

    Step 6 Step 7 Grease Pan / Foil Pan Installation Igniter Battery Installation Insert the Foil Pan into the Grease Pan. Slide the Grease Unscrew Igniter Cover and insert AA Battery with the Pan into the guides under the Bottom Body Panel. This negative “-“...

  • Page 9: Connecting/Disconnecting The Gas

    Connecting/Disconnecting the Gas Using Gas D A N G E R Carbon Monoxide Hazard • This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. • Never use this appliance indoors, on recreational vehicles, or boats. WARNING To reduce the risk of serious bodily injury or death from fire or explosion: •...

  • Page 10: Lp Hose And Regulator

    LP Hose and Regulator WARNING To reduce the risk of serious bodily injury or death from fire or explosion: • Clean and inspect the gas hose/regulator before each use of the outdoor cooking gas appliance. The gas hose/ regulator must be replaced prior to being used, if there is evidence of excessive abrasion or wear, or if the hose is cut or leaks.

  • Page 11: Before Using Your Lp Gas Grill

    Before Using Your LP Gas Grill Installation Codes WARNING To reduce the risk of serious bodily injury or death from fire or explosion: • This installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2 or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192 and CSA Z240 RV Series, recreational Vehicle Code, as applicable.

  • Page 12: How To Perform A Leak Test

    How to Perform A Leak Test “FIRST TIME USE” and as required Supplies Needed for a Leak Test: • Clean paint brush • Water • Dish washing liquid • Clean container 1. Use an LP Gas Cylinder equipped with an OPD (Overfill Prevention Device) and have it filled at an authorized LP gas dealer by a qualified attendant.
  • Page 13 6. Check for leaks by brushing the soap solution on all gas valves, hose connections and fittings. (Shown by the heavy arrows in Fig. 3 and 4) Make sure you generously brush the locations with the soap solution, completely surround- ing the connections and fittings.

  • Page 14: Lighting The Grill Using The Pulse-Spark Ignitor

    Lighting the Grill Using the Pulse-Spark Ignitor WARNING To reduce the risk of death or serious injury from an explosion or a fire beneath the grill: • Regularly inspect and clean Burner/Venturi Tubes for insects or insect nests. Spiders or small insects can build nests, webs, and lay eggs in the grill’s Venturi Tubes, (Fig 12, page 20) obstructing the flow of gas to the Burner.
  • Page 15 4. Push the Igniter Button in until the Burner is lit. Listen for the spark ignition, and look to make sure the Burner is lit. If no spark, first be sure the gap between the electrode and burner is 3/16” (Fig. 10). If still no spark see Trouble- shooting Section on page 23.

  • Page 16: Manually Lighting The Grill

    Manually Lighting the Grill 1. IMPORTANT: Make sure Control Knobs are turned “Off.” (Fig. 7 - P.14) 2. Turn the LP Gas Cylinder valve open counterclockwise until it stops. (Fig. 8- P.14) 3. Using the Match Holder, Insert a lit match through the cooking grids near the burner to be lit. (Fig. 11) 4.

  • Page 17: Cooking On The Gas Grill

    Cooking On the Gas Grill WARNING To reduce the risk of serious bodily injury or death from fire, explosion or burn hazard: • Never use charcoal or lighter fluid in your gas grill. Keep this outdoor cooking appliance clear and free from combustible materials, gasoline, and other flammable vapors and liquids.

  • Page 18: End Of Cooking Session

    Grill Cooking (Direct Method) Direct Cooking on the Grids: Food is cooked directly over the heat source. The Burners heat up the Flavor Activators under the Cooking Grids, which in turn heat the food on the grill. The natural food juices from cooking fall onto the hot Flavor Activators below and vaporize.

  • Page 19: Care And Maintenance

    Care and Maintenance CAUTION To reduce the risk of a laceration hazard, wear protective gloves when handling parts that have sharp edges. Cleaning the Grill Bottom Body Panel, Grease Pan, Foil Pan: Remove the Bottom Body Panel. (page 21) Scrape away food and fat residue from the Bottom Panel. Empty and wash the Foil Pan and Grease Pan with hot soapy water and a cloth.

  • Page 20: How To Clean The Burners

    In order to prevent flashbacks, the Burner(s) should be removed from the grill and cleaned periodically, especially if the grill has been stored for an extended period of time. Valve Control Knob Burner Spider webs or nest inside Venturi Tube Venturi Tube Fig.

  • Page 21: Bottom Body Panel Removal

    5. Use a pipe cleaner to clear insect nests from the inlet hole of Burner (Fig. 15) 6. Open up the Burner holes (Fig. 15) with a small nail or wire. Use a non-metal- lic brush to remove food particles and corrosion from the Burner surfaces. Fig.

  • Page 22: Storage And Transportation

    Storage and Transportation WARNING To reduce the risk of serious bodily injury or death: • Store your LP gas grill in a cool dry place. Do not store an LP Gas Cylinder in a space greater than 125 degrees Fahrenheit. Never store a connected LP Gas Cylinder in a building, garage, or any enclosed area. •...

  • Page 23: Emergencies

    Emergencies Problem Possible Cause Solution Gas leaking from Damaged hose Turn off gas at the LP Gas Cylinder. Replace valve/hose cracked/cut/burned hose regulator before continuing use. Gas leaking from Mechanical failure due to rust Replace LP Gas Cylinder. LP Gas Cylinder or mishandling Gas leaking from LP Gas Failure of valve from mishan-...
  • Page 24 Troubleshooting Problem Possible Cause Solution Regulator coupling nut is not Tighten coupling nut by hand about one-half to three quar- fully connected to LP cylinder ters additional turn. Do not use tools. LP-Excess flow valve tripped in Turn Control Knobs to “Off” position and turn LP Gas Cyl- regulator inder handle clockwise until it stops.

  • Page 25: Important Notice- Lp Cylinder With Opd

    Problem Possible Cause Solution Flare up Grease build-up Clean grill. Excessive fat in meat Trim fat from meat before grilling. Persistent grease fire Grease trapped around burner Turn Control Knobs “Off” and turn handle of LP Gas Cylinder system clockwise until it stops. Carefully and let fire burn out. After the grill cools, remove and clean all parts.

  • Page 26: Parts Illustration

    Parts Illustration...

  • Page 27: Parts List

    Parts List When ordering parts, it is VERY important to have the complete Model Number to receive the correct replacement parts for your grill. Description Quantity Windscreen If you need replacement parts, refer to the Parts Il- Cooking Grid lustrations to find the exact parts you need. If you have any questions or need help, go to www.aussiegrills.

  • Page 28: Limited Warranty

    Limited Warranty MECO CORPORATION - LIMITED WARRANTY This product is warranted to the original consumer purchaser against defects in material and workmanship under normal outdoor household use and correct assembly (if assembled by the consumer purchaser). Burners are warranted for a period of two (2) years from the date of purchase. Stainless steel parts are warranted for a period of one (1) year (for rust-through only) from the date of purchase.
