- Page 1 USB 2.0 DVI KVM Switch USER MANUAL CS682...
-
Page 2: Emc Information
EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 Telephone Support International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For North American technical support: Email Support support@aten-usa.com...
-
Page 4: Package Contents
Copyright © 2019 ATEN International Co., Ltd. Manual Date: 2019-11-15 - Manual Part No. PAPE-1337-AT5G ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 Overview The CS682 takes a giant step forward from prior cable KVM models in the Petite series, by offering DVI functionality, USB 2.0 peripheral sharing (via a USB hub attached to the USB mouse port), a rich bass experience for 2.1 surround systems, and a firmware upgrade function that allows you to keep up with latest available versions.
- Page 6 Superior video quality – up to 1920 x 1200 Compatible with widescreen LCD monitors Video DynaSync – exclusive ATEN technology which eliminates boot-up display problems and optimizes resolution when switching between ports Power on detection – if either of the computers is powered off, the CS682 will automatically switch to the other computer ...
-
Page 7: System Requirements
3. To use the USB 2.0 mouse port as a USB hub, you must first disable mouse emulation mode. See Hotkey Summary Table, page 15 for information. System Requirements Console A DVI monitor capable of the highest resolution that you will be using on any computer in the installation ... -
Page 8: Operating Systems
Operating Systems Supported operating systems are shown in the table, below: Version Windows 2000 / XP / Vista / 7 Linux RedHat 6.0 and higher SuSE 8.2 and higher Mandriva (Mandrake) 9.0 and higher UNIX 4.3 and higher FreeBSD 3.51 and higher Solaris 9 and higher Novell Netware... - Page 9 Components CS682 Remote Port Selector - 9 -...
- Page 10 Component Description Console Audio Ports Your console speakers and microphone plug in here. Console Monitor Port Your console DVI monitor plugs in here. Port LEDs The Port LEDs indicate status. The LED lights on to indicate that the computer attached to the corresponding port is selected and has the KVM focus.
-
Page 11: Installation
Installation 1. Make sure that the power to any device that you connect to the installation has been turned off. You must unplug the power cords of any computers that have the Keyboard Power On function. 2. To prevent damage to your installation from power surges or static electricity. -
Page 12: Installation Diagram
Installation Diagram USB 2.0 Hub KVM Cable - 12 -... -
Page 13: Operation
Operation The CS682 provides three convenient methods of selecting computers: Manual – click the pushbutton on the Remote Port Selector; Mouse – click the mouse’s scroll wheel; and Hotkey – enter combinations from the keyboard. Manual Port Selection Press the port selection pushbutton on the Remote Port Selector to toggle the KVM and Audio focus between the two computers. -
Page 14: Hotkey Port Selection
Hotkey Port Selection All hotkey operations begin by tapping the Scroll Lock key twice. See the Hotkey Summary Table for full details. Note: If using [Scroll Lock] conflicts with other programs, [Ctrl] can be used instead. Alternate Entering Hotkey Mode ... -
Page 15: Hotkey Summary Table
Hotkey Summary Table Combination Function [Scroll [Enter] Toggles the KVM and Audio focus between the two Lock] ports. If the KVM and Audio focus are on different [Scroll ports, only the KVM focus switches. Lock] + [k] [Enter] Only toggles the KVM focus. [s] [Enter] Only toggles the Audio focus. -
Page 16: Keyboard Emulation
Keyboard Emulation PC Keyboard Mac Keyboard PC Keyboard Sun Keyboard [Shift] Shift [Ctrl] [T] Stop [Ctrl] Ctrl [Ctrl] [F2] Again [Ctrl] [F3] Props [Ctrl] [1] [Ctrl] [F4] Undo [Ctrl] [2] [Ctrl] [F5] Front [Ctrl] [3] [Ctrl] [F6] Copy [Ctrl] [4] [Ctrl] [F7] Open [Alt]... -
Page 17: The Firmware Upgrade Utility
1. From a computer that is not part of your KVM installation, download the latest Firmware Upgrade package for the CS682 from our Internet support site ( www.aten.com 2. Disconnect the CS682 from your KVM installation. Press and hold the Remote Port Selector’s pushbutton. While you are still holding the pushbutton, connect the KVM cable’s purple... -
Page 18: Upgrade Failed
Upgrade Failed If the Upgrade Succeeded screen doesn’t appear, it means that the upgrade failed to complete successfully, in which case you should do the following: 1. Disconnect the USB connectors on the KVM cables from the computer. 2. Press and hold the Remote Port Selector’s pushbutton. While you are still holding the pushbutton, reconnect the KVM cable’s USB connectors to the computer. -
Page 19: Specifications
Specifications Function CS682 Computer Connections Console Connections Port Selection Remote Port Selector, Mouse, Hotkeys Connectors Console 1 x USB Type A Female (Silver) Ports Video 1 x DVI-D Female (White) Mouse 1 x USB Type A Female (Silver) Speakers 1 x Mini Stereo Jack Female (Green) Mic. -
Page 20: Factory Default Hotkey Settings
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
