LGR-5320 Series User's Guide
Pin Signal name
1 CH0
2 AGND
3 CH8
4 AGND
5 CH1
6 AGND
7 CH9
8 AGND
9 CH2
10 AGND
11 CH10
12 AGND
13 CH3
14 AGND
15 CH11
16 AGND
17 RSVD
18 CTR0
19 RSVD
20 UPDN0
21 RSVD
22 GATE0
23 RSVD
24 GND
25 RSVD
26 CTR1
27 RSVD
28 UPDN1
29 RSVD
30 GATE1
31 RSVD
32 GND
33 RSVD
34 CTR2
35 RSVD
36 UPDN2
37 RSVD
38 GATE2
39 RSVD
40 GND
41 RSVD
42 CTR3
43 RSVD
44 UPDN3
45 RSVD
46 GATE3
47 RSVD
48 GND
Table 21. LGR-5325 16-channel single-ended mode pinout
Pin description Pin
Channel 0 96
Analog ground 95
Channel 8 94
Analog ground 93
Channel 1 92
Analog ground 91
Channel 9 90
Analog ground 89
Channel 2 88
Analog ground 87
Channel 10 86
Analog ground 85
Channel 3 84
Analog ground 83
Channel 11 82
Analog ground 81
Reserved 80
Counter 0 input 79
Reserved 78
Up/down 0 input 77
Reserved 76
Gate 0 input 75
Reserved 74
Digital ground 73
Reserved 72
Counter 1 input 71
Reserved 70
Up/down 1 input 69
Reserved 68
Gate 1 input 67
Reserved 66
Digital ground 65
Reserved 64
Counter 2 input 63
Reserved 62
Up/down 2 input 61
Reserved 60
Gate 2 input 59
Reserved 58
Digital ground 57
Reserved 56
Counter 3 input 55
Reserved 54
Up/down 3 input 53
Reserved 52
Gate 3 input 51
Reserved 50
Digital ground 49
Signal name Pin description
AGND Analog ground
CH15 Channel 15
AGND Analog ground
CH7 Channel 7
AGND Analog ground
CH14 Channel 14
AGND Analog ground
CH6 Channel 6
AGND Analog ground
CH13 Channel 13
AGND Analog ground
CH5 Channel 5
AGND Analog ground
CH12 Channel 12
AGND Analog ground
CH4 Channel 4
EGND Chassis ground
AGND Analog ground
ATRIG Analog trigger input
GND Digital ground
DTRIG Digital trigger
PACER Pacer I/O
PWR– Input ground
PWR+ Input power
NC Relay normally closed contact
COM Relay common contact
NO Relay normally open contact
GND Digital ground
RSVD Reserved
GND Digital ground
GND Digital ground
GND Digital ground
DIN15 Digital input 15
DIN14 Digital input 14
DIN13 Digital input 13
DIN12 Digital input 12
DIN11 Digital input 11
DIN10 Digital input 10
DIN9 Digital input 9
DIN8 Digital input 8
DIN7 Digital input 7
DIN6 Digital input 6
DIN5 Digital input 5
DIN4 Digital input 4
DIN3 Digital input 3
DIN2 Digital input 2
DIN1 Digital input 1
DIN0 Digital input 0
39
Specifications
