11

SPECIFICATIONS AND OPTIONS

■ Specifi cations
D GENERAL
• Frequency coverage
• Mode
• Power supply requirement
• Current drain (approximately) : TX (5 W/1.0 W)
• Frequency stability
• Operating temperature range : –20°C to +60°C; –4°F to +140°F
• Dimensions
(projections not included)
• Weight
(including battery pack, antenna and belt clip)
D TRANSMITTER
• Output power
• Modulation system
• Maximum frequency deviation : ±5 kHz
• Adjacent channel power
• Spurious emissions
• Residual modulation
• Audio frequency response
D RECEIVER
• Receive system
• Intermediate frequency
• Sensitivity (12 dB SINAD)
• Squelch sensitivity
• Intermodulation
• Spurious response
• Adjacent channel selectivity
• Audio output impedance
• Audio output power
28 All stated specifi cations are subject to change without notice or obligation.
: Transmit 156.025–157.425 MHz
Receive 156.050–163.275 MHz
: FM (16K0G3E)
: BP-266 only
2.3 A/0.9 A
Max. audio 0.35 A typical
Power save 8 mA typical
: ±10 ppm
: 58.5 (W) × 128.5(H) × 34.5(D) mm
(W) × 5 (H) × 1
5 19 11
2 ⁄ ⁄ ⁄ (D) inch
16 32 32
: Approximately 260 g; 9.2 oz
: 5 W (approximately; High) and 1 W (Low)
: Variable reactance frequency modulation
: 70 dB
: –68 dBc typical
: 40 dB
: +1 dB to –3 dB of 6 dB oct. from 300–3000 Hz
: Double-conversion superheterodyne
: 1st 21.7 MHz, 2nd 450 kHz
: 0.25 µV typical
: 0.35 µV typical (at threshold)
: 70 dB typical
: 70 dB typical
: 70 dB typical
: 8 Ω
: 0.6 W typical (at 10% distortion)

■ Options

D BATTERY PACK
• BP-266 -
i ion
L BATTERY PACK
Voltage/Capacity : 3.7 V/1500 mAh (minimum), 1590 mAh (typical)
D CHARGERS
• BC-199S
AC ADAPTER
For regular charging of the battery pack.
Charging time : Approximately 8.5 hours
• BC-119N + AD-123
DESKTOP CHARGER
+ BC-145S
AC ADAPTER
For rapid charging of the battery pack. The AC adapter, BC-145S, is not sup-
plied with some versions.
Charging time : Approximately 2.5 hours
• BC-121N - + AD-123
MULTI CHARGER CHARGER ADAPTER
For simultaneously rapid charging up to six battery packs (six AD-123s are
required). An AC adapter must be separately purchased.
Charging time : Approximately 2.5 hours
D OTHER OPTIONS
• FA-SC58V
ANTENNA
• MB-124
BELT CLIP
• CP-24
CIGARETTE LIGHTER CABLE
• CP-23L
CIGARETTE LIGHTER CABLE
For BC-119N
• OPC-515L
DC POWER CABLE
For BC-119N
Approved Icom optional equipment is designed for optimal performance when
used with an Icom transceiver. Icom is not responsible for the destruction or
damage to an Icom transceiver in the event the Icom transceiver is used with
equipment that is not manufactured or approved by Icom.
Some options may not be available in some countries. Please ask your dealer
for details.
CHARGER ADAPTER
+ BC-157S
AC ADAPTER
