1
Quick Setup Guide
LEDs

Power Connectors

+12V
Ground
2
4
1
3
Ground
+12V
Important:
To ensure that adequate power is provided, we strongly recommend
that you use a minimum of 400 Watt (or greater) power supply.
12
DRAM
Power LED
Standby
Power LED
1 3 1
+3.3VDC
+3.3VDC
-12VDC +3.3VDC
COM COM
+5VDC
PS_ON#
COM
COM
COM +5VDC
COM COM
NC
PWR_OK
+5VDC +5VSB
+12VDC
+5VDC
+5VDC +12VDC
+3.3VDC
COM
2 4 1 2
