INSTEON SwitchLinc V2 Dimmer User's Guide
Mechanical
Paddle Type
Paddle and Trim Frame Color
Wire Nuts
Mounting
Operating Conditions
Dimensions
Weight
Electrical
Supply Voltage
Surge Protection
Power Wire Leads
Ground Lead
Load Types
Maximum Load
Minimum Load
Certification
True rocker action
White installed, Ivory included;
Optional Almond, Black, Brown, or Gray with #2400xx kits
5 included
Mounts in single or multiple-ganged junction box.
Control 200 W less load for each immediately adjacent SwitchLinc Dimmer
installed. For example, 600 W load control becomes 400 W with another dimmer
to the immediate right or left. Use a triple-gang box with a mechanical switch in
the center to avoid de-rating.
Indoors, 40 to 104°F, up to 85% relative humidity
4.1" H x 1.8" W x 1.2" D
3.6 oz
120 Volts AC +/- 10%, 60 Hertz, single phase
MOV rated for 150 Volts
6", 16 AWG, stranded,
600V, 105°C insulation, ends stripped and tinned,
LINE (black), LOAD (red), NEUTRAL (white)
6", 18 AWG, stranded, bare copper
Wired-in incandescent lighting devices
600 Watts (uses 12-Amp triac dimmer)
No minimum load required
Safety tested for use in USA and Canada (ETL #3017581)
Page 34 of 35
