Visual Systems Division
Technical Bulletin
MultiSync LT100 Installation Data
Desk Top and Ceiling Mount
Contents
Projection Distances and Screen Sizes
Notes
§
For Screen Sizes of 24 to 300 inches not indicated on the projection tables, use the formulas below.
§
Set the projection distance based on the width of the screen.
§
If the figures on the tables do not match the figures in the formulas, use the figures in the table.
§
All dimensions are in inches. Multiply by 25.4 for millimeters.
§
Distances may vary +/- 5%.
Formulas
Units: Inches
A = C / COS
B = 3.7H / 25.4
C (WIDE) = (H x 2.026) - 2.437
C (TELE) = C (WIDE) x 1.3
-1
= TAN
((W x 0.375) + B) / C
H = Screen Width
Screen Height = Screen Diagonal (4:3) x 3 / 5
A = Distance between lens center and screen center
B = Vertical distance between lens center and screen bottom (screen top for ceiling mount)
C = Horizontal throw distance between screen surface and projector lens
= Offset Angle of image path center line with reference to desktop or ceiling
