  • Page 1 KIRK 4080 Handset User’s Guide...

  • Page 2: Table Of Contents

    Congratulations on your new KIRK handset Your new handset from KIRK telecom will provide you with the greatest possible degree of flexibility and mobility due to high battery capacity, low weight, practical size and design. Contents: 9.5 Menu subscription and login ..........22 9.5.1 Create subscription ..........23 1.

  • Page 3: Warning

    1. Warnings The KIRK 4080 is developed for use in potentially explosive working environments, as defined by local fire protection authorities. The handset complies with the ATEX directive 94/9/EC as well as IEC standards, please refer to Declaration of Conformity at the end of this user guide for more details.

  • Page 4: Construction

    Headset Connector Display with backlight 3. Construction MENU key Left arrow key, Redial menu from standby text Key for internal calls (not used on KIRK system 1500) Loud speaking Alarm key Keyboard LOCK (Menu*) Right arrow key, save number. Telephone book menu from Recall key standby text (MAIL key)

  • Page 5: Charging

    5. Charging Do not charge KIRK 4080 in a potentially explosive atmosphere. Use only the dedicated charger 8464 2458 (orange) for charging KIRK 4080. It takes approximately 3 1/2 hours to charge the handset from fully discharged to its full capacity. Place the handset in the charger.

  • Page 6: Turning The Handset On/Off

    “INT” -If residential systems: Internal calls off hook (not used on KIRK systems 1500 and 500) Turns loudspeaking on and off “R” - If off hook: Recall. If on hook: Read or write message “ ” - On hook/off hook and turn ON ”...

  • Page 7: Making A Call

    8. Making a call For making or receiving calls the handset has to be subscribed to a system ( shown in display) (see chap. 9.5.1) Press the -key, the -icon in the display will flash until connection is established Dial the number Pre-dial: Press the number to dial (long press on »...

  • Page 8: Receiving Calls

    8.1. Receiving calls If the phone rings, the call can be answered by pressing the -key. When ringing the LED flashes fast, and the display shows the CLIP (if presented). If it is an external call (or if no CLIP) the display shows “INCOMING CALL”. It is possible to stop the ring signal without answering the call.

  • Page 9: Menu Structure

    9. Menu structure Pressing the MENU-key, enters or exits the menu structure. It has to be used if a “NO” or “CLEAR” is wanted in the menu structure. Pressing the -key, jumps to a lower level in the menu. When the lowest menu level is reached, it will store the setting and jump to a higher level.

  • Page 10: The Key Functions

    9.2 The key functions Capital letter Small letter ? ! 1 - + * / = & ( ) % ¿ ¡ ? ! 1 - + * / = & ( ) % ¿ ¡ A B C 2 Ä Å À Á Ã Æ Ç a b c 2 ä...

  • Page 11: Handset Functions

    Profile set-up (fig) KIRK telecom PROFILE SET UP SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE SET PROFILE BACKLIGHT RINGER TONE RINGER VOL KEY CLICK VIBRATOR B-ANSWER START VOL OUT OF RANGE AUTO KEYLOCK LANGUAGE BACKLIGHT...

  • Page 12: Menu Subscription And Login

    SUBSCRIPTION 9.5 Menu subscription and login REMOVE MENU REMOVE? LOGIN PASSWORD Password is factory set 0000 _ _ _ _ _ MENU SUBSCRIPTION SUBSCRIPTION SUBSCRIPTION SELECT LOGIN CREATE REMOVE REMOVE LOGIN CREATE REMOVE SYSTEM1* SEARCH ID: SYSTEM 1 123456789012 REMOVE REMOVE REMOVE REMOVE...

  • Page 13: Login

    9.5.2 Login The handset can be subscribed to 10 different systems enabling you to use the same handset on 10 different systems. If you would like to change to another system, use the login menu to connect to another system number. The actual chosen system is marked with a or an A (if Autologin is selected).

  • Page 14: Remove Subscription

    9.5.4 Remove subscription Subscriptions can be removed from the system in use and from the 9 other systems (if connected). Removing a subscription requires a password. Password is factory set at 0000. If the system in use is removed, it is necessary either to select one of the remaining systems or to subscribe to a new one.

  • Page 15: Redial

    9.7 Redial The handset has maximum 10 redial numbers and 10 Caller ID’s placed in the same stack. Each number is only represented once. Enter the redial menu by pressing ”< ”(Redial) from the standby text. Repeated presses at the “<”...

  • Page 16: Book

    9.8 Book Storing a number (max. 24 digits) in the telephone book is done by pressing the number to be stored (in on hook), then press the “>”- key followed by the “ ” key. The book can store up to 65 numbers with name. Typing of the name and a confirmation is required.

  • Page 17: External Services

    9.9 External services External services are facilities placed in the main system, and only available if the handset is subscribed to a KIRK system. Under External services can be found; Clip stack, Delete clip stack and local Phone book. The Local Pho- ne book is a common Phone book for all handsets subscribed to the actual system, and all handsets subscribed to the system are listed in the Phone book.

  • Page 18: Mail/Textmessages

    9.11 Mail/Text Messages Available in systems configured with the possibility of sending text messages At the reception of a text message the envelope icon appears in the display. The envelope icon is indicating one or more unread messages. The text message is shown in the display, and when the message is read the envelope icon will disappear. If the message contains a call-back number, this will be displayed on the bottom line of the display.
  • Page 19 Delete a mail Open the mail by pressing the R-key followed by the -key, press the -key again and use the < >-keys to find the delete feature, press the -key and the mail is deleted Lock/unlock a mail Open the mail by pressing the R-key followed by the -key, press the -key again and use the <...

  • Page 20: Menu Language

    9.12 Menu language There are 6 predefined languages in the handset: English, German, French, Italian, Spanish and Dutch. If a 7th language is present this will be shown as ”OPEN”. The ”OPEN” selection is a specific dealer language and is facto- ry programmed.

  • Page 21: Information

    11. Information 11.1 Error tree Problem Check The telephone freezes Remove and replace the battery pack. Press to turn on the telephone The telephone does not ring Check whether the ringer is SILENT or RINGER VOL. is OFF The telephone cannot find a system ID at Check whether the system is set to allow subscriptions “SUBSCRIPTION CREATE”...

  • Page 22: Technical Information

    11.4. Technical information Approvals Acoustics: TBR 10 Electrical: TBR 6 (DECT RF) Access profile: TBR 22 (GAP) EMC: ETS 300 329 (CE labelling) Size and weight Size: 148 x 50 x 28 mm Weight: 130 g including battery ± 10 g Capacity Active talking time 16 hours Stand-by time 150 hours...

  • Page 23: Ec Declaration Of Conformity

    Langmarksvej 34 8700 Horsens Denmark Product Type KIRK 4080 0238 02XX Type number XX may vary (numbers and letters) depending on software and design. Telecom requirements The transceivers described above comply with the essential requirements of the R&TTE directive 99/5/EC if used...
  • Page 24 1999 Application, Intended purpose The KIRK 4080 is a DECT based handset, designed to be used in connection with KIRK wireless communication solutions in potentially explosive environments. The DECT transmitter frequencies of the apparatus are harmonized for these services in the European Community.
  • Page 25 Electrical apparatus for potentially explosive atmospheres The KIRK 4080 is in conformance with the requirements of the ATEX Directive 94/9/EC as well as the below standards Date EN 50014 (+ amendments) General requirements 1997 EN 50020 Intrinsic Safety “ i “.
  • Page 26 Quality Assurance The product is designed and produced by a manufacturing organisation, which is certified on ISO 9001: 2000 and ISO 14001: 1996 standards. These products are in conformance with the full quality assurance procedures as mentioned in annex III, IV and VII of the ATEX directive 94/9/EC and annex V of the R&TTE directive 99/5/EC and bears the marking 0539.
  • Page 27 For safe use of the KIRK 4080, please remind the following: The KIRK 4080 is developed for use in potentially explosive working environments, as defined by local fire protection authorities. The handset complies with the ATEX directive 94/9/EC as well as IEC standards.
  • Page 28 Equipment group II, ib group C (gas group C) Temperature group T3 (relevant for gas) IECEx International country code for notified body/year/certification number Special warnings concerning the use of KIRK 4080 exist, please refer to the users guide II 2G Equipment group II, zone 1 (gas) II 3D Equipment group II, zone 2 (dust) T60ºC...
  • Page 29 If in doubt about installation, configuration or the correct functioning of the product please consult the manufacturer: KIRK telecom A/S Customer Support Langmarksvej 34 8700 Horsens Denmark Tel: +45 75602850 support@kirktelecom.com...
