SPECIFICATIONS AND FEATURES

Operating Frequencies:
Sensitivity:
Signal/Noise Ratio:
Squelch Quieting:
AM Rejection:
Modulation Acceptance:
Image and Spurious Rejection: greater than 100dB
Third Order Intercept:
Audio Outputs:
XLR:
Headphone:
Antenna Input:
Controls:
Indicators:
Power Requirements:
Power consumption:
Battery Life:
Weight:
Dimensions:
Specifications subject to change without notice.
470MHz to 608MHz, crystal controlled
Better than 0.35 uV for 20dB SINAD;
1.5 uV for 50dB S/N ratio
106dB A-weighted
greater than 106dB
-60dB (10uV to 0.1 Volts)
±15kHz
-5 dBm
200 Ohms balanced; 100mV max.
0.6 Volts RMS into 50 Ohms
BNC; 50 Ohms impedance
Front panel attenuator controls XLR output.
Recessed trim-pot controls headphone 3 position
power/function switch.
Red LED for power "ON" (Battery status)
2 LEDs for modulation level
"RF" LED for transmitter "ON"
11.5 to 18VDC external (either polarity)
110 VAC via CH-12 AC adapter
Single 9 Volt alkaline battery
60mA at idle;
70mA at 15kHz deviation, with headphones
5 hours with alkaline
11 ounces including battery
1.1" x 2.75" x 5.2"
Rio Rancho, NM – USA
UHF Compact Receiver
