HOOVER
The Easy to Use Deep Cleaner
Owner's Manual
Review this manual before oper-
ating carpet cleaning machine.
Record and Retain
This HOOVER carpet cleaning machine is designed for deep
cleaning of carpet, and rugs. Some models can also be used
to clean carpeted stairs and upholstery.
The model and serial numbers are located on the data label
on the back of the carpet cleaning machine handle.
For your personal records, please enter the COMPLETE
model and serial numbers in the spaces provided and retain
this information.
Your carpet cleaning machine is model
and has serial number
It is suggested that you attach your sales receipt to this
owner's manual. Verification of date of purchase may be
required for warranty service of your Hoover product.
Index
Important safeguards .....................................................2
Unpacking cleaner ..........................................................2
Assembling carpet cleaning machine....................... 2-4
Carpet cleaning machine description ...........................4
General operation ...........................................................5
Filling the clean solution tank ............................ 5-6
Emptying the recovery tank................................ 6-7
After cleaning ...........................................................8
Cleaning carpet ........................................................8
Picking up spills.......................................................8
Cleaning bare floors ................................................9
Using the stair/upholstery nozzle..................... 9-10
Cleaning carpeted stairs................................11
Cleaning upholstery .......................................11
If you have a problem ...................................................12
Lubrication.....................................................................12
Service ..........................................................................12
Storage ..........................................................................12
®
TM
Thank you for selecting a HOOVER product.
This cleaner was inspected and packaged carefully before
being shipped from the factory. If you should happen to need
®
assistance during assembly or operation, call
1-800-944-9200 for an automated referral of authorized
service outlet locations (U.S. only) or
1-800-414-1066 (U.S.) and 1-800-263-6376 (Canada) to
speak with a Hoover representative.
DO NOT RETURN THIS PRODUCT

Grounding Instructions

This appliance must be grounded. If it should malfunction or
breakdown, grounding provides a path of least resistance for
electrical current to reduce the risk of electric shock. This
appliance is equipped with a cord having an equipment-
grounding conductor and grounding plug (A). The plug must
be plugged into an appropriate outlet (B) that is properly
installed and grounded in accordance with all local codes and
ordinances.
(A)
GROUNDING PIN
DANGER-
Improper connection of the equipment-grounding conductor
can result in the risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether
the outlet is properly grounded. Do not modify the plug
provided with the appliance - if it will not fit the outlet, have a
proper outlet installed by a qualified electrician. This appliance
is for use on a nominal 120 volt circuit and has a grounding
plug that looks like the plug illustrated in sketch (A).
A temporary adapter (C) may be used to connect this plug to a
2-pole receptacle (D) if a properly grounded outlet is not
available. The temporary adapter should be used only until a
properly grounded outlet (B) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like
extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. When-
ever the adapter is used, it must be held in place by a metal
screw.
ADAPTER
(C)
METAL SCREW
NOTE: In Canada, the use of a temporary adaptor is not
permitted by the Canadian Electrical Code.
©
1993 The Hoover Company
TO THE STORE.
(B)
TAB FOR
GROUNDING
SCREW
(D)
1

Advertisement

loading

  Also See for Hoover F5810

  Related Manuals for Hoover F5810

  Summary of Contents for Hoover F5810

  • Page 1: Table Of Contents

    Review this manual before oper- ating carpet cleaning machine. Record and Retain This HOOVER carpet cleaning machine is designed for deep cleaning of carpet, and rugs. Some models can also be used to clean carpeted stairs and upholstery. The model and serial numbers are located on the data label on the back of the carpet cleaning machine handle.
  • Page 2: Important Safeguards

    • Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a Hoover Factory Service Center or Authorized Hoover Warranty Service Dealer.
  • Page 3 CORD HOOK With cord hook to back of carpet cleaning ma- chine, push upper handle down onto lower handle. (Fig. 2). Push bolts into holes on front of handle (Fig. 3). If bolts will not go through hole easily handle is not pushed completely down.
  • Page 4: Carpet Cleaning Machine Description

    15" 15" 3" 16" 16" Position the remaining straps on the “solution” tube about 16 inches apart. Fasten the straps around the “suction” hose about every 15 inches to allow for flexibility of the hose (Fig. 10). The last strap should be at least 18 inches from opposite end of hose and tube.
  • Page 5: General Operation

    General operation Operate carpet cleaning machine only at voltage specified on data plate on back of cleaner. ON/OFF pedal ON/OFF PEDAL Plug carpet cleaning machine into a properly grounded outlet. Step on pedal to turn carpet cleaning machine on. Step on pedal again to turn carpet cleaning machine off.
  • Page 6: Emptying The Recovery Tank

    Turn cap upside down to serve as a measuring cup. Using cap, measure detergent following the chart below. For carpet and carpeted stairs: Fill cap to upper “carpet” fill line (5 ounces) with HOOVER Carpet/Upholstery Detergent. For bare floors: Fill cap to upper "carpet” fill line (5 ounces) with HOOVER Bare Floor Cleaner (available at additional cost if not included with your model.)
  • Page 7: How To Use

    ‘SteamVac’ carpet cleaning machine as a dry vacuum cleaner. For upholstery, check cleaning code - Use your HOOVER ‘SteamVac’ cleaning machine only if the uphol- stery fabric is marked with a “W” (for “wet” clean) or “S/W” (for “solvent/dry” or “wet” clean). Do not clean fabric marked “S”...
  • Page 8: After Cleaning

    Read “Before you begin cleaning” instructions on page 7. Fill clean solution tank (upper tank) according to instructions on pages 5 and 6. Use 5 ounces of HOOVER Carpet/Upholstery Detergent. Dry hands and plug cord into a properly grounded outlet. Do not clean over floor electrical outlets.
  • Page 9: Cleaning Bare Floors

    Do not use the 'SteamVac' carpet cleaning machine on hard- wood floors. Fill clean solution tank according to instructions on pages 5 and 6. Use 5 ounces of HOOVER Bare Floor Cleaner. grounded outlet. To release solution, squeeze trigger. Slowly move carpet Step on handle release pedal and lower handle to operating position;...
  • Page 10 HANDLE RELEASE PEDAL Step on handle release pedal and lower carpet cleaning machine handle until it rests on the floor. Unlatch back part of recovery tank lid and remove lid. Remove recovery tank front panel by sliding it straight up. HOSE CONNECTOR Replace panel with hose connector.
  • Page 11: Cleaning Carpeted Stairs

    Attach hose and solution tube as instructed on pages 9 and 10. Fill clean solution tank according to instructions on pages 5 and 6. Use 5 ounces of HOOVER Carpet/Upholstery Detergent. Hose length may require that machine be placed at the top of the stairs to clean upper half of stairway and at bottom of stairs to clean lower half.
  • Page 12: Troubleshooting

    Do not send your cleaner to The Hoover Company in North Canton for service, this will only result in delay. If further assistance is needed, contact The Hoover Company Consumer Response Center, North Canton, Ohio 44720 Phone: 1-800-414-1066.
