INSTEON SwitchLinc V2 Dimmer User's Guide
3. Cap the other TRAVELER wire. The other TRAVELER
wire, usually red, will not be used, so put a wire nut on the
end of it.
4. Cap the red LOAD wire from the SwitchLinc Secondary.
Put a wire nut on the end of the SwitchLinc Secondary's
LOAD wire to ensure that it won't connect to anything.
5. Connect the SwitchLinc Secondary's NEUTRAL Wire.
Locate the group of NEUTRAL wires, usually white, in the
rear of the box.
connected to the NEUTRAL wires, but SwitchLinc Dimmer
requires this connection in order to draw a small amount of
power for itself.
NEUTRAL wire to the other NEUTRAL wires with a wire nut.
The old switch should not have been
Connect SwitchLinc Secondary's white
