- Page 1 Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number This appliance has been designed for domestic use only.
-
Page 3: Before First Use
• Do not put solvents in the dishwasher detergent compartment to prevent risk of explosion • Only put dishwasher safe items into the dishwasher. If in doubt, check with the manufacturer of the items. • Take care when loading the dishwasher to observe the recommendations for best loading practice, and also to ensure that sharp objects such as knives are placed blade down to prevent accidents. -
Page 4: Control Panel
Control Panel Power button (1) • To switch the dishwasher on or off, press the power button (1). When you switch on the dishwasher, the end of programme light will illuminate, and two dashes will appear on the display. Programme display (2) The programme display shows the selected programme and the remaining time to run. - Page 5 Please note: You should ensure that there are no dishes in the upper basket when running a lower basket half- load programme, and none in the lower basket when running an upper basket half-load programme. If you have selected any extra function (3 in 1, prewash, half-load) for a programme, this function will automatically be selected the next time the dishwasher is used.
- Page 6 As a result, it is recommended that powder detergents should be used in the shorter programmes to allow better performance. CDA recommends the use of separate detergent, rinse aid and dishwasher salt rather than combination tablets as separates achieve better wash performance.
- Page 7 Salt To ensure the best efficiency, the dishwasher needs soft water. Hard water means that lime residues remain on the dishes and the interior of the dishwasher, affecting performance. The softener system is designed to remove the ions that make the water hard to provide the best quality wash performance.
-
Page 8: Softener Adjustment
Softener Adjustment The efficiency of your dishwasher depends on the softness of the tap water. To ensure best efficiency, the dishwasher is equipped with a system that reduces the hardness in the mains water supply. The efficiency will increase when the system is correctly set. -
Page 9: Rinse Aid
Rinse Aid To fill the rinse aid compartment 1. Open the rinse aid compartment by turning and removing the cap as shown in figure 5. 2. Fill the rinse aid compartment until the rinse aid indicator goes dark, as shown in figure 6 (where a indicates the compartment is empty, and “b”... -
Page 10: Dishwasher Baskets
Dishwasher Baskets Top basket height adjustment while it is The upper basket has two different heights available, to allow for Basket he larger products in either the upper or lower basket. To raise or your mach lower the upper basket: Top basket height adjustment while it is full Top basket height adjustment while it is full top basket... -
Page 11: Standard Loading And Test Data
Standard Loading and Test Data Capacity • Upper and lower baskets: 12 place settings. • The upper basket should be adjusted to high position. • Cups should be placed on to the dish rack pins. Detergent / Rinse aid • 5 + 25 cm3, in accordance with EN50242-DIN 44990 IEC 436 (international norms) / Rinse aid dosage adjustment: 4. -
Page 12: Programme Listing
Programme Listing Auto Auto- Auto- Programme name Intensive Express Quick Prewash Intensive+ Intensive normal delicate 60 O 60 O 50 O 40 O 70 O and temperature 60-70 O 50-60 O 30-50 O Level of soil High High High Medium Medium High Detergent... -
Page 13: Care And Maintenance
Care and Maintenance Before beginning any care or maintenance, you should always disconnect the appliance from the electricity supply, and also turn off the water supply. Door seals Wipe the dishwasher door seals regularly with a damp cloth to remove any residues. Filters fig. -
Page 14: Failure Codes And Troubleshooting
The programme indicators also serve as a diagnostic display to help in the event of a problem with the appliance. Error Code Error description Advice • Turn off the dishwasher and disconnect the water supply Water leakage has been detected • Contact CDA Customer Care • Drain hose is blocked • The filters of your machine might be blocked The waste water cannot be discharged • Restart the dishwasher and cancel the programme • If the error continues, contact CDA Customer Care... - Page 15 Failure Codes and Troubleshooting Problem Possible cause Check the plug, fuse and circuit breakers of the mains supply. The water tap is turned off. The programme will not start The dishwasher door is not fully closed. The water inlet filter or the machine filters are blocked. The water drain hose is blocked or kinked.
-
Page 16: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. -
Page 17: Installation
Installation • D o not install this appliance if it is damaged in any way. Installing a damaged appliance may invalidate the warranty. • T he water supply tap should be located in an adjacent cupboard so that it can be accessed after installation. •... -
Page 18: Fitting The Integrated Appliance Door
Fitting the integrated appliance door Where non-standard integrated appliance doors are supplied, additional fitting instructions are required to ensure compatibility with this product. The machine is supplied with a fitting template and these instructions should be followed as normal. Fitting template However, the fitting template needs to be located lower down the fascia door;... - Page 19 Notes...
- Page 20 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
