Table Top Grill
NOTE: Quick Disconnect Hose & Hanger Rail
not included.
For Outdoor Household Use Only. Not for Commercial Use.
D A N G E R
!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fi re
department.
Failure to follow these instructions could result
in fi re or explosion which could cause prop-
erty damage, personal injury or death.
Need Help? Need to Register Your Grill? Looking for Aussie Parts & Accessories?
Visit us online at www.mecocorp.com/registration Or call Customer Service at 1-800-251-7558
LP Gas Grill Users Manual
for Recreational Vehicles
6TV1S00KP1 -
6TV1U00SS1 -
-
Hanger Bracket Included
Satin Black
Stainless Steel
WA R N I N G
!
• This instruction manual contains important
information necessary for the proper assem-
bly and safe use of this appliance. Failure to
follow these instructions could result in death
or serious injury from explosion or fi re.
• Read and follow all warnings and instruc-
tions carefully before assembling or using
this appliance.
• Follow all warnings and instructions when
using this appliance.
• Keep this manual for future reference.
SAVE THESE INSTRUCTIONS.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aussie 6TV1U00SS1
Summary of Contents for Aussie 6TV1U00SS1
- Page 1 • Keep this manual for future reference. erty damage, personal injury or death. SAVE THESE INSTRUCTIONS. Need Help? Need to Register Your Grill? Looking for Aussie Parts & Accessories? Visit us online at www.mecocorp.com/registration Or call Customer Service at 1-800-251-7558...
- Page 2 D A N G E R CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide, an odorless toxic gas. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space, such as a camper, tent, car, boat or home. This appliance is not intended for and should never be used as a heater.
-
Page 3: Table Of Contents
Packing List Grill Body When ordering parts, it is VERY important to have the complete Model and Serial Number to receive the correct replacement parts for your grill. The grill Igniter Housing Assembly model number and serial number are printed on the label located on the inside Valve Housing Assembly surface of the rear leg. -
Page 4: Preparation For Assembly
Preparation for Assembly Remove grill, Hanger Bracket, Carry Bag and all packaging materials from the carton and place on a clean level surface. Some parts are packed inside the grill body. Remove, unpack and inspect these parts as well. To remove Cooking Grid with attached parts box, see instructions below. -
Page 5: Grill Assembly Instructions
Grill Assembly Instructions Step 1 Hood Handle Assembly Hood Handle Place a Handle Bezel between each end of the handle and the grill hood then insert a 1/4-20 x .50” Bolt through the inside of the hood into each end of the Hood Handle Bezel handle. -
Page 6: Step 3 Igniter Housing Assembly
Step 3 Igniter Housing Assembly Thread the Electrode Wire through the hole in the Igniter Housing and attach the end onto the pin at the bottom end of the Piezo Igniter. Align the holes in the Igniter Housing with the threaded holes in the fi rebowl end. Insert three 5/32 x .31” Bolts through the housing into the threaded holes. -
Page 7: Step 5 Install Cooking Grid
Step 5 Install Cooking Grid If Warming Rack is installed, remove legs from holes in sides of the fi rebowl as instructed in “Unpacking” on page 4. Place the back edge of the Cooking Grid on the ledges of the fi rebowl ends and slide towards the back of the back of the grill until the Cooking Grid drops down into a fl... -
Page 8: Hanger Bracket Assembly And Use
Hanger Bracket Assembly and Use Hanger and Leg Brackets Assembly Slide the U-Tube on to the tapered ends of the Hanger Bracket Frame. Align holes in both parts and fasten in place with two 10-24 wingbolts and wingnuts. Attach two Leg Brackets to the crosstube of the Hanger Bracket Frame oriented as shown. Insert the 1/4-20 Leg Bracket Wingbolt through the hole in the Leg Bracket and into the threaded hole on the crosstube. -
Page 9: Attaching The Grill To The Hanger Bracket
WA R N I N G To reduce risk of serious injury or death from fi re or burn hazard: • Verify that the mounting rail attached to the RV is solidly attached per the manufacturer’s mounting instructions. • Also verify that the Hanger Bracket is securly hung on the rail with the bottom channel resting squarely on the side of the RV and that the grill is locked in position on the Hanger Bracket before using. -
Page 10: Hanger Bracket Orientation
Hanger Bracket Orientation The Hanger Bracket may be placed on the hanger rail in either orientation shown below. This allows for the cooking surface of the grill to be higher or lower depending on the user’s preference. Note: The method of attaching the grill to the Hanger Bracket is the same for either orientation. Table Top Use WA R N I N G To reduce risk of serious injury or death from fi... - Page 11 This page left intentionally blank...
-
Page 12: Connecting/Disconnecting The Gas
Connecting/Disconnecting the Gas Using Gas D A N G E R If you see, smell, or hear the hiss of LP gas escaping from the connections: 1. Do not attempt to light appliance. 2. Extinguish any open fl ame. 3. Disconnect from fuel supply. Carbon Monoxide Hazard •... - Page 13 WA R N I N G To reduce the risk of serious injury or death from fi re or explosion: • If the grill connection fi tting or the fl exible gas hose connector are bent, deformed or damaged, do not use. Connecting to the LP Gas Supply (continued) 1.
-
Page 14: Before Using Your Lp Gas Grill Installation Codes
Before Using Your LP Gas Grill Installation Codes WA R N I N G To reduce the risk of serious bodily injury or death from fi re or explosion: • This installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2 or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192 and CSA Z240 RV Series, recreational Vehicle Code, as applicable. -
Page 15: Performing A Leak Test
Performing A Leak Test WA R N I N G To reduce the risk of serious bodily injury or death from fi re or explosion: • Perform a leak test before lighting your grill for the fi rst time. • Perform a leak test if any gas component is changed. •... -
Page 16: Lighting The Grill
Lighting the Grill WA R N I N G To reduce the risk of serious bodily injury or death from fi re or explosion: • Open Hood before lighting the grill to release trapped gas. • During failed lighting attempts, or if the Burner goes out during operation, turn Control Knob “Off ” to dissipate any accumulated gas. -
Page 17: Manually Lighting The Grill
Manually Lighting the Grill 1. Open the Hood. IMPORTANT: Make sure Control Knob is turned “Off .” 2. While holding a lit match near the burner, push Burner Control Knob in and turn 90 degrees counterclockwise to the High position. (Fig. 4) If Burner goes out during operation, turn Control Knob to the “Off... -
Page 18: Cooking On The Gas Grill
Cooking On the Gas Grill WA R N I N G To reduce the risk of serious injury or death from fi re, explosion or burn hazard: • Never use charcoal or lighter fl uid in your gas grill. Keep this outdoor cooking appliance clear and free from combus- tible materials, gasoline, and other fl... -
Page 19: Warming Rack
Controlling Flare-ups: Flare-ups are part of cooking meats on a grill. This adds to the unique fl avor of barbequed food. However, excessive fl are- ups can overcook your food and create a dangerous situation for you and your grill. Excessive fl are-ups may result from large amounts of fat on the food being cooked or the build up of grease in the grill. -
Page 20: Care And Maintenance
Care and Maintenance Cleaning the Grill CAUTIO N To reduce risk of laceration hazard, wear protective gloves when handling parts with sharp edges. Drip Tray: Remove the Drip Tray under the grill bowl after the grill has cooled completely. Scrape away food and fat residue from the Drip Tray. - Page 21 4a.(6TV1S) Detach the electrode wire from the igniter and lift up gently on the back of the burner while sliding the end of the burner off of the valve nozzle (Fig. 8). Gently pull the electrode wire back through the fi rebowl until it comes free with the burner.
-
Page 22: Storage And Transportation
7. Check the Electrode to see if it is loose. If so, tighten the screw holding the Electrode to maintain 3/16” gap between Electrode tip and Burner. NOTE: Before next step, you may wish to clean the rest of the grill. See “Cleaning the Grill” section. 8. -
Page 23: Emergencies
Emergencies Problem Possible Cause Solution Gas leaking between Improper installation, con- Remove Gas Supply line, clean and reconnect. See LP Gas Supply and Valve nection not tight, damage or “Leak Test” and “Connecting to the LP Gas Supply” sec- connection. debris in connections. - Page 24 Troubleshooting Problem Solution Possible Cause Burners will not light using a See re-assembly after cleaning in Care and Maintenance. Burners not assembled correctly. match Gas supply is turned off . Turn on LP gas supply. Properly connect the LP gas supply as described in the Gas supply connection is loose.
- Page 25 This page left intentionally blank...
-
Page 26: Parts Illustration
Parts Illustration... -
Page 27: Parts List
Parts List Description Quantity If you need replacement parts, refer to the Parts Illustrations to fi nd Thermometer the exact parts you need. Thermometer Bezel If you have any questions or need help, go to www.mecocorp.com or Hood contact Customer Service at 1-800-251-7558. Be sure to have the grill Hood Pivot Pin model number and serial number that are printed on the label located Hood Pivot Pin Nut (not shown) -
Page 28: Limited Warranty
Limited Warranty MECO CORPORATION - LIMITED WARRANTY This product is warranted to the original consumer purchaser against defects in material and workmanship under normal outdoor household use and correct assembly (if assembled by the consumer purchaser). Burners are warranted for a period of two (2) years from the date of purchase. Stainless steel parts are warranted for a period of one (1) year (for rust-through only) from the date of purchase.
