- Page 1 Operating instructions Rotary iron HM 5316 en - US, CA To prevent accidents and appliance damage, read these instructions before M.-Nr. 06 858 370 installation or use.
-
Page 2: Table Of Contents
Miele Ironing Handbook........ -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Be aware of loose fitting or hanging garments when using the rotary iron. Read all instructions before installation or Sleeves, apron ties, bracelets, etc. could be use. To prevent injury and machine caught by the roller. damage. Danger of burns when the heater plate is touched. - Page 4 IMPORTANT SAFETY INSTRUCTIONS Using accessories Do not damage, remove or bypass any of the safety features and controls of the rotary Only use genuine Miele accessories. If iron. other parts are used, guarantee, Do not operate a machine with an performance and product liability claims electrical fault until repaired.
-
Page 5: Guide To The Rotary Iron
Guide to the rotary iron 1 Heater plate with finger guard 2 Roller 3 Feed board 4 Operating panel 5 Laundry container 6 Cover for emergency handle insert 7 Emergency handle 8 Ironing table 9 Exhaust connector 10 Foot control bar... -
Page 6: Operating Panel
Guide to the rotary iron Operating panel a Temperature selector e Button "0" The temperature can be increased by tur- ning the selector clockwise. It can be de- When the button is pressed, the rotary iron is creased by turning the selector counter- turned off. -
Page 7: Foot Control Bar
Guide to the rotary iron Foot control bar Finger guard 1st Switch point The finger guard is a safety feature Steaming, the roller stops which must be checked before each use 2nd Switch point and button "O" pressed: of the rotary iron. The heater plate lowers and the roller turns. -
Page 8: Use
Correct dampness Ironing tips For best results, the residual moisture of the – To avoid creasing stop the roller, pull the laundry should be 25%. item back slightly and smooth out. If ne- cessary, dampen again with a wet cloth or spray bottle. -
Page 9: Ironing Laundry
Ironing laundry Steaming laundry ^ Turn the unit on at the wall switch. ^ To steam laundry, press the foot pedal down to the 1st switch point. ^ Ironing with coin mechanism: Insert coins or token. The roller stops. ^ Press "I" to turn the iron on. To feed thicker items ^ Select the temperature depending on the ^ Press the foot pedal down to the 2nd... -
Page 10: Frequently Asked Questions
Frequently asked questions Power failure Protecting the roller and iron cover If there is a power failure when the iron is in – During breaks and after ironing the heater use, the heater plate will stay on the roller. plate should be raised. The roller and the The item being ironed will then be held there iron cover durability will be increased. -
Page 11: Cleaning And Care
Only use a small quantity of wax. ^ The heater plate must be waxed after each cleaning. Do not get wax on the roller, it will melt and damage the roller cover. See "Miele Ironing Handbook" for further in- formation. - Page 12 Cleaning and Care Discoloration of the ironing cover Applying an ironing cover ^ Raise the heater plate and turn the rotary A slight to heavily brown coloration of the iro- iron off. ning cover is normal. ^ Lay the ironing cover on the roller To avoid the cover from turning black: (parallel).
-
Page 13: After Sales Service
When contacting Technical Service please quote the model (M.-Nr.) and serial number (Fabr.-Nr.) of the machine. These can be found on the silver data plate. Only use original Miele spare parts for main- tenance or repairs on this machine. -
Page 14: Guide To The Data Plate Symbols
Guide to the data plate symbols 15 Electric heating 1 Machine type 2 Serial number/Year of production * 16 Fuse (on site) 3 Voltage/Frequency 17 Steam heating indirect 4 Fuse rating 18 Steam heating direct 5 Drive motor 19 Gas heating 6 Plate diameter/Plate quantity * 20 Commissioning date 21 Water-Registration... -
Page 15: Installation Instructions
Installation Instructions... -
Page 16: Installation Site
Installation instructions Condensate trap The rotary iron should be installed by a Miele trained installer. Installation site Do not operate the rotary iron in a room where cleaning machines are operated with solvents containing CFC. These vapors could damage the machine. -
Page 17: Electrical Connection
Installation instructions Electrical connection All electrical work must be performed by a qualified service technician in accordance with all applicable codes and standards. ^ Regard the data plate, wiring diagram, conversion and installation plan. The wiring diagram is located under the co- ver of the right side column. -
Page 18: Help To Protect The Environment
Help to protect the environment Disposal of the packing materials Disposal of an old appliance The packing materials protect the appliance Old appliances may contain materials that during shipping. They have been designed can be recycled. Please contact your local to be biodegradable and recyclable. - Page 22 All rights reserved / 2509 06 858 370 / 01...
