Page 1: Ceiling Fan
113 102 Gazebo II Ceiling Fan Owner’s Manual Gazebo II Ventilador de Techo de 1,07 Manual del Propietario... -
Page 2: Table Of Contents
Thank you for purchasing our ceiling fan. This product has been manufactured with the highest standards of safety and quality. The finish of this fan is weather resistant, but over time will Ceiling Fan by Hampton Bay naturally weather and fade. Date Purchased... -
Page 3: Safety Rules
Safety Rules – Read and Save These Instructions To reduce the risk of electric shock, insure electricity has been turned off After making electrical connections, spliced conductors should be turned at the circuit breaker or fuse box before beginning. upward and pushed carefully up into outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding All wiring must be in accordance with the National Electrical Code conductor on one side of the outlet box and ungrounded conductor on the... -
Page 4: Unpacking Your Fan
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items: Set of blades (5) Fan motor assembly Blade attachment hardware (16 screws with rubber washers) Canopy assembly Set of blades arms (5) Electrical hardware Ball/downrod assembly Pull chain and fob (3 plastic wire nuts) -
Page 5: Installing Your Fan
Installing Your Fan Provide Strong Support Tools Required Figures 1~3 are examples of different ways to mount the outlet box. Phillips screwdriver, straight slot screwdriver, step ladder and wire cutters. Recessed Ceiling Outlet Box Mounting Plate Mounting Options Figure 3 Outlet Box Note: You may need a longer downrod to If there isn't an existing UL listed mounting box,... -
Page 6: Hanging The Fan
Hanging the Fan Motor Wires Remove the Pin in Locked Canopy Ring Positioon Ball/Downrod REMEMBER to turn off the power. Follow the Assembly steps below to hang your fan properly. Ceiling Canopy NOTE: This ceiling fan is supplied with two types Canopy Ring of hanging assemblies;... - Page 7 NOTE: If a longer downrod is needed, take out Remove the decorative canopy bottom cover Motor the screw located in the hanger ball, lower the from the canopy by turning the canopy bottom Collar Screw and Lock Washer hanger ball and remove the pin, remove all 3 cover counterclockwise (Figure 8).
-
Page 8: Installing Fan To The Electrical Box
Installing Fan to UL Listed Outlet Box the Electrical Box WARNING 120V TO REDUCE THE RISK OF FIRE, ELECTRIC Wires SHOCK OTHER PERSONAL INJURY. MOUNT FAN ONLY TO AN OUTLET BOX OR SUPPORTING SYSTEM MARKED ACCEPTABLE Groove FOR FAN SUPPORT AND USE THE MOUNTING Ceiling Mounting SCREWS PROVIDED WITH THE OUTLET BOX. - Page 9 Making the Electrical Connect the fan motor black wire to the supply SUPPLY CIRCUIT black (hot) wire using a wire nut (Figure 13). Connections Connect the blue wire for light kit to the black Ground REMEMBER to disconnect the power. household supply wire.
-
Page 10: Standard Ceiling Mounting
Finishing the Fan Close-to-Ceiling Mounting Installation Remove the fan from the tab on the hanger Outlet Box bracket. Secure the canopy to the hanger bracket Standard Ceiling Mounting with four screws included with your fan. (Fig. 15) Hanger Raise up canopy ring and line up the 4 tabs with Screws WARNING Bracket... -
Page 11: Attaching The Fan Blades
Attaching the Fan Blades NOTE Motor MOTOR IS SHIPPED WITH RUBBER MOTOR STOPS TO PREVENT MOVEMENT DURING TRANSPORTA- TION. REMOVE MOTOR STOPS PRIOR TO ATTACH- ING BLADE BRACKETS. (FIG. 16) Blade arm Slot Step 1. Attach blades to blade arms using three Rubber packing mounts screws with rubber washers. -
Page 12: Blade Balancing
Blade Balancing The following procedure should correct most fan wobble. Check after each step. Touching Ceiling Check that all blade and blade arm screws are secure. Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling above the tip of one of the blades. -
Page 13: Operating Your Fan
Operating Your Fan WARNING LOCKING SLOTS OF CEILING CANOPY ARE Warm weather - (Counter Clockwise Direction) PROVIDED ONLY AS AN AID TO MOUNTING. DO NOT LEAVE FAN ASSEMBLY UNATTENDED A downward air flow creates a cooling effect as UNTIL ALL FOUR CANOPY SCREWS ARE shown in Figure 20. -
Page 14: Care Of Your Fan
Care of Your Fan Troubleshooting PROBLEM SOLUTION Here are some suggestions to help you maintain your fan. Fan will not start Check main and branch circuit fuses or breakers. Because of the fan's natural movement, some Check line wire connections to the fan and switch wire connections may become loose. -
Page 15: Specifications
Specifications FAN SIZE SPEED VOLTS AMPS WATTS N.W. G.W. C.F. 0.19 1812 42” 6.3 kgs 7.2 kgs MED. 1.30' 0.32 3267 (107cm) (13.9 lbs) (15.8 lbs) HIGH 0.40 4130 These are approximate measures. They do not include Amps and Wattage used by the light kit . -
Page 16: Warranty Information
Lifetime Limited Warranty (lifetime warranty on motor) The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time You must present a copy of the original purchase receipt to obtain warranty of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
