- Page 1 Laptop USB KVM Switch USER MANUAL CS661...
-
Page 2: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. -
Page 3: Online Registration
CS661 User Manual Online Registration You can register your product at our online support center: International http://support.aten.com North America ATEN TECH http://www.aten-usa.com/ product_registration ATEN NJ http://support.aten.com Online Support International Email Support support@aten.com Online Technical Support http://support.aten.com Support Troubleshooting http://www.aten.com Documentation... -
Page 4: Package Contents
Copyright © 2008–2010 ATEN International Co., Ltd. Manual Part No. PAPE-1285-N01G Manual Date: 2010-03-22 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 Overview The CS661 Laptop USB KVM Switch takes a giant step forward from previous cable KVM models in the Petite series. In addition to offering simple USB-to-USB plug and play KVM* switch functionality for two USB-enabled PCs or laptops running...
-
Page 6: System Requirements
System Requirements Two complete computer/laptop systems running Microsoft Windows. See Operating Systems, below. Note: 1. The CS661 only controls two complete systems. It cannot be used to control two standalone PCs (without keyboards or mice) through one console in the same way as a typical KVM switch. -
Page 7: A Note About Terminology
Features Laptop USB KVM Switch with File Transfer functionality and USB 2.0 support Dual PC control (KVM functionality) – allows you to control both your Local computer/laptop and a Remote computer/ laptop via the Local computer 1-port USB 2.0 hub built in – allows the Local computer to connect to a USB 2.0 peripheral Compact design, built-in all-in-one USB 2.0 cables –... - Page 8 Components 1.8 m 0.9 m Local Remote (Blue) (Yellow) Component Description USB Connector This connects to the USB port on the (Blue) Remote computer. LED Display Flashes blue at a slow, steady pace when there is a working connection between the Local and Remote computers and the device is idle.
-
Page 9: Installation
1. Make sure that all devices you will be installing are properly grounded. Setting up the CS661 is quick and easy, offering simple plug and play functionality in just a few short steps. Numbers 1–3 below refer to the diagram on the following page: 1. -
Page 10: Installation Diagram
Installation Diagram Local Remote Note: Both the Local and Remote systems must be running Microsoft Windows OS. - 10 -... -
Page 11: Operation
Operation Toolbar The CS661 User Interface provides a convenient toolbar in the top left of the Remote desktop window. Toolbar buttons are as follows (see the table following for further details): Toolbar Buttons Name Function Open File Transfer Opens the File Transfer utility. (See Transferring... - Page 12 Desktop Scaling When the CS661 is operational, the desktop environment of the Remote computer appears in its own window on the desktop of the Local computer. The CS661’s innovative desktop scaling feature offers the options of a full-screen or sizable (by ratio) remote desktop window.
- Page 13 USB 2.0 Hub The CS661 Laptop USB KVM Switch is a full-featured 1-port USB 2.0 hub, offering the Local computer effortless control of any USB 2.0 peripheral device connected to the CS661. Note: When connecting USB 2.0 mass storage devices to the CS661’s USB 2.0 hub, it is recommended that an external...
-
Page 14: File Management
File Management Transferring Files The CS661 provides a complete file management feature that includes an intuitive File Transfer utility that makes it quick and easy to transfer files between the Local and Remote computers. 1. In the Remote desktop window on the Local computer’s monitor, click the Open File Transfer icon. -
Page 15: Other File Management Features
History bar will tell you when the file transfer has completed. Other File Management Features In addition to File Transfer, the CS661’s User Interface also offers a full range of file system management features, such as creating, renaming, and deleting files and folders on both the Local and the Remote computers. - Page 16 1. Download the latest CS661 AP Upgrade Utility from the ATEN website (www.aten.com). 2. Connect the CS661 to the Local PC and double click on the AP Upgrade Utility. In the dialog box that appears, click Start to execute the upgrade.
-
Page 17: Troubleshooting
CS661 the other way round. Note: If you plug in CS661 the other way round, the Local computer/laptop will become the Remote computer/laptop, and vice versa. Does the CS661 All the CS661’s KVM and file management... - Page 18 If you reboot either your Local or Remote computer, the computer/laptop, the CS661 utility will be offline. attached CS661 Unplug the CS661 and then replug it into the USB does not function. ports on both computers. The utility will then will be operational.
-
Page 19: Specifications
Specifications Function CS661 Computer Connections Connectors Local Port 1 x USB Type A Male (Yellow) Remote Port 1 x USB Type A Male (Blue) LEDs On Line 1 (Blue) Data Transfer 1 (Blue) USB Hub 1 x USB 2.0 Port Environment Operation Temp. -
Page 20: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
