11 Laser Button
Press and hold this button to activate the laser pointer. When lit, you can use
the laser to draw your audience's attention to a red dot that you can place on
any object within 30 feet (10 m).
12 Mouse Pointer Buttons
Works as a mouse for your computer. This button is also used to adjust
screen position. Push (+) or (–) to select the submenu you want to adjust.
13 Right Click Button
Press this button to exit "Menus" or "Position."
14 Freeze Button
This button will freeze a video image. Press again to resume motion.
15 Position Button
When image is magnified, press this button to activate the mouse. This
allows you to select the portion of the image displayed on screen. Position
button will remain lit for 10 seconds or until right click button is pushed.
NOTE: When you are adjusting Position, the Mouse Pointer button is used to
move the picture.
16 Picture Mute Button
This button turns off the image for a short period of time. Press again to
restore the image.
17 Magnify Button
Use the (+) or (–) button to adjust the image size up to 400%.
18 Slide Button
Press (+) to advance the next file or slide and (-) to return to the
previous file or slide. (the optional LT Viewer board required)
19 Volume Buttons
Press (+) to increase the volume and (–) to decrease it.
20 Remote Jack
Connect your remote control cable here for wired operation.
NOTE: You cannot use Menu and Position at the same time.
Remote Control Precautions
• Do not look into the laser pointer while it is on.
• Do not point the laser beam at a person.
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• If you will not be using the remote control for a long time, remove the
batteries.
• Do not mix new and old or different types of batteries.
INTRODUCTION
OFF POWER
VIDEO S-VIDEO
RGB PC CARD
MENU
-
13
R-CLICK
POSITION PIC-MUTE
15
MAGNIFY SLIDE VOLUME
+
-
17
20
ON
LASER
11
12
+
FREEZE
14
16
+ +
- -
19
18
27
28
