HOOVER
The Easy to
Use Deep
Cleaner
Owner's
Manual
Review this manual before
operating deep cleaner.
Record and Retain
This HOOVER deep cleaner is designed for deep cleaning of
carpet, and rugs. It can also be used to clean carpeted stairs
and upholstery.
The model and serial numbers are located on the data label
on the back of the deep cleaner handle.
For your personal records, please enter the COMPLETE
model and serial numbers in the spaces provided and retain
this information.
Your deep cleaner is model
and has serial number
It is suggested that you attach your sales receipt to this
owner's manual. Verification of date of purchase may be
required for warranty service of your Hoover product.
Index
Important safeguards .....................................................2
Unpacking deep cleaner.................................................2
Assembling deep cleaner........................................... 3-5
Deep cleaner description ...............................................5
General operation ...........................................................6
Filling the clean solution tank ............................ 7-8
Emptying the recovery tank....................................8
Agitator speed selector...........................................6
Brush indicator ........................................................7
Before you begin......................................................9
After cleaning ...........................................................9
Cleaning carpet ......................................................10
Picking up spills.....................................................10
Cleaning bare floors ........................................ 10-11
Using the stair/upholstery nozzle................... 11-12
Cleaning carpeted stairs................................13
Cleaning upholstery .......................................14
If you have a problem ...................................................15
Lubrication.....................................................................14
Service ..........................................................................15
Storage ..........................................................................14
®
with attached tools
ENGLISH
pp. 1 - 15
ESPAÑOL
pág. 16 - 30
FRANÇAIS
p. 31 - 48
Thank you for selecting a HOOVER product.
This cleaner was inspected and packaged carefully before
being shipped from the factory. If you should happen to need
®
assistance during assembly or operation, call
1-800-944-9200 for an automated referral of authorized
service outlet locations (U.S. only) or
1-330-499-9499 (U.S.) and 1-800-263-6376 (Canada)
to speak with a Hoover representative.
PLEASE DO NOT RETURN THIS PRODUCT
Grounding Instructions
This appliance must be grounded. If it should malfunction or
breakdown, grounding provides a path of least resistance for
electrical current to reduce the risk of electric shock. This
appliance is equipped with a cord having an equipment-
grounding conductor and grounding plug (A). The plug must
be plugged into an appropriate outlet (B) that is properly
installed and grounded in accordance with all local codes and
ordinances.
(A)
GROUNDING PIN
DANGER-
Improper connection of the equipment-grounding conductor
can result in the risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether
the outlet is properly grounded. Do not modify the plug
provided with the appliance - if it will not fit the outlet, have a
proper outlet installed by a qualified electrician. This appliance
is for use on a nominal 120 volt circuit and has a grounding
plug that looks like the plug illustrated in sketch (A).
A temporary adapter (C) may be used to connect this plug to a
2-pole receptacle (D) if a properly grounded outlet is not
available. The temporary adapter should be used only until a
properly grounded outlet (B) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like
extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. When-
ever the adapter is used, it must be held in place by a metal
screw.
ADAPTER
(C)
METAL SCREW
NOTE: In Canada, the use of a temporary adaptor is not
permitted by the Canadian Electrical Code.
©
1995, 1996 The Hoover Company
www.hoover.com
TO THE STORE.
(B)
TAB FOR
GROUNDING
SCREW
(D)
1

Advertisement

Table of Contents
loading

  Related Manuals for Hoover SteanVac

  Summary of Contents for Hoover SteanVac

  • Page 1: Table Of Contents

    Review this manual before operating deep cleaner. Record and Retain This HOOVER deep cleaner is designed for deep cleaning of carpet, and rugs. It can also be used to clean carpeted stairs and upholstery. GROUNDING PIN The model and serial numbers are located on the data label on the back of the deep cleaner handle.
  • Page 2: Important Safeguards

    • Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a Hoover Factory Service Center or Authorized Hoover Warranty Service Dealer.
  • Page 3: Assembling Deep Cleaner

    Assembling deep cleaner The assembled cleaner will look like this drawing. Push bolts into holes on front of handle (Fig. 4). If bolts will not go through hole easily handle is not pushed completely down. Place nuts in recessed areas on back of handle. Hold each Attach upper handle nut in place while tightening each bolt securely with a Phillips screw driver (Fig.
  • Page 4 HANDLE NOZZLE CONNECTOR CLIP 1 CORD HOOK CLIP 1 Press cord into cord clip on back of handle. Pull cord tight (Fig. 8). Attach lower hose holder To store hose on rack, begin by placing nozzle connector end HOSE of hose (straight end) into clip 1 on rack (Fig. 12). HOLDER PROJECTIONS HOLES...
  • Page 5: Deep Cleaner Description

    Deep cleaner description The assembled deep cleaner will look like the drawing below. TAB (A) The nozzle is stored in the area between the cord hooks (Fig. 15). Place brushes of nozzle on top of Tab (A) as shown. Gently push the nozzle downward while pivoting it into the nozzle holder (B).
  • Page 6: General Operation

    To transport General operation Turn deep cleaner off before transporting. Operate deep cleaner only at voltage specified on data plate on back of cleaner. ON/OFF pedal ON/OFF PEDAL To move your deep cleaner from room to room, put handle in upright and locked position, tilt deep cleaner back on wheels, and push forward.
  • Page 7: Filling The Clean Solution Tank

    3. Brush indicator screen dirty. For bare floors: To clean screen, turn deep cleaner off and disconnect from Fill cap to fill line (5 ounces) with HOOVER Bare Floor electrical outlet. Cleaner Do not use any type of wax with your ‘SteamVac’ deep cleaner.
  • Page 8: Emptying The Recovery Tank

    REAR OF TANK Replace cap. Rotate cap clockwise until it locks in place. Cap must be locked in place for proper performance and to Unlatch back part of tank lid and remove lid. prevent leaking. Empty tank. Pour dirty water out from the rear of the tank. TABS Position bottom of tank into unit and press on tank handle to snap tank into place.
  • Page 9: How To Use

    If you do not have access to the PreCleaner Spray, double attempt to remove nozzle cover. the amount of HOOVER detergent (use 2 capfuls or 10 oz. Pour one to two cups of clear water on a non-carpeted floor. per 1 gallon) in the clean solution tank.
  • Page 10: Cleaning Carpet

    Cleaning carpet Picking up spills Your HOOVER ‘SteamVac’ deep cleaner may also be used to Read “Before you begin cleaning” instructions on page 9. pick up small liquid spills (1 gallon or less, never to exceed inch in depth) on carpet, upholstery, or bare floors.
  • Page 11: Cleaning Bare Floors

    Do not use the 'SteamVac' deep cleaner on hardwood floors. Fill clean solution tank according to instructions on pages 7 and 8. Use 5 ounces of HOOVER Bare Floor Cleaner. Do not use any type of wax with your ‘SteamVac’ deep cleaner.
  • Page 12 FRONT PANEL TABS FRONT Remove recovery tank front panel by sliding it straight up. The tank lid is replaced in a hinge-like manner. Position front of lid under tabs on front of tank. Rotate lid down onto tank. Make sure lid is secure on all sides before cleaning. For full suction, it is important that the recovery CONVERTER tank lid is properly secured before cleaning.
  • Page 13: Cleaning Carpeted Stairs

    Disconnect hose and solution tube from deep cleaner. Fill clean solution tank according to instructions on pages 7 and 8. Use 5 ounces of HOOVER Carpet/Upholstery Detergent. Hose length may require that machine be placed at the top of the stairs to clean upper half of stairway and at bottom of stairs to clean lower half.
  • Page 14: Cleaning Upholstery

    Be sure to check the cleaning code on your upholstery. Use • Replace empty solution tank and turn deep cleaner your HOOVER ‘SteamVac’ deep cleaner only on upholstery ON. Squeeze trigger and push deep cleaner forward marked “W” or “W/S”.
  • Page 15: If You Have A Problem

    Company on-line at www.hoover.com Possible solution • Recovery tank lid not on correctly Do not send your cleaner to The Hoover Company in • Make sure lid is on securely (page 8) North Canton for service, this will only result in delay.
