Timing Chart

Y/N Signal Resolution
Y NTSC 640 480
Y PAL 768 576
Y SECAM 768 576
Y VESA 640 350
Y IBM 640 400
Y VESA 640 400
Y MAC 640 400
Y VESA 640 480
Y IBM 640 480
Y MAC 640 480
Y MAC 640 480
Y MAC 640 480
Y VESA 640 480
Y VESA 640 480
Y IBM 640 480
Y VESA 640 480
Y IBM 720 350
Y IBM 720 400
Y VESA 720 400
Y IBM 720 350
Y IBM 720 400
Y VESA 800 600
Y VESA 800 600
Y VESA 800 600
Y VESA 800 600
Y VESA 800 600
Y MAC 832 624
N VESA 1024 768
Y VESA 1024 768
Y VESA 1024 768
Y IBM 1024 768
Y MAC 1024 768
Y VESA 1024 768
Y VESA 1024 768
Y SGI 1024 768
# MAC 1152 870
# SUN 1152 900
# SGI 1152 900
# SGI 1280 1024
# VESA 1280 1024
# MAC 1280 1024
# HP 1280 1024
# VESA 1280 1024
# SUN 1280 1024
Refresh F.H.
Rate (Hz) (kHz)
60 15.734
50 15.625
50 15.625
85.08 37.86
70 31.47
85.08 37.86
66 35
59.94 31.47
60 31.47
60 31.47
66.7 34.97
66.67 35
72.81 37.86
75 37.5
75 39.375
85.01 43.269
70.09 31.469
70.09 31.4469
85.04 37.927
87.85 39.44
87.7 39.375
56.25 35.16
60.32 37.879
72.19 48.077
75 46.88
85.06 53.674
74.55 49.725
43interlace 35.5
60 48.363
70.07 57.476
72.03 58.131
74.93 60.241
75.03 60.023
85 68.677
60.4 49.7
75.6 68.7
65.95 61.769
70.05 71.736
60 63.9
60.02 64.286
69.89 74.882
72.01 78.125
75.03 79.976
76.11 81.13
Dot
Clk(MHz)
-
-
-
31.5
25.175
31.5
30.24
25.175
25.175
25.175
31.334
30.24
31.5
31.5
31.49
36
28.322
28.322
40
35.5
35.5
36
40
50
49.5
56.25
57.283
44.9
65
75
79
80
78.75
94.5
70
# 1152 870, # 1152 900 and # 1280 1024
100
images are compressed into 1024 768
92.94
105.6
107.35
108
118.5
135
135
135
95
