Aussie
ULURU
Assembly and Use Manual
For Customer Service, call
1-800-251-7558
www.aussiegrill.com
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open Lid.
4. If odor continues, immediately call your gas
supplier or your fire department.
TM
LP Gas Grill
TM
This manual intended for the following models: 8362 & 8462.
• READ AND FOLLOW INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY OR USE.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DEATH, SERIOUS
BODILY INJURY, AND/OR PROPERTY LOSS.
• FOR OUTDOOR HOUSEHOLD USE ONLY. NOT FOR COMMERCIAL USE.
• SOME PARTS MAY CONTAIN SHARP EDGES - ESPECIALLY WHERE NOTED IN THIS
MANUAL! WEAR PROTECTIVE GLOVES IF NECESSARY.
• THESE INSTRUCTIONS MUST BE KEPT WITH THE CONSUMER AND RETAINED FOR
FUTURE USE.
• PORCELAIN COATING CAN CHIP DURING ASSEMBLY. WEAR SAFETY GLASSES WHILE
ASSEMBLING GRILL.
©Aussie™ Grill Company 2001
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
