INSTEON SwitchLinc V2 Dimmer User's Guide

COLOR OPTIONS FOR SWITCHLINC DIMMER

Paddle and LED Colors are Changeable

You can change the color of SwitchLinc Dimmer's LEDs and also its paddle and trim frame to match the
décor of any room.
SwitchLinc Dimmer comes standard with a white paddle assembly, but with an ivory paddle assembly
included. You can optionally purchase almond (#2400AL), black (#2400BK), brown (#2400BR), or gray
(#2400GY) SwitchLinc Color Change Kits from www.smarthome.com.
Light-pipe color change kits for the LEDs are also available from www.smarthome.com. Each SwitchLinc
Indicator Color Change Kit (#2400L) contains five each of blue, red, green, amber, and clear light-pipes.

How to Change Paddle and LED Colors

You can remove the front paddle and trim frame assembly before or after SwitchLinc Dimmer is installed.
During the changeover process, the power and the load may remain on and operating. There are no
dangerous voltages or unsafe areas under the paddle.
1. If SwitchLinc Dimmer is already installed in the wall, remove the
faceplate from the switch junction box.
2. Remove the four Phillips screws that hold the paddle assembly to the
metal frame.
3. Pull the entire paddle frame straight away from the switch. You may
have to wiggle the bottom of the frame to get it free of the bottom SET
Button.
4. Using a flat blade, remove the large light pipe as shown. The light pipe
will snap out of the frame. Do the same for the small light pipe.
Page 27 of 35
Paddle Assembly and
SwitchLinc body separated
Snap out the light pipes with a
flat tool
