OPERATING MANUAL
5" RANDOM ORBIT SANDER
241-0972
IMPORTANT:
Carefully read this operating manual before using your new tool. Pay close
attention to all Safety Instructions, Warnings and Caution sections. Use your
tool properly and only for its intended use.
Safety symbols in this manual are used to call attention to possible dangers.
The safety symbols and their explanations require the operator's full understand-
ing. The safety warnings do not, by themselves, eliminate any danger, nor are
they a substitute for proper accident-prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to the operator or to others. To
reduce the risk of injury, fire, or electric shock, always follow the safety precau-
tions.
10-06-17 manual 241-0972 En.indd
1
2010-6-18
12:00:01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Performax 5” RANDOM ORBIT SANDER
Summary of Contents for Performax 5” RANDOM ORBIT SANDER
- Page 1 OPERATING MANUAL 5” RANDOM ORBIT SANDER 241-0972 IMPORTANT: Carefully read this operating manual before using your new tool. Pay close attention to all Safety Instructions, Warnings and Caution sections. Use your tool properly and only for its intended use. Safety symbols in this manual are used to call attention to possible dangers. The safety symbols and their explanations require the operator’s full understand- ing.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Specifications ................. Page 2 Rules for Safe Operation ..............Page 5 Description ..................Page 9 Assembly and Adjustment ............... Page10 Operation ..................Page11 Maintenance ................... Page13 Accessories ..................Page14 Warranty ..................Page14 SPECIFICATIONS Motor: 120V, 60Hz, 2.0A No load speed: 12000 OPM Pad size:... - Page 3 SAFTEY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warning they give are no substitutes for proper accident prevention measures.
- Page 4 SAFETY SYMBOLS FOR YOUR TOOL The label on your tool may include thefollowing symbols Volts Amps Hertz Watts minutes Alternating current Direct current No load speed Class II construction,Double insulated .../min Revolutions or Strokes per minute Indicates danger,warning or caution. It means attenti on!Your safety is involved Wet Conditions Alert: Do not expose to rain or use in damp locations...
-
Page 5: Rules For Safe Operation
RULES FOR SAFE OPERATION KNOW THE TOOL To operate this tool, carefully read this Owner’s Manual and all labels affixed to the sander before using. Keep this Manual available for future reference. IMPORTANT This tool should only be serviced by a qualified service technician. For more information, call the toll-free helpline, 1-866-858-2664. - Page 6 Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords immediately. Damaged cords increase the risk of electric shock. When operating a power tool outside, use an outdoor extension cord marked “W-A”...
- Page 7 Do not force the tool. Use the correct tool for your application. The correct tool will do the job better and more safely at the rate for which is designed. Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled with the switch is dangerous and must be repaired.
- Page 8 Unplug the sander before changing accessories. Accidental start-ups may occur if sander is plugged in while changing an accessory. Always wear safety goggles and dust mask when sanding, especially when sanding overhead. A suitable breathing respirator must be worn while sanding chemically pressure treated objects.
-
Page 9: Description
DESCRIPTION KNOW YOUR SANDER(Fig. 1) Before attempting to use this sander, familiarize yourself with all its operating features and safety requirements. WARNING: Do not allow familiarity with your sander to make you care- less. Remember that a careless fraction of a second is sufficient enough to inflict severe injury. -
Page 10: Assembly And Adjustment
ASSEMBLY AND ADJUSTMENTS Remove the random orbit sander from the carton and examine it carefully. Do not discard the carton or any packaging material until all parts are examined. NOTE: If any part of the random orbit sander is missing or damaged, do not plug the sander in until the damaged part is repaired or replaced. - Page 11 ROCKER ON/OFF SWITCH This random orbit sander is equipped with a dust-sealed ON/OFF rocker switch, located on the front of the handle. 1. To turn the sander ON, depress the rocker switch to the “I” position. 2. To turn the tool OFF, depress the rocker switch to the “O” position. GENERAL SANDING WARNING: Finish sanding can produce clouds of fine sanding dust that could ignite in the presence of sparks or an open flame.
- Page 12 REMOVING PAINT OR VARNISH 1. If removing several layers of paint or varnish, first remove as much as possible with a paint or varnish remover. 2. Scrape the residue off with a putty knife or scraping tool and allow the surface to cool and dry before sanding.
-
Page 13: Maintenance
Coarse Grit 60–80 Initial sanding on rougher surfaces. For fast stock removal. Rough sanding and stripping of painted and rusted surfaces. Medium Grit 100–140 Intermediate sanding. Removal of minor surface imperfections. Fine Grit 150–220 Fine sanding. Sanding prior to staining, priming, or sealing. MAINTENANCE WARNING: To ensure safety and reliability, all repairs should be per- formed by a qualified service technician. -
Page 14: Accessories
Dust Bag....................1pc 80 Grits sandpaper...................3pcs WARRANTY If, during normal use, this PERFORMAX power tool breaks or fails due to a defect in material or workmanship within two years from the date of original purchase, simply bring this tool and its sales receipt back to your nearest Menards retail ®... - Page 15 10-06-17 manual 241-0972 En.indd 2010-6-18 12:00:06...
- Page 16 10-06-17 manual 241-0972 En.indd 2010-6-18 12:00:06...
