HOW TO USE SWITCHLINC DIMMER

Using the Paddle

The Paddle Top makes your light go ON and the Paddle Bottom makes your light go OFF.
•
Tap the Paddle Top to make your light go at the Local Ramp Rate from whatever brightness it
currently has to the Local On-Level brightness.
•
Tap the Paddle Bottom to make your light go at the Local Ramp Rate from whatever brightness it
currently has to full-OFF.
•
Double-tap the Paddle Top to make your light go full-ON quickly.
•
Double-tap the Paddle Bottom to make your light go full-OFF quickly.
•
Press and hold the Paddle Top to gradually brighten your light from whatever brightness it currently
has to full-ON.
•
Press and hold the Paddle Bottom to gradually dim your light from whatever brightness it currently
has to full-OFF.
Paddle
Top
Bottom

Using the Air Gap

Pulling the SET Button at the bottom of the paddle out as far as it will go (about 1/8") opens mechanical
contacts that remove all power from SwitchLinc Dimmer and the load that it controls. "Air gapping" can be
useful for replacing bulbs or any other time you want the controlled circuit to be unpowered.
Because SwitchLinc Dimmer's settings are stored in non-volatile memory, setup information will not be
lost when the unit unpowered.
If you press the SET Button in too far when you undo the air gap, you might inadvertently reset
SwitchLinc V2 Dimmer to its factory default settings. Just push the button in until its top is even with
the Trim Frame.
Tap
Ramp to On-Level
Ramp to OFF
BE CAREFUL
Page 26 of 35
Double Tap Press and Hold
Fast ON Brighten
Fast OFF Dim
