  • Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS AP 1246 G DUAL FUEL COOKER distributed by DèLonghi Pty Ltd...

  • Page 2: Product Label

    Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. Please keep this booklet in a safe place.

  • Page 3: Important Precautions And Recommendations

    IMPORTANT FIRST TIME USE THE OVEN It is advised to follow these instructions: Insert shelves and tray. Switch on the empty oven on max to eliminate grease tracks from the heating elements. Let the oven cool down, switch off the electrical supply, then clean the inside of the oven with a cloth soaked in water and neutral detergent and dry thoroughly.

  • Page 4: Installation

    I N S T A L L A T I O N Figure 1.1 CAUTION: This appliance must be installed in accordance with these installation instruc- tions. This appliance shall only be serviced by authorized personnel. This appliance is to be installed only by an authorised person. Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury of damage.

  • Page 5: Feeder Cable Section

    I N S T A L L A T I O N CONNECTING THE FEEDER Figure 1.2b CABLE To connect the feeder cable to the cooker it is necessary to: Remove the 4 screws that hold shield A behind the cooker. N(L2) L2 L3 Open completely the cable clamp D.
  • Page 6 I N S T A L L A T I O N Figure 1.3 CLEARANCES Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AG 601 (AS 5601) Gas Installations code. Installation shall comply with the dimension in Fig 1.4 bearing in mind that Overhead Clearances In no case shall the clearances between the highest part of the cooker...

  • Page 7: Assembling The Backguard

    I N S T A L L A T I O N Figure 1.5 ASSEMBLING THE BACKGUARD It is mandatory to install the backguard Assemble the backguard as shown in figure 1.5 and fix it by screwing the 5 screws “A”. LEVELLING THE COOKER The range is equipped with 6 LEVELLING FEET (already fitted on the appliance) and may be levelled by screwing or...

  • Page 8: Anti-Tip Stability Device Installation Instructions

    I N S T A L L A T I O N ANTI-TIP STABILITY DEVICE INSTALLATION INSTRUCTIONS YOU MUST USE STABILITY ANTI TIP BRACKET TO WARNING: In order to prevent accidental tipping of the appliance, for exam- PREVENT UNIT FROM ple by a child climbing onto the open oven door, the stabilizing means must TIPPING.

  • Page 9: Moving The Cooker

    I N S T A L L A T I O N GAS AND ELECTRIC CONNECTION Figure 1.10 Dotted line showing the Area for GAS and ELECTRIC connection position of the range when installed Rif. 16,5 107 - 119 * : Depending on feet regulation MOVING THE COOKER WARNING WARNING...

  • Page 10: Universal Lpg

    I N S T A L L A T I O N Figure 1.14a GAS SUPPLY: Gas connection for The connection must be performed by an authorised person according to the rel- UNIVERSAL LPG evant standards. Before connecting the appliance to the gas main, mount the brass conical adap- tor onto the gas inlet pipe, upon which the gasket has been placed (figures 1.14a- Gas inlet pipe 1.14b).
  • Page 11 Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. WARNING, This appliance IS NOT SUITABLE for installation with a hose assembly.
  • Page 12 I N S T A L L A T I O N Figure 1.17a CONVERSION PROCEDURE (to convert to Universal LPG) REPLACING THE INJECTORS Rapid The conversion procedure must be carried out only by an authorised person. burner This appliance is suitable for use with Natural gas or Universal LPG (check the “gas type”...
  • Page 13 I N S T A L L A T I O N Figure 1.18 OPERATIONS TO BE EXECUTED FOR THE REPLACEMENT OF THE INJECTOR OF THE GRID- DLE BURNER Lift and remove the griddle stainless steel plate. Unscrew the no. 2 (two) screws and remove the plate "B" (fig. 1.18).
  • Page 14 I N S T A L L A T I O N Remove the burner as shown in figure 1.24. Using a 7 mm box spanner, unscrew the injector (indicated by the arrow in fig. 1.25) and replace it by the proper one according to the kind of gas.

  • Page 15: Lubrication Of The Gas Taps

    I N S T A L L A T I O N TABLE FOR THE CHOICE OF THE INJECTORS Natural gas Universal LPG 2.75 Test Point Pressure [kPa] Injector Injector BURNERS Consumption Orifice Dia. Consumption Orifice Dia. [mm] [MJ/h] [MJ/h] [mm] 1.45 10.30...
  • Page 16 U S E & C A R E CAUTION: This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. Do NOT place combustible materials or products on this appliance at any time.

  • Page 17: Control Panel

    C O N T R O L P A N E L U S E & C A R E Figure 2.2 15 16 CONTROLS DESCRIPTION Gas cooking hob controls: 1. Front left burner (2) control knob 2. Rear left burner (1) control knob 3.

  • Page 18: Cooking Hob

    C O O K I N G H O B U S E & C A R E Figure 2.3 GAS BURNERS Natural Gas Universal LPG MJ/h MJ/h 1. Rapid (R) 10.30 11.20 2. Triple ring burner (TC) 13.30 11.90 3.60 ( * ) 3.20 ( * ) 3.

  • Page 19: T O P B U R N E R S

    T O P B U R N E R S U S E & C A R E GAS BURNERS (Rapid and triple ring) Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 3.1) which control the valves.
  • Page 20 T O P B U R N E R S U S E & C A R E LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE (Rapid and triple ring) In order to light the burner, you must: 1 – Push and turn the knob in an anti-clockwise direction up to the position (maximum rate), push in and hold the knob until the flame has been lit (fig.
  • Page 21 T O P B U R N E R S U S E & C A R E GAS BURNER (Dual) The Dual Burner is a very flexible burner which allows different regulations and optimal cooking. It is composed by one inner and two outer crowns; the flame of the inner crown can be regulated separately from the flames of the outer crowns.
  • Page 22 T O P B U R N E R S U S E & C A R E LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE (Dual Burner) In order to light the burner, you must: 1 – Push and turn the knob in an anti-clockwise direction up to the position (maximum rate of inner crown);...

  • Page 23: Cooking Vessels

    T O P B U R N E R S U S E & C A R E CHOICE OF BURNER Figure 3.5 (fig. 3.5) The symbols printed on the panel above the gas knobs indicate the correspondence between the knob and the burner. The most suitable burner is to be chosen according to the diameter and volume capac- ity of the container to be warmed.

  • Page 24: Important Warnings

    G A S G R I D D L E U S E & C A R E GAS GRIDDLE The griddle plate, supplied with this range, is made of stainless steel. It shall be installed before using the range. Never use the griddle without using the supplied griddle plate.

  • Page 25: Grease Tray

    G A S G R I D D L E U S E & C A R E Figure 4.2 GRIDDLE STAINLESS STEEL PLATE POSITION- CORRECT 1 - Before installing the griddle plate fit the empty bottom grease tray. 2 - The griddle plate must be correctly placed to operate properly. The integrated grease tray for cooking juices shall be positioned towards the front of the range.

  • Page 26: Griddle Burner

    G A S G R I D D L E U S E & C A R E Figure 4.4 GRIDDLE BURNER The griddle burner generates the infra-red rays which ensure an uniform cooking on the griddle cooking plate. Gas flow to the burner is adjusted by turning the knob (illustrated in fig. 4.4) which con- trols the valve.
  • Page 27 G A S G R I D D L E U S E & C A R E LIGHTING THE GAS GRIDDLE BURNER FITTED WITH FLAME FAILURE SAFETY DEVICE In order to light the burner, you must: 1 - With the griddle plate correctly installed push and turn the knob in an anti-clock- wise direction up to the position (maximum rate), push in and hold the knob until the flame has been lit (fig.

  • Page 28: Using The Griddle

    G A S G R I D D L E U S E & C A R E USING THE GRIDDLE Before using the griddle the griddle plate cooking surface shall be seasoned. Seasoning is an important process which keeps food from sticking during cook- ing and avoid surface corrosion.

  • Page 29: Griddle Care

    G A S G R I D D L E U S E & C A R E GRIDDLE CARE WARNING. VERY IMPORTANT. Before any operation of maintenance disconnect the appliance from the elec- trical mains supply. Before cleaning the griddle, turn control knob to OFF and allow griddle to cool.
  • Page 30 W A R M E R D R A W E R S U S E & C A R E Figure 5.1 GENERAL FEATURES The warming drawer is fitted with an heating element (500 W at 240 V ) placed on the top.

  • Page 31: Temperature Selector

    W A R M E R D R A W E R S U S E & C A R E TEMPERATURE SELECTOR Knob position °C The setting can be anywhere between LO and HI position. between LO and HI from 31 to 119 WARNING LIGHT The signal light is located above the con-...

  • Page 32: Self-Cleaning

    S E L F C L E A N I N G O V E N S U S E & C A R E GENERAL FEATURES Attention: the oven door becomes The ovens have special operating features. very hot during operation. Keep children away.

  • Page 33: Selecting The Functions

    S E L F C L E A N I N G O V E N S U S E & C A R E Figure 6.1 SELECTING THE FUNCTIONS (fig. 6.1) The cooking function is selected by turning the function selector knob and matching the mark with the symbol printed on the print.
  • Page 34 S E L F C L E A N I N G O V E N S U S E & C A R E TRADITIONAL CONVECTION COOKING The upper and lower heating elements switch on. The heat is diffused by natural convection and the temperature must be set between 50 °C (120 °F) and 250 °C (480 °F).

  • Page 35: Self-Cleaning Function

    S E L F C L E A N I N G O V E N S U S E & C A R E SELF CLEANING FUNCTION (this is not a cooking function) IMPORTANT NOTES: This is not a cooking function but is only used to clean the oven. Before starting the self cleaning cycle: - Take all the accessories out of the oven (drip tray and shelves).
  • Page 36 S E L F C L E A N I N G O V E N S U S E & C A R E SELECTING °F/°C ON THE DISPLAY Turn the oven selector knob to a cooking function (i.e. BAKE). Press key 5 on the programmer to reduce the temperature until you reach the min- imum value 120 °F (50 °C).
  • Page 37 S E L F C L E A N I N G O V E N S U S E & C A R E HOW TO START THE SELF CLEANING CYCLE Important: the self cleaning cycle must only be performed with the oven empty; so, before starting the cycle take all the accessories (shelves, drip tray, ...) out of the oven cavity and dry any traces of overflowed liquid.
  • Page 38 S E L F C L E A N I N G O V E N S U S E & C A R E PROBLEMS ON STARTING AND DURING THE SELF CLEANING CYCLE door Steady The function selector has been turned to the self cleaning position with the oven door open or not perfectly closed.
  • Page 39 S E L F C L E A N I N G O V E N S U S E & C A R E HOW TO STOP THE SELF CLEANING CYCLE Turn the function selector to (oven OFF) If the oven cavity temperature is higher than 300 °C (570 °F). 1a.
  • Page 40 S E L F C L E A N I N G O V E N S U S E & C A R E ABNORMAL SITUATIONS AND/OR OPERATION PROBLEMS during cooking or the self cleaning cycle. 30 F0 30 F1 appear during the cooking or self cleaning cycle Oven temperature sensor broken or not working properly.
  • Page 41 S E L F C L E A N I N G O V E N S U S E & C A R E C O O K I N G A D V I C E WARNING!! STERILIZATION KEEP ATTENTION Sterilization of foods to be conserved, in full and hermetically sealed jars, is done in the following way:...

  • Page 42: Broiling Pan

    S E L F C L E A N I N G O V E N S U S E & C A R E Figure 6.2 BROILING PAN 1° STEP 2° STEP 3° STEP 4° STEP Figure 6.2a BROILING Very important: the broil element must always be used with the oven door closed.
  • Page 43 S E L F C L E A N I N G O V E N S U S E & C A R E Figure 6.3 1° STEP GRILL PAN 2° STEP 3° STEP 4° STEP BROILING Figure 6.3a Very important: the broil element must always be used with the oven door closed.

  • Page 44: Electronic Programmer

    E L E C T R O N I C P R O G R A M M E R U S E & C A R E - The electronic programmer is a device which groups together the following functions: –...

  • Page 45: Semi-Automatic Cooking

    - E L E C T R O N I C P R O G R A M M E R U S E & C A R E TIMER The timer function is only used to count the time and does not influence oven operation or any programmes which are in progress or set.

  • Page 46: Automatic Cooking

    - E L E C T R O N I C P R O G R A M M E R U S E & C A R E AUTOMATIC COOKING Start cooking at the programmed time and switch the oven off automatically after the programmed cooking time.
  • Page 47 - E L E C T R O N I C P R O G R A M M E R U S E & C A R E CANCELLING A SET PROGRAMME To cancel any programme just turn the function selector to (oven OFF).
  • Page 48 C L E A N I N G & M A I N T E N A N C E Maintenance WARNING Description Period VERY IMPORTANT Daily • Clean gas cooktop as per instructions below. Before any operation of maintenance •...
  • Page 49 C L E A N I N G & M A I N T E N A N C E Figure 8.1 Figure 8.2 BURNERS AND GRIDS They can be removed and washed only with soapy water. Detergents can be used but must not be abrasive or corrosive.

  • Page 50: Cleaning And Maintenance

    C L E A N I N G & M A I N T E N A N C E Figure 8.6 CORRECT POSITION OF DUAL BURNERS The DUAL burner must be correctly positioned (see fig. 8.6); the burner rib must be fitted as shown by the arrows.

  • Page 51: Removing The Warmer Drawer

    C L E A N I N G & M A I N T E N A N C E REMOVING THE WARMER DRAWER (fig. 8.12) WARNING: 1. Open the drawer completely (fig. 8.12) • Do not remove drawer while hot. 2.

  • Page 52: Replacing The Oven Light

    C L E A N I N G & M A I N T E N A N C E Figure 8.16 REPLACING THE OVEN LIGHT (fig. 8.16) Before any maintenance is started involving electrical parts of the appliance, it must be disconnected from the power supply.

  • Page 53: Do's And Do Not's

    C L E A N I N G & M A I N T E N A N C E DO’S AND DO NOT’S Do always use the oven with the door closed. Do read the user instructions carefully before using the range for first time. Do allow the oven to heat for about two hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food.

  • Page 54: Service And Maintenance

    S E R V I C E & M A I N T E N A N C E If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised Service Agent: Burner is reassembled and located correctly.

  • Page 55: Electric Diagram

    E L E C T R I C D I A G R A M...
  • Page 56 Rif. 1688.5...
