PARTS AND SERVICE
This product has been expertly en gi neered and carefully manu fac tured to rigid quality stan dards. As with all
mechanical products, some adjustments or part replacement may be necessary during the life of your unit.
For Parts and service, contact our authorized distributor: call 1-800-849-1297
•
For replacement parts, have available the following information:
a.
Model Number/Manufacturer's I.D. Number
b.
Description of part.
For Technical Assistance: call 1-800-829-5886
For a Parts Manual, go to our website: www.weedeater.com
NOTE:
HOP provides parts and service through its au thor ized dis tribu tors and dealers; there fore,
all requests for parts and service should be directed to your local dealer(s). The phi loso phy
of HOP is to con tinu ally improve all of its prod ucts. If the operating characteristics or the
appearance of your product differs from those described in this Manual, please contact
your local dealer for updated in for ma tion and as sis tance.
03.14.11 CL/TH
Printed in the U.S.A.
Owner's Manual
30" RIDING MOWER
SIDE DISCHARGE
ELECTRIC START
Catalog No.
WELRVBA30
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The
use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
532 44 19-83 Rev. 5
IMPORTANT:
Read and follow all Safety
Rules and Instructions before
op er at ing this equipment.
Patents Pending
Advertisement
Table of Contents
Related Manuals for Weed Eater WELRVBA
Summary of Contents for Weed Eater WELRVBA
-
Page 1: Parts And Service
Owner's Manual 30" RIDING MOWER SIDE DISCHARGE ELECTRIC START PARTS AND SERVICE This product has been expertly en gi neered and carefully manu fac tured to rigid quality stan dards. As with all mechanical products, some adjustments or part replacement may be necessary during the life of your unit. For Parts and service, contact our authorized distributor: call 1-800-849-1297 •... -
Page 2: Table Of Contents
TABLE OF CONTENTS SERVICE NOTES Warranty ..........2 Maintenance ......... 17 Safety Rules ........... 3 Service and Adjustments ...... 21 Product Specifications ......6 Storage ..........25 Assembly/Pre-Operation ......7 Troubleshooting ........26 Operation ..........10 Repair Parts .......... 29 Maintenance Schedule ...... -
Page 3: Safety Rules
SERVICE NOTES SAFETY RULES DANGER: This cutting machine is ca pa ble of amputating hands and feet and throwing objects. Failure to observe the fol low ing safety instructions could result in serious injury or death. • Never direct discharged material toward WARNING: In order to prevent ac ci- anyone. - Page 4 SAFETY RULES II. SLOPE OPERATION III. CHILDREN Slopes are a major factor related to loss of Tragic accidents can occur if the operator control and tip-over accidents, which can is not alert to the presence of children. result in severe injury or death. Operation Children are often attracted to the machine on all slopes requires extra caution.
- Page 5 RIDING MOWER MODEL NUMBER WELRVBA (96026000100) SAFETY RULES PRODUCT NUMBER 960 26 00-01 DECALS • Never fill containers inside a vehicle or on a truck or trailer bed with plastic liner. Always place containers on the ground away from your vehicle when filling.
-
Page 6: Product Specifications
RIDING MOWER MODEL NUMBER WELRVBA (96026000100) PRODUCT SPECIFICATIONS PRODUCT NUMBER 960 26 00-01 MOWER DECK CUSTOMER RESPONSIBILITIES PRODUCT SPECIFICATIONS • Read and observe the safety rules. Gasoline Capacity 1.5 Gallons • Follow a regular schedule in main tain- and Type: Unleaded Regular ing, caring for and using your tractor. -
Page 7: Assembly/Pre-Operation
RIDING MOWER MODEL NUMBER WELRVBA (96026000100) ASSEMBLY/PRE-OPERATION PRODUCT NUMBER 960 26 00-01 MOWER DECK Your new riding mower has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your riding mower all parts and hardware you as sem ble must be tightened securely. - Page 8 INSTALL SEAT LUMBAR SUPPORT - RIDING MOWER MODEL NUMBER WELRVBA (96026000100) PRODUCT NUMBER 960 26 00-01 1. Remove bolt and flat washer se cur ing • Loosen lumbar adjustment knob. STEERING seat to cardboard packing and set aside • Slide seat back up or down to most com- for as sem bly of seat to riding mower.
- Page 9 ✓ RIDING MOWER MODEL NUMBER WELRVBA (96026000100) CHECK TIRE PRESSURE PRODUCT NUMBER 960 26 00-01 CHECKLIST The tires on your riding mower were overin- STEERING flated at the factory for shipping purposes. Before you operate your new riding mower, Correct tire pressure is important for best we wish to assure that you receive the best cutting performance.
-
Page 10: Operation
RIDING MOWER MODEL NUMBER WELRVBA (96026000100) OPERATION PRODUCT NUMBER 960 26 00-01 DRIVE These symbols may appear on your riding mower or in literature supplied with the product. Learn and understand their meaning. KEY PART KEY PART REVERSE HIGH FAST... - Page 11 RIDING MOWER MODEL NUMBER WELRVBA (96026000100) KNOW YOUR RIDING MOWER PRODUCT NUMBER 960 26 00-01 READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING DRIVE YOUR RIDING MOWER Compare the illustrations with your riding mower to familiarize yourself with the locations of various controls and ad just ments.
- Page 12 RIDING MOWER MODEL NUMBER WELRVBA (96026000100) The op er a tion of any riding mower can result in foreign objects thrown PRODUCT NUMBER 960 26 00-01 into the eyes, which can result in severe eye dam age. Al ways wear...
- Page 13 RIDING MOWER MODEL NUMBER WELRVBA (96026000100) TO USE THROTTLE CONTROL • The average lawn should be cut to ap- PRODUCT NUMBER 960 26 00-01 proximately 2-1/2" during the cool season Always operate engine at full speed (fast). CHASSIS and to over 3" during hot months. For •...
- Page 14 REVERSE OPERATION SYSTEM (ROS) Hinge Bracket RIDING MOWER MODEL NUMBER WELRVBA (96026000100) PRODUCT NUMBER 960 26 00-01 Your riding mower is equipped with a Reverse ELECTRICAL Operation System (ROS). Any attempt by the operator to travel in the reverse direc-...
- Page 15 RIDING MOWER MODEL NUMBER WELRVBA (96026000100) BEFORE STARTING THE ENGINE TO START ENGINE PRODUCT NUMBER 960 26 00-01 CHECK ENGINE OIL LEVEL When starting the engine for the first time or ELECTRICAL if the engine has run out of fuel, it will take...
- Page 16 MOWING TIPS RIDING MOWER MODEL NUMBER WELRVBA (96026000100) PRODUCT NUMBER 960 26 00-01 • Mower should be properly leveled for best SCHEMATIC mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. • The left hand side of mower should be...
-
Page 17: Maintenance Schedule
SERVICE NOTES MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blade Clean Battery and Terminals Lubricate Axles and Spindles Clean Friction Surfaces Check Mower Levelness... - Page 18 RIDING MOWER CHECK REVERSE OPERATION (ROS) TROUBLESHOOTING CHART: SYSTEM Always observe safety rules when per form ing See ap pro pri ate section in manual un less di rect ed to service center. any main te nance. • When the engine is running with the ignition PROBLEM CAUSE CORRECTION...
- Page 19 TROUBLESHOOTING CHART: BATTERY TO CHANGE ENGINE OIL Your riding mower has a battery charging See ap pro pri ate section in manual un less di rect ed to service center. Determine temperature range expected sys tem which is suf fi cient for normal use. before oil change.
-
Page 20: Storage
AIR FILTER MUFFLER STORAGE Your engine will not run properly using a Inspect and replace corroded muffler and dirty air filter. Service air cleaner more often spark arrester (if equipped) as it could create under dusty conditions. See engine manual. a fire hazard and/or dam age. -
Page 21: Service And Adjustments
TO START ENGINE WITH A WEAK INTERLOCKS AND RELAYS SERVICE AND ADJUSTMENTS Loose or damaged wiring may cause your BAT TERY riding mower to run poorly, stop running, or CAUTION: Lead-acid batteries gen er- prevent it from starting. ate ex plo sive gases. Keep sparks, flame WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY •... -
Page 22: Mower Drive Belt Removal
TO LEVEL MOWER HOUSING FRONT-TO-BACK ADJUSTMENT TO REPLACE MOWER BLADE DRIVE TO ADJUST STEERING WHEEL BELT ALIGNMENT Adjust the mower while riding mower is IMPORTANT: Deck must be level side-to If steering wheel crossbars are not horizontal parked on level ground or driveway. Ensure side.
