- Page 1 GEBRUIKERSHANDLEIDING/ USER’S MANUAL BETRIEBSANLEITUNG / MODE D’EMPLOI MASS SINE 12/500 SINE WAVE H.F. - 230V & 117V models MASTERVOLT Snijdersbergweg 93, 1105 AN Amsterdam The Netherlands Tel.: +31-20-3422100 V1. March 2000 Fax: +31-20-6971006 www.mastervolt.com...
-
Page 2: Table Of Contents
TROUBLE SHOOTING ..............28 March 2000 / MASS Sine 12/500/ EN... - Page 3 EC DECLARATION OF CONFORMITY ........... . .38 EN / MASS Sine 12/500 / March 2000...
-
Page 4: General Information
CAREFUL ! GARANTEE SPECIFICATIONS Never remove the type number plate. Mastervolt quarantees that this unit has been built according to the legally applicable standards and Important technical information required for service, specifications. Should work take place, which is not maintenance & secondary delivery of parts can be in accordance with the guidelines, instructions and derived from the type number plate. -
Page 5: Safety Guidelines And Measures
Mastervolt is not liable for any damage resul- 3 Check the wiring at least once a year. Defects ting from failure to comply with the above. -
Page 6: Warning Regarding Life Support Applications
In addition such manufactu- rer must agree to indemnify Mastervolt from any claims arising from the use of Mastervolt parts in the life support equipment. March 2000 / MASS Sine 12/500/ EN... -
Page 7: Operation
Fig. 1: Mass Sine 12/500 indicator lights. EN / MASS Sine 12/500 / March 2000... -
Page 8: Trouble Shooting
This wait-state gives the battery ti- me to recover. If you cannot correct a problem with the aid of the malfunction table, contact your MASTERVOLT Service Center or MASTERVOLT Amsterdam for an extended service list, tel: INT+ 31-20-3422100. March 2000 / MASS Sine 12/500/ EN... -
Page 9: Maintenance
• Keep the inverter dry, clean and dust-free, in order to ensure good heat discharge. • Check the fan operation (has a lifetime of at least 10 years in normal use). EN / MASS Sine 12/500 / March 2000... -
Page 10: Technical Data
< 95% relative humidity, non condensing ENCLOSURE Dimensions (hxwxd) 310 x 190 x 100 mm (see fig. 3) Weight 3 kg Protection degree IP 23 STANDARDS Emmission EN 50081-1:1992 Immunity EN 50082-1:1992 Safety IEC 950 March 2000 / MASS Sine 12/500/ EN... -
Page 11: Technology
Mas- tervolt Amsterdam. The MASS SINE inverter is part of a series advanced quality battery chargers and in- verters supplied by Mastervolt all over the world. The MASS SINE inverter converts DC voltage to 230V AC, 50 Hz*. -
Page 12: Installation
Type: Mass Sine 12/500 and cables. Part no: 012020500 Input: 12V DC (10 ... 16V) Output: 230V 50Hz sine wave Output power: 500VA Fig. 2: Type number plate. March 2000 / MASS Sine 12/500/ EN... -
Page 13: Mounting Of The Cabinet
3 Mount the MASS inverter with four screws or bolts (M6) to the wall. 2 Drill mounting holes for the cabinet. 4 Fasten all screws or bolts securely. Low batt. Temp Fig. 3: Dimensions of the Mass Sine 12/500. EN / MASS Sine 12/500 / March 2000... -
Page 14: Connecting
Keep the cable length as short as possible, this will keep the system efficiency as high as possible. The recommended minimum size of the battery cables is: cable thickness 25 mm March 2000 / MASS Sine 12/500/ EN... -
Page 15: Connecting The Remote Control Panel
The LED 'failure' indicates overload, over- temperature or too low voltage. C4-RI, remote control panel. Afb. 4: Connection of the Mass Sine 12/500. Afb. 5: Connection cable for panel C4-RI (not delivered as a standard). EN / MASS Sine 12/500 / March 2000... -
Page 16: Commissioning After Installation
250W. The output voltage will be to 230V if the load connected to the inverter rises Please contact your Mastervolt supplier if you intend above the 250W. to use the inverter with a genset or shore power connection. - Page 17 230V low power 208V < 30W economic 208V < 250W stand by 0V, switches on at load Fig. 6: Position of the jumpers at the MASS Sine 12/500. EN / MASS Sine 12/500 / March 2000...
-
Page 18: List Of Key Words
Conform with the provision of the EC EMC directive 89/336/EEC and amendments 92/31/EEC, 93/68/EEC. The following harmonized standards have been applied: Generic emission standard EN 50081-1:1992 Generic immunity standard EN 50082-1:1992 Amsterdam, Dr. F.J. ter Heide, Managing director Mastervolt March 2000 / MASS Sine 12/500/ EN... - Page 19 EN / MASS Sine 12/500 / March 2000...
